https://wiki.teltonika-networks.com/view/QSG_TAP100
QSG TAP100
Main Page
>
TAP Access Points
This Wiki page contains the online version of the Quick Start Guide (QSG) for the TAP100 Access
Point. Here you will find an overview of the various components for TAP100 device, hardware
installation instructions, first login information, device specifications, and general safety
information. It is highly recommended to acquaint yourself with the Quick Start Guide before using
the device.
Contents
•
1 Safety information
-
1.1 General
-
-
-
-
-
•
•
•
•
•
•
•
•
Safety information
Before starting operating the device, please review recommendations and precautions to minimize
the possibility of accidents. Safety precautions presented are supplementary and subject to the local
safety regulations. When various operations are executed on the device, the user must fully follow
the safety instructions and recommendations provided with the device.
General
RF technologies Wi-Fi
Max RF power 20 dBm@W-iFi
Integrated antennas specifications
WiFi antenna
2x 2400~2500 MHz, peak gain < 4.9 dBi, omnidirectional
Bundled accessories specifications*
Power adapter Input: 0.5 A@100-240V VAC, Output: 52 VDC, 0.35A, 802.3af
* Order code dependant.
> QSG TAP100
>
TAP100
Radio specifications
www.ime.de
Advertisement
Table of Contents
Related Manuals for Teltonika TAP100
Summary of Contents for Teltonika TAP100
-
Page 1: Table Of Contents
> TAP100 This Wiki page contains the online version of the Quick Start Guide (QSG) for the TAP100 Access Point. Here you will find an overview of the various components for TAP100 device, hardware installation instructions, first login information, device specifications, and general safety information. - Page 2 TAP100 access point must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the communication module in prescribed applications and environments. CE Declaration of Conformity С настоящото TELTONIKA NETWORKS декларира, че този TAP100 е в...
-
Page 3: Rf Exposure
This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Hereby, TELTONIKA NETWORKS declares that this TAP100 is in compliance with the essential requirements and other relevant provisions of Directives 2014/53/EU, 2011/65/EU, 2009/125/EC. -
Page 4: Operating Conditions
RF exposure exceeding the applicable limits. External antennas used with TAP100 must be installed to provide a distance of at least 20 cm from any people and must not be co-located or operated in conjunction with any other antenna or transmitter. -
Page 5: Bottom View
www.ime.de use. Use of your device is subject to safety measures designed to protect users and their environment. Always treat your device and its accessories with care and keep it in a clean and dust-free place. Do not expose your device or its accessories to open flames, lit tobacco products, liquid, moisture, or high humidity. -
Page 6: Tap100 Rj45 Port
TAP100 RJ45 Port Video Quick Start Guide Need some help setting up your new Teltonika Networks TAP10 Access Point? Watch our quick start guide video and follow the step-by-step instructions to set up your new access point for operation easily. -
Page 7: Tap100 Setup Without Internet Access
8 characters. Requirements: one uppercase letter, one lowercase letter, and one digit. TAP100 Setup Without Internet Access If you need to configure the TAP100 without an internet connection, please refer to the guide in this section. - Page 8 www.ime.de 1. Ensure the Wireless network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right- click on Wireless Network Adapter, and select Enable.
- Page 9 6. Choose the wireless network TAP100 **** from the list and click Connect. Enter the WiFi password located on the device's label. 7. To enter the router's Web interface (WebUI), type http://192.168.1.3 into the URL field of your Internet browser.
