Summary of Contents for Heatsail BEEM Series
- Page 1 B E E M ® M A N U A L N L / E N / F R / D E For the most recent version of this manual, check our website. Do not discard this manual, as it contains your device’s serial number. User manual...
- Page 2 Heatsail BEEM WIRING®...
- Page 3 Assembly and wiring instructions - Installation illustrée et schémas de connections The BEEM has seperated powerlines for heating and Le BEEM a des lignes électriques séparées pour le lighting, which enables the BEEM to work on 2 different chauffage et l’éclairage, ce qui permet au BEEM de incoming voltages.
- Page 4 1 FIL NEUTRE • 1 GROUNDING WIRE • 1 FIL DE TERRE CUT THE FOURTH PIN OF THE DIMMER AND REMOVE COUPER ET ENLEVER LA QUATRIÈME BROCHE DU GRADATEUR BLACK GRAY BROWN BLACK GRAY BROWN NEUTER BLACK GRAY BROWN Heatsail BEEM WIRING®...
- Page 5 V E R S I O N A T 2 4 0 - 1 2 0 V O LT S T E P 2 / E T A P E 2 Insert the wires into the corresponding terminals: Branchez le câble électrique du BEEM dans les trous Follow the numbering below.
-
Page 6: Factory Setting
TOGETHER TO 240 VOLTS: RELIÉS ENSEMBLE À 240 VOLTS : • 2 HOT WIRES • 2 FILS CHAUDS • 1 GROUNDING WIRE • 1 FIL DE TERRE FACTORY SETTING CONFIGURATION D’ORIGINE BLACK GRAY BROWN NEUTER BLACK GRAY BROWN Heatsail BEEM WIRING®... - Page 7 V E R S I O N A T 2 4 0 V O LT S T E P 2 / E T A P E 2 Insert the wires into the corresponding terminals: Branchez le câble électrique du BEEM dans les trous Follow the numbering below.
- Page 8 PUSHING UPWARD IN THE CORNER AND ROTATING VERS LE HAUT ET EN FAISANT PIVOTER LE COIN THE BOTTOM CORNER OF THE GLASS OUT OF THE INFÉRIEUR DU VERRE HORS DE OPENING. L’OUVERTURE. FOLLOW THE DRAWINGS BELOW. SUIVEZ LES DESSINS CI-DESSOUS. Heatsail BEEM WIRING®...
-
Page 9: Replace The Bulb
V E R S I O N A T 2 4 0 V O LT S T E P 5 / E T A P E 5 REPLACE THE BULB REMPLACEZ LA LAMPE TURN OFF THE POWER SUPPLY FIRST! THE BULB SITS IN COUPEZ D’ABORD L’ALIMENTATION ÉLECTRIQUE ! PLACE IN A HOLDER AND CAN BE REMOVED BY GENTLY L’AMPOULE EST PLACÉE DANS UN SUPPORT ET PEUT... - Page 10 Corporate Headquarters U.S. Office HEATSAIL NV HEATSAIL USA INC Prins Boudewijnlaan 7 Unit A 08 1910 North Josey Ln 2550 Kontich Carrollton, Texas 75006 Belgium United States of America +32 3 502 99 88 +1 214 808 5091 sales@heatsail.com UCM@heatsail.com www.heatsail.com...
