- Page 1 INFORMATION FOR FIRST AND SECOND RESPONDERS EMERGENCY RESPONSE GUIDE NIO EL8 ELECTRIC VERSION: 001...
- Page 2 Take the used battery to a recycling center or to your service center. ONLINE USER MANUAL This guide provides the basic operating instructions of NIO EL8. For owners who want insights and detailed information about the features and functions of the car, an in-depth online...
-
Page 3: Table Of Contents
7. In case of submersion Page 21 7. In case of submersion Page 21 8. Towing / transportation / storage Page 21 9. Important additional information Page 23 10. Explanation of pictograms used Page 25 NIO EL8 Emergency Response Guide... -
Page 4: Rescue Sheet
0. Rescue sheet This Emergency Response Guide covers the NIO EL8 corresponding rescue sheet. 1. Identification / recognition WARNING Silent movement or instant restart capability exists until vehicle is fully shut down. EL8 Information Vehicle manufacturer NIO hotline Refer to the contact table... - Page 5 The vehicle nameplate is located under the B-pillar on the right side. The vehicle brand logo can be found in the following places: NIO EL8 Emergency Response Guide...
- Page 6 Instrumentation and Controls 1. Electronic Switch for Inner Door Handles 11. Gears and Central Control Panel 2. Window Control Panel 12. Central Control Wireless Charging Board 3. Left Switches of Steering Wheel 13. Accelerator Pedal 4. Turn Light and Headlight Stalk 14.
- Page 7 C, K or L. Voltage ranges related to those identifiers are as follows: C: AC ≤ 480 V K: DC 50 V to 500 V L: DC 200 V to 920 V NIO EL8 Emergency Response Guide...
- Page 8 5. Lower left corner of the front windshield 6. Above the rear floor 7. On the right side of the trunklid You can also read the vehicle identification number (VIN) with a diagnostic tool (Second Generation NIO Diagnostic System (BD2)) that is compatible with the vehicle:...
- Page 9 Drive Motor Identification Mark The front drive motor identification mark is The rear drive motor identification mark is located under the motor. located on the lower left side of the motor. NIO EL8 Emergency Response Guide...
-
Page 10: Immobilisation / Stabilisation / Lifting
2. Immobilisation / stabilisation / lifting Set Up Warning Signs How to assemble the warning triangle: In the event of an emergency, drive the vehicle to a safe area while ensuring safety, then depress the brake pedal to stop the vehicle;... - Page 11 WARNING then contact NIO Service Center for a tire replacement. If there is a risk of battery fire, the vehicle will automatically cut off the power, and a WARNING warning message will pop up on the instrument panel •...
- Page 12 current suspension height of the vehicle, WARNING preventing any changes in the suspension height during the tire changing process. Ensure that the jack is placed at the correct jacking point. 4. Use the bolt cover remover in the vehicle An incorrect jacking point will kit to remove the bolt covers, and loosen damage the vehicle or cause the bolts counterclockwise with the wheel...
-
Page 13: Disable Direct Hazards / Safety Regulations
Chemical Protection it properly. In case of battery leakage or potential risk of battery leakage, wear the following protective equipment to prevent injury to your skin and face: • Protective mask • Solvent resistant gloves NIO EL8 Emergency Response Guide... - Page 14 There are 2 ways to cut off the high voltage circuit: 1. Main Disabling Method In case of emergency, cut the harness with tool to shutdown the high voltage circuit. Access to 12 V Battery Disconnect the cable from the 12 V battery negative terminal, and wrap it with a protective layer after disconnection to prevent conduction due to accidental...
-
Page 15: Access To The Occupants
To raise or lower the seat, toggle the center portion of this button up or down. Seat Cushion Length Adjustment To adjust the length of the seat cushion, press this button on the matching end. NIO EL8 Emergency Response Guide... - Page 16 Opening the Hood with Power WARNING Trunklid • Make sure there is a safe Opening and Closing the Trunklid by space around the seat Pressing the Button and any rear children, passengers, pets, etc. before When you carry the smart key, lightly press you make any adjustments the pressure plate on the handle of the to the seat (i.e.
- Page 17 2. Press and hold the front part of the outer door handle of the driver’s door to unfold the outer door handle. NIO EL8 Emergency Response Guide...
- Page 18 CAUTION CAUTION If you want to use the smart key to lock the • When the 12 V battery of the vehicle is door after having unlocked the driver's door low on power, the physical emergency key using the physical emergency key, you need can only be used to unlock the door on to open and close the driver's door once to the driver side.
- Page 19 If cutting is required during rescue, appropriate tools should be used. The high-voltage and high-pressure areas of the vehicle shall not be cut, such as airbag-related components, high- voltage components, etc.. NIO EL8 Emergency Response Guide...
-
Page 20: Stored Energy / Liquids / Gases / Solids
5. Stored energy / liquids / gases / solids 12 V 350 V E-Powertrain System Information 1. High voltage control system 10. High voltage battery 2. Emergency HV cut-off plug 11. Charge port 3. Air conditioning HV electric heater 12. Airbag control unit 4. - Page 21 The vehicle is equipped with two electric drive systems, of which the front electric drive system is installed on the front sub-frame, and the rear electric drive system is installed on the rear sub-frame. NIO EL8 Emergency Response Guide...
-
Page 22: In Case Of Fire
6. In case of fire USE LARGE AMOUNTS OF WATER DO NOT SUBMERGE VEHICLE TO BATTERY RE-IGNITION! EXTINGUISH BATTERY Rescuing the Vehicle on Fire If the vehicle's HV battery catches a fire or gets heated, or is even bent, ruptured, or damaged, use a large amount of water or WARNING water mixed with foam extinguishing agent... -
Page 23: In Case Of Submersion
When the vehicle is on snow, mud, or sand, or when the wheels are locked and unable to rotate freely, do not use a towing hook to tow the vehicle. Please contact the NIO service center. NIO EL8 Emergency Response Guide... - Page 24 2. Press the lower end of the front towing 6. After the vehicle is towed to the flap of the vehicle to open it (1 in the designated location on the flatbed, use figure), insert the hitch into the hole and brake stops and wheel straps to fix the rotate until the hitch is firmly seated (2 tires.
-
Page 25: Important Additional Information
9. Important additional information Must Read Thank you for choosing NIO’s EL8 model (hereinafter referred to as “EL8”). EL8 is a smart electric SUV. During your green journey with EL8, you will get a seamless and considerate user experience. Before starting your journey with EL8, it is recommended that you read the User Manual from the center display to get all the information you need to use the vehicle. - Page 26 This content gives you suggestions for better use of your vehicle. If you have any questions about this guide, please call the NIO hotline, or log on to the NIO official website to obtain the latest version of the EL8 User Manual.
-
Page 27: Explanation Of Pictograms Used
10. Explanation of pictograms used Warning high voltage Flammable Caution Hazardous to the human health Air-conditioning component Acute toxicity Electric vehicle Corrosives Bonnet Gases under pressure Boot Explosive Use thermal Infrared camera Use water to extinguish the fire NIO EL8 Emergency Response Guide...
