Wall-Smart 085-1-347-UBL Manual

Model:
Model No.:
Make Your Wall Smart Make Your Wall Smart
"WS IN-WALL MOUNT FOR SONOS BEAM " - Product description: "WS IN-WALL MOUNT FOR SONOS BEAM " - Product description:
The "WS IN-WALL MOUNT FOR SONOS BEAM" is an adapter for in-wall The "WS IN-WALL MOUNT FOR SONOS BEAM" is an adapter for in-wall
nearly flush installation of a SONOS Beam sound bar. nearly flush installation of a SONOS Beam sound bar.
The "WS IN-WALL MOUNT FOR SONOS BEAM" conceals the sound bar The "WS IN-WALL MOUNT FOR SONOS BEAM" conceals the sound bar
while allowing easy access, removal and operation. while allowing easy access, removal and operation.
Key features and benefits: Key features and benefits:
Nearly flush with the wall (7.6mm [0.3"] thick on-wall grille). Nearly flush with the wall (7.6mm [0.3"] thick on-wall grille).
• •
Allows easy insertion and removal of the sound bar. Allows easy insertion and removal of the sound bar.
• •
Wall adapter includes knockouts to install US or UK backboxes and Wall adapter includes knockouts to install US or UK backboxes and
• •
receptacles (See page 4 for backbox installation instructions) receptacles (See page 4 for backbox installation instructions)
(to install an European backbox use 085-1-347-EBL/EWH "WS IN- (to install an European backbox use 085-1-347-EBL/EWH "WS IN-
WALL MOUNT FOR SONOS BEAM EU&IL BLACK/WHITE") WALL MOUNT FOR SONOS BEAM EU&IL BLACK/WHITE")
Wall adapter is designed for the use with the following backboxes: Wall adapter is designed for the use with the following backboxes:
• •
o UK – BS4662 2 Gang (or equivalent) o UK – BS4662 2 Gang (or equivalent)
o US – HUBBELL Racobox 420 (or equivalent) o US – HUBBELL Racobox 420 (or equivalent)
Wall adapter is designed for High Fidelity audio output Wall adapter is designed for High Fidelity audio output
• •
Grille is supplied white (UWH) or black (UBL) Grille is supplied white (UWH) or black (UBL)
• •
Grille is made with high quality acoustic and IR transparent fabric Grille is made with high quality acoustic and IR transparent fabric
• •
Grille attaches magnetically to the wall mount base Grille attaches magnetically to the wall mount base
• •
Wall Board thickness may be 9.1mm[0.36"] up to 18.4mm[0.72"] Wall Board thickness may be 9.1mm[0.36"] up to 18.4mm[0.72"]
• •
Designed for the use with Beam sound bar (by SONOS)(not included) Designed for the use with Beam sound bar (by SONOS)(not included)
• •
Wall adapter is supplied unassembled (See page 3 for instructions) Wall adapter is supplied unassembled (See page 3 for instructions)
• •
See page 2 for package content See page 2 for package content
• •
Key properties: Key properties:
Dimensions: (W/H/D): 1016mm (40")/203.2mm (8")/ 157.7mm (6.21") Dimensions: (W/H/D): 1016mm (40")/203.2mm (8")/ 157.7mm (6.21")
• •
Weight: 4.3Kg, 9.5lbs. Weight: 4.3Kg, 9.5lbs.
• •
Material: Moisture resistant MDF (compliant with TSCA Title VI) Material: Moisture resistant MDF (compliant with TSCA Title VI)
• •
UNLESS OTHERWISE SPECIFIED:
Wall
-Smart Ltd.
by
DIMENSIONS ARE IN MILLIMETERS
www.wall-smart.com Phone: (201) 205-2056 / info@wall-smart.com
WS IN-WALL MOUNT FOR SONOS
BEAM US&UK BLACK/WHITE
085-1-347-UBL/UWH
[0.36 ~ 0.72]
9.1 ~ 18.4
WALL EDGE
THICKNESS RANGE
40.00
1016
DEPTH BEHIND WALL
INFORMATION CONTAINED HEREIN IS PROPRIETARY AND MAY NOT BE USED,
REPRODUCED OR COPIED WITHOUT WRITTEN CONSENT OF WALL-SMART z z z z
Family:
DWG NO.
PRODUCT SPEC.
0.30
5.91 7.6
150.1 GRILLE THICKNESS
ON-WALL
WALL-SMART
085-4-347-U-SPC
REVISION B
DATE 16/FEB/2022
38.7
982
WALL OPENING
SHEET 1/5
