- Page 1 Operation Manual Sembdner Manual Roller HR 60 E Electric Drive Sembdner Maschinenbau GmbH – Liebigstraße 16, 82256 Fürstenfeldbruck Telefon +49 (8141) 81851-0 - Telefax +49 (8141) 81851-14 Subject to technical changes; errors excepted - as of 09/2021...
-
Page 2: Table Of Contents
Table of contents Technical Data ..........................3 Machine characteristics ......................3 Type Label ............................ 3 Intended Use ..........................3 General ............................. 3 Limitation of Liability ........................3 Guarantee/Warranty ........................4 Accident prevention regulations ....................4 Safety Instructions .......................... 4 Installation ............................4 Scope of Delivery ......................... -
Page 3: Technical Data
We do not accept any liability for damage and malfunctions caused by operating errors, non-compliance with these operating instructions or improper repairs. SEMBDNER Maschinenbau GmbH accepts no liability for damage resulting from the use of non-original spare parts and / or accessories. -
Page 4: Guarantee/Warranty
2.2 Guarantee/Warranty Warranty claims are to be made immediately after the damage has been determined, stating the purchase details. Complaints have to be confirmed by us. Wear parts are not covered by the warranty. Guarantee/Warranty expires with: - improper operation - improper use - Nonuse of original spare parts 2.3 Accident prevention regulations... -
Page 5: Operation
5.2 Accessory frame for GSD vegetable seeding machines The manual roller HR 60 E Electric Drive can be equipped with an accessory frame for up to 3 GSD vegetable seeding machines (the balance weight cannot be installed then.) -
Page 6: Balance Weight
5.3 Balance Weight To make handling easier, a balance weight can be attached to stabilize the roller (it is not possible to install the accessory frame for GSD then). The balance weight can be swivelled via the additional holes and thus, depending on the filling of the roller, contributes to balanced and therefore body-friendly work. - Page 7 Step 5 Step 6 Step 7 Step 8 Page 7 of 12 12211218Seite 7 von 12...
-
Page 8: Roller Stand
The balance weight can also be used as a roller stand: 5.4 Roller stand The roller can be safely parked with the help of the foldable roller stand. Montage: Page 8 of 12 12211218Seite 8 von 12... -
Page 9: Operation Of The Controller
5.5 Operation of the controller To switch on the machine, the main switch of the battery must be switched to ON. The required speed can be preselected by means of the control knob located on the controller box; the position of the direction selector switch determines the direction of travel. The machine is put into operation by actuating the driving buttons on the tie bar. -
Page 10: Service / Maintenance
6. Service / Maintenance 6.1 Notes on maintenance The motor itself is maintenance-free; however, it is recommended that the cap nut of the motor be secured with medium-strength liquid threadlocker for a tight fit. The ball bearing opposite the motor should be lubricated regularly (at least once a year or according to the intensity of use). -
Page 11: Spare Parts
6.3 Spare Parts Only original spare parts from SEMBDNER may be used, otherwise the guarantee claims will expire. 6.4 Customer Service Our specialist staff and our resellers, agricultural machinery dealers and motorists are at your disposal for all technical information. -
Page 12: Declaration Of Conformity
Liebigstr. 16 82256 Fürstenfeldbruck herewith declares that the product Manual Roller HR 60 E Electric Drive to which this declaration relates, is in conformity with the relevant safety and health provisions stipulated by EG Directive 2006 / 42 / EG Peter Schwarzmann Fürstenfeldbruck, Oct.
