Summary of Contents for MiniBot NANOPIX
- Page 3 Take the drone body (see at the motors schematic below) and insert the motor into one of the legs, as seen in the picture, until you feel a click. motor shaft upward Wrap the wire around the jumper in the leg as shown in the picture.
- Page 4 Connect the two velcro pieces together with a 1.5 - 2cm overlap. Insert the resulting part into the drone body from top, using two oblong holes. edge outside. edge 1-2 cm from inside. the edge Partly insert the main control board by sliding it sideways into the body.
- Page 5 After inserting all the connectors push the board fully into the body. Cover the board with the supplied transparent cap. Make sure the red and black power wires leave the body through an opening in the side of the cover. Insert the propeller guard such that the retainers - four protrusions on the guard - stay inside the leg.
- Page 6 Blade guard touches the body. Retainers are placed inside the legs. Install the battery and fasten it tightly with velcro. If the ends are too long, cut them slightly. Board wire and battery wire extend to one side. Make sure that the This zone should not distance sensor is not be covered by other...
- Page 7 Red and black power wires on the right. marking of the propeller (B) - identical motor wires diagonally red/blue and black/white CHECK - Propellers are installed according to the scheme. Install the Nanopix Pilot app from Google Play Store. Network: NanopixXXXXX Password: 12345678...
