- Page 1 Libelium One Quick start guide...
-
Page 2: Table Of Contents
Index 1. Read before using 2. What's in the box 3. Node activation 4. Sensor Connection 5. Powering 6. Configuration & Data visualization 7. Installation 7.1. Wall mount 7.2. Pole mount 7.3. Solar panel installation 8. Support 9. Disposal and recycling 10. -
Page 3: Read Before Using
(1) , certifications (2) or a QR code for easy provisioning (3). Scan the QR code to access the device tab in the Libelium Cloud, but be sure to be logged into Libelium Cloud with your personal account and to be the owner of the device. Otherwise the URL on the QR code will not work. -
Page 4: Node Activation
Because of that, sensors will not be detected while in this state and no information will be sent to the Libelium Cloud. To exit this state the node needs to be reset three times, as shown in the next video. - Page 5 Up to four sensors can be connected to the node using the bottom connectors labeled from A to D. All sensor sockets are equal, so they can accept any of the One sensor probes offered by Libelium. Bottom side with sensors and power socket, without caps The next video shows the process.
-
Page 6: Powering
Quick start guide 5. Powering There are two common external power sources for the Libelium One node. The power grid and solar panels. In both cases, the cable is connected to the unique power socket, so the user should make the most suitable choice for the application. -
Page 7: Configuration & Data Visualization
Quick start guide 6. Configuration & Data visualization The Libelium One main node sends the sensor measurements directly to the Libelium Cloud, using the cellular radio module embedded by default. An account on the Libelium Cloud platform is needed (it... -
Page 8: Installation
Libelium One Quick start guide 7. Installation The equipment shall be installed in a proper way to ensure endurance over time. Due to each location having specific conditions, the node enclosure and the installation accessories have been designed for versatility and adaptability. For instance, there are no restrictions on height from the floor, but always ensure there are no loose screws on the enclosure, sensor connectors are firmly screwed, and cable ties are correctly tightened. - Page 9 Libelium One Quick start guide Installation accessory Remember to screw firmly the accessory screw to avoid a loose installation that may have vibrations from wind or other environmental factors. Screw firmly the accessory libelium.com...
-
Page 10: Pole Mount
If a solar panel is going to be used together with the node, the whole set could use the same holes and cable ties. The assembly of the solar panel mounting accessory with the solar panel and the Libelium one main node is shown below. Solar panel with One... - Page 11 Libelium One Quick start guide The next step is to remove the side screw used to fix the position of the accessory during transport and place it in the indicated hole, allowing angle regulation. The next figure shows how the node installation accessory fits together with the solar panel.
- Page 12 Libelium One Quick start guide Assembling the whole set Fastening the side screw Finally, the solar panel angle could be adjusted to the latitude of the deployment to maximize its efficiency by the two side screws of the accessory. Adjusting solar panel angle...
-
Page 13: Support
