Summary of Contents for VEIKOUS PG0101-18
- Page 1 Cedar Poly Greenhouse...
- Page 2 1-858-324-1911 (Mon - Fri, 10:00 am to 7:00 pm EST) you can also e-mail customerservice@veikous.com or visit www.veikous.com Please prefer email contact. Due to busy lines, there may be a wait for calls to be answered.
- Page 3 Structure Location Preparation Note: lt is critically important you start with square, solid and level base to attach your Greenhouse. The hardware to mount the structure permanently will need to be purchased separately at your local hardware store. Before preparing your surface for the structure please double check for possibility of any underground utilities such as gas, telephone, cable or sprinkler lines.
- Page 4 Wood Parts List 1A (Front Base) 1PC 1B (Back Base) 1PC 2 (Left Post) 2PCS 3 (Right Post) 2PCS 4A (Left Door Post) 1PC 4B (Right Door Post) 1PC 5 (Front Wall Sill) 2PCS 6 (Left Roof Rafter) 2PCS 7 (Right Roof Rafter) 2PCS 8 (Gable Beam) 2PCS 9 (Peak Spacer) 2PCS...
- Page 5 10 (Back Wall Sill) 1PC 11A (Back Post) 2PCS 12 (Left Side Base) 2PCS 13 (Right Side Base) 2PCS 14 (Side Post) 6PCS 15 (Left Side Wall Sill) 2PCS 16 (Right Side Wall Sill) 2PCS 17 (Left Side Wall Top) 2PCS 18 (Right Side Wall Top) 2PCS 19 (Roof Brace) 2PCS...
- Page 6 20A (Left Roof Peak) 1PC 20B (Right Roof Peak) 1PC 22 (Middle Roof Rafter) 4PCS 23 (Window Roof Rafter) 2PCS 24 (Side Vent Block) 2PCS 25 (Bottom Vent Block) 1PC 26-1 (Window-1) 1PC 26-2 (Window-2) 1PC 26-3 (Window-3) 1PC 26-4 (Window-4) 1PC 26-5 (Window-5) 1PC 27-1 (Door-1) 1PC...
- Page 7 27-2 (Door-2) 1PC RR (Guide Spacer) 2PCS This part is used to assist 27-3 (Door-3) 1PC with assembly. 27-4 (Door-4) 1PC 27-5 (Door-5) 1PC 30 (Door Block) 2PCS 27-6 (Door-6) 1PC A (Front/Back Wall Panel) 4PCS B (Back Middle Wall Panel) 1PC C (Side Wall Panel) 8PCS...
- Page 8 Polycarbonate Board List E 2PCS E1 2PCS D 2PCS D1 2PCS H 7PCS F 1PC G 8PCS K 1PC I 1PC J 1PC NOTE: When installing the panel, keep the UV-protected side facing out (White plastic film). Remove the plastic film on both sides and lock in place before inserting the panel.
-
Page 9: Hardware List
Hardware List OO(Wood Screw) AA(Wood Screw) 12PCS 90PCS JJ(Wood Screw) HH(Nut) 18PCS 12PCS BB(Wood Screw) 94PCS PP(Washer) 24PCS CC(Wood Screw) 46PCS QQ(Hex Key) DD(Wood Screw) 18PCS EE(Wood Screw) 20PCS FF(Bolt) 8PCS GG(Bolt) 4PCS KK(Window Long Hinge With Screw) LL(Door Hinge With Screw) 2PCS 28(Roof Bracket) 3PCS MM(Door Handle With Screw) -
Page 10: Step1 Front Wall Assembly
Step1 Front Wall Assembly 1 Wood Parts Hardware 1x 1A(Front Base) 4x BB(Wood Screw) 1x 2(Left Post) 1x 3(Right Post) - Page 11 Step2 Front Wall Assembly 2 Wood Parts Hardware 2x A(Front/Back Wall Panel) 4x BB(Wood Screw) 1x 4A(Left Door Post) 1x 4B(Right Door Post)
- Page 12 Step3 Front Wall Assembly 3 Hardware Wood Parts 4x BB(Wood Screw) 2x 5(Front Wall Sill) 8x CC(Wood Screw) 4x EE(Wood Screw) Guide Spacer NOTE: Guide spacers are placed in the grooves of the posts, door- posts, and front wall sill to align the posts, and then removed when the posts are correctly aligned.
- Page 13 Step4 Front Wall Assembly 4 Polycarbonate Board Hardware Wood Parts 1x D 4x DD(Wood Screw) 1x 8(Gable Beam) 1x D1...
- Page 14 Step5 Front Wall Assembly 5 Wood Parts Polycarbonate Board Hardware 1x 19(Roof Brace) 1x E 2x DD(Wood Screw) 1x E1 Guide Spacer...
- Page 15 Step6 Front Wall Assembly 6 Hardware Wood Parts 1x 6(Left Roof Rafter) 3x JJ(Wood Screw) 2x BB(Wood Screw) 1x 7(Right Roof Rafter) 4x CC(Wood Screw) 1x 9(Peak Spacer) 1.77in (4.5cm)
-
Page 16: Step7 Back Wall Assembly
Step7 Back Wall Assembly 1 Hardware Wood Parts 1x 1B(Back Base) 4x BB(Wood Screw) 1x 2(Left Post) 4x CC(Wood Screw) 2x EE(Wood Screw) 1x A(Front/Back Wall Panel) 1x 11A(Back Post) - Page 17 Step8 Back Wall Assembly 2 Wood Parts Hardware 1x B(Back Middle Wall Panel) 2x BB(Wood Screw) 1x 11A(Back Post) 4x CC(Wood Screw)
- Page 18 Step9 Back Wall Assembly 3 Wood Parts Hardware 2x BB(Wood Screw) 1x 2(Right Post) 2x CC(Wood Screw) 1x A(Front/Back Wall Panel) 2x EE(Wood Screw)
- Page 19 Step10 Back Wall Assembly 4 Wood Parts Hardware 1x 10(Back Wall Sill) 6x BB(Wood Screw) Guide Spacer NOTE: Guide spacers are placed in the grooves of the posts, door- posts, and front wall sill to align the posts, and then removed when the posts are correctly aligned.
- Page 20 Step11 Back Wall Assembly 5 Polycarbonate Board Hardware Wood Parts 1x D 4x DD(Wood Screw) 1x 8(Gable Beam) 1x D1 1x F...
- Page 21 Step12 Back Wall Assembly 6 Polycarbonate Board Hardware Wood Parts 1x 19(Roof Brace) 1x E 2x DD(Wood Screw) 1x E1 Guide Spacer...
- Page 22 Step13 Back Wall Assembly 7 Hardware Wood Parts 1x 6(Left Roof Rafter) 3x JJ(Wood Screw) 2x BB(Wood Screw) 1x 7(Right Roof Rafter) 4x CC(Wood Screw) 1x 9(Peak Spacer) 1.77in (4.5cm)
-
Page 23: Step14 Side Wall Assembly
Step14 Side Wall Assembly 1 Hardware Wood Parts 4x BB(Wood Screw) 2x 12(Left Side Base) 2x 13(Right Side Base) 8x JJ(Wood Screw) 2x 14(Side Post) 2x C(Side Wall Panle) Repeat 2 times... - Page 24 Step15 Side Wall Assembly 2 Hardware Wood Parts 4x 14(Side Post) 8x BB(Wood Screw) 2x C(Side Wall Panle) Repeat 2 times...
- Page 25 Step16 Side Wall Assembly 3 Hardware Wood Parts 4x C(Side Wall Panle) 16x CC(Wood Screw) Repeat 2 times Note: The tongue of the side panels overhangs from the side base.
- Page 26 Step17 Connect Wall Assembly 1 Hardware 4x EE(Wood Screw) Back Wall Side Wall Side Wall Back Wall Side Wall Groove on Post...
- Page 27 Step18 Connect Wall Assembly 2 Hardware 4x EE(Wood Screw) Back Wall Side Wall Front Wall Side Wall Front Wall Side Wall Groove on Post...
- Page 28 Step19 Connect Wall Assembly 3 9.59’ （2.925M） NOTE：Make sure the assembly is square and the diagonal distance from the inside of one post to the inside of the opposite postis is 9.59'(2.925 m).
- Page 29 Step20 Attach Corner Brackets Hardware 24x AA(Wood Screw) 4x 29(Corner Bracket) Repeat 4 times...
- Page 30 Step21 Attach Side Wall Sills Hardware Wood Parts 2x15(Left Side Wall Sill) 16x BB(Wood Screw) 2x16(Right Side Wall Sill) Guide Spacer...
- Page 31 Step22 Attach Side Wall Top Hardware Wood Parts 2x17(Left Side Wall Top) 8x FF(Bolt) 16x PP(Washer) 2x18(Right Side Wall Top) 8x HH(Nut) 10x BB(Wood Screw) Repeat 2 times...
- Page 32 Step23 Side Wall Panel Assembly 1 Polycarbonate Board 8x G...
- Page 33 Step24 Side Wall Panel Assembly 2 Hardware 24x AA(Wood Screw)
- Page 34 Step25 Roof Peak Assembly Hardware Wood Parts 4x GG(Bolt) 1x 20A(Left Roof Peak) 8x PP(Washer) 1x 20B(Right Roof Peak) 4x HH(Nut) 4x EE(Wood Screw)
- Page 35 Step26 Roof Rafter Assembly Hardware Wood Parts 6x BB(Wood Screw) 4x 22(Middle Roof Rafter) 6x DD(Wood Screw) 2x 23(Window Roof Rafter) Guide Spacer...
-
Page 36: Step27 Window Assembly
Step27 Window Assembly 1 Hardware Wood Parts 6x BB(Wood Screw) 2x 24(Side Vent Block) 4x CC(Wood Screw) 1x 25(Bottom Vent Block) - Page 37 Step28 Window Assembly 2 Polycarbonate Board Hardware Wood Parts 1x 26-1(Window-1) 1x J 8x OO(Wood Screw) 1x 26-2(Window-2) 4x JJ(Wood Screw) 1x 26-3(Window-3) 1x KK(Window Long 1x 26-4(Window-4) Hinge With Screw) 1x 26-5(Window-5) 26-1 26-3 26-2 Front 26-4 26-1 Back 26-3 26-2 26-5...
- Page 38 Step29 Window Assembly 3 Hardware 1x KK(Window Long Hinge With Screw) 1x NN(Window Support) 4x OO(Wood Screw)
-
Page 39: Step30 Roof Panel
Step30 Roof Panel Assembly 1 Polycarbonate Board 7x H 1x I... - Page 40 Step31 Roof Panel Assembly 2 Hardware 24x AA(Wood Screw)
- Page 41 Step32 Attach Roof Brackets Hardware Wood Parts 2x 30(Door Block) 18x AA(Wood Screw) 4x BB(Wood Screw) 3x 28(Roof Bracket)
-
Page 42: Step33 Door Assembly
Step33 Door Assembly 1 Wood Parts Hardware 1x 27-1(Door-1) 4x BB(Wood Screw) 1x 27-2(Door-2) 1x 27-5(Door-5) 1x 27-6(Door-6) 27-5 27-1 27-1 27-6 27-6 27-2 27-2... - Page 43 Step34 Door Assembly 2 Hardware Wood Parts Polycarbonate Board 1x 27-3(Door-3) 6x BB(Wood Screw) 1x K 1x 27-4(Door-4) 27-3 27-5 27-1 Guide Spacer 27-4...
- Page 44 Step35 Door Assembly 3 Hardware 2x LL(Door Hinge With Screw) 10” (25.4cm) 27-5 27-1 10” (25.4cm) 27-1 10” (25.4cm)
- Page 45 Step36 Door Assembly 4 Guide Spacer Guide Spacer...
-
Page 46: Step37 Door Handle Assembly
Step37 Door Handle Assembly Hardware 1x MM(Door Handle With Screw) 27-5... - Page 47 Step38 Apply Sealant NOTE: Seal the panels of four walls and roof on the inside and outside with silicone sealant as shown.
- Page 48 Enjoy your product !
Need help?
Do you have a question about the PG0101-18 and is the answer not in the manual?
Questions and answers
Do the polycarbonate panels have a right side out?
Yes, the VEIKOUS PG0101-18 polycarbonate panels have a right side out. The manual specifies that the UV-protected side should face outward and is covered with a white plastic film, which should be removed before installation.
This answer is automatically generated
@Sara Smith Schob
@Mr. Anderson It is not in our Manuel
@Mr. Anderson it does say it
Can you leave the film on the polycarbonate panels on the roof to help block some sun in the summer?
No, the plastic film on both sides of the polycarbonate panels must be removed before inserting them. The UV-protected side should face out.
This answer is automatically generated
@Sara Smith Schob
@Mr. Anderson once you’ve removed the plastic, is there anyway to tell which is the UV side?
Any way to tell which side is which once u remove the protective liner?
@Sara Smith Schob
The manual does not provide specific instructions on identifying the correct sides of the VEIKOUS PG0101-18 after removing the protective liner. However, a general approach is to check for features such as grooves, pre-drilled holes, or overhanging tongues on the side panels, as mentioned in the side wall assembly steps. Additionally, referring to the illustrations in the manual and ensuring alignment with the base and posts can help confirm the correct orientation.
This answer is automatically generated
I purchased a Veikous 6x8 cedar greenhouse from Home Depot. I received 4 boxes. Where do I find the directions?
The assembly directions for the VEIKOUS PG0101-18 6x8 cedar greenhouse are contained in the VEIKOUS manual titled "PG0101-18 VEIKOUS Manual."
This answer is automatically generated
I need the model number of the Veikous Aluminum Greenhouse, The assembly manual does not have the number in it.
The model number of the VEIKOUS Aluminum Greenhouse is PG0101-18.
This answer is automatically generated
How are the materials packed? It says it comes in 3 boxes. What is packed in each box?
The VEIKOUS PG0101-18 package contains wood parts, polycarbonate boards, and hardware, including wood screws, roof brackets, door blocks, door hinges with screws, and a door handle. It is advised to check the packing material for small parts that may have fallen out during shipment.
This answer is automatically generated
We purchased the 8x14 cedar greenhouse Still waiting on one box Could you tell me the dimensions we are going to put in a treated 6x6 base? Is there a set of written instructions snd if there is in which box?
The VEIKOUS PG0101-18 greenhouse has a dimension of 9.59 feet (2.925 meters) for the diagonal distance from the inside of one post to the inside of the opposite post. There is a set of written instructions included in the boxes, as the manual contains information on assembly preparation, installation procedures, and required maintenance.
This answer is automatically generated
I wood like a written manual of the 6' by 10' wooden Veikous 191-19 c1 through c4 Greenhouse
If some panels were put in with the UV side on the inside, what will happen?
If some panels were put in with the UV side on the inside, what will happen?
