HB734G1B1 o cerca il tuo prodotto tra le migliori offerte di Forni Oven HB734G1.1 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
en Safety Table of contents 1 Safety Observe the following safety instructions. 1.1 General information INFORMATION FOR USE ¡ Read this instruction manual carefully. Safety .............. 2 ¡ Keep the instruction manual and the Preventing material damage ....... 4 product information safe for future refer- ence or for the next owner.
Safety en 1.4 Safe use WARNING ‒ Risk of scalding! Always place accessories in the cooking com- The accessible parts of the appliance become partment the right way round. hot during operation. → "Accessories", Page 9 ▶ Never touch these hot parts. ▶ Keep children at a safe distance. WARNING ‒ Risk of fire! Hot steam may escape when you open the Combustible objects that are left in the cook-...
Page 4
en Preventing material damage WARNING ‒ Risk of electric shock! WARNING ‒ Risk of suffocation! Incorrect repairs are dangerous. Children may put packaging material over ▶ Repairs to the appliance should only be their heads or wrap themselves up in it and suffocate. carried out by trained specialist staff. ▶...
Environmental protection and saving energy en Leaving the appliance to cool down with the door open Using oven cleaner in a hot cooking compartment will damage the front of neighbouring kitchen units over damages the enamel. time. Never use oven cleaner in the cooking compartment ▶...
Page 6
en Familiarising yourself with your appliance 4 Familiarising yourself with your appliance 4.1 Control panel Symbol Meaning WiFi signal strength for Home Connect. You can use the control panel to configure all functions The more lines of the symbol are filled, of your appliance and to obtain information about the the better the signal.
Page 7
Operating modes en If the self-cleaning surfaces no longer clean themselves 4.4 Cooking compartment adequately during operation, heat up the cooking com- Various functions in the cooking compartment provide partment specifically to the right temperature. support when operating your appliance. → "Regenerating self-cleaning surfaces in the cooking compartment", Page 19 Shelf supports The shelf supports in the cooking compartment enable...
Page 8
en Operating modes Symbol Type of heating Temperature What it's used for and how it works range Possible additional functions 3D hot air 30 - 275 °C Bake or roast on one or more levels. The fan distributes the heat from the ring-shaped heating element in the back wall evenly around the cooking compartment.
Accessories en 6 Accessories Use original accessories. These have been made espe- The accessories supplied may differ depending on the cially for your appliance. appliance model. Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the ac- cessory cools down, it will regain its original shape.
You will find a comprehensive range of products for Wire rack your appliance in our brochures and online: on univer- siemens-home.bsh-group.com sal pan Accessories vary from one appliance to another. When purchasing accessories, always quote the exact product number (E no.) of your appliance.
Page 11
Basic operation en Change the temperature using or or directly via 8.4 Interrupting the operation the adjustment bar. You can interrupt the operation and then continue Press "Apply". again. To interrupt the operation, press . 8.7 Displaying information Press ...
en Rapid heating 9 Rapid heating To save time, rapid heating can shorten the preheat- Set a suitable type of heating and a temperature of ing time for set temperatures over 100 °C. at least 100 °C. Rapid heating is possible for the following types of Rapid heating automatically switches off as of a set heating: temperature of 200 °C.
Page 13
Dishes en To set the timer, press the relevant time value on a When the time has elapsed, a signal sounds. A the display, e.g. hour display "h" or minute display message appears on the display confirming that the "min". operation has finished. Once the cooking time has elapsed: a The selected value is marked in blue.
en Favourites ¡ Roast fish, whole 11.3 Overview of the dishes ¡ Pizza, frozen, with deep-pan base, x 1 You can see which individual dishes are available to ¡ Pizza, frozen, with thin base, x 1 you here. The dishes depend on the features of your ¡...
Childproof lock en To change the favourites, you must use the 12.3 Changing favourites ▶ Home Connect app. If your appliance is connected, You can change, sort or delete your saved favourites at follow the instructions in the app. any time. 13 Childproof lock You can secure your appliance to prevent children a The control panel is locked.
en Home Connect Press the required basic setting. Factory set- Selection Press to select the required basic setting. tings a The change is applied directly for most basic set- Factory set- ¡ Restore tings. tings To change additional basic settings, use to go Appliance in- Appliance information back and select a different basic setting.
Page 17
Home Connect en Basic setting Possible settings Explanation Wi-Fi You can use the Wi-Fi to switch off the network connection for your appliance. When you have connected successfully once, you can deactivate the Wi-Fi and not lose your detailed data. As soon as you activate Wi-Fi again, the appliance connects automatically.
en Cleaning and servicing Note: Please note that the Home Connect functions can only be utilised with the Home Connect app. In- formation on data protection can be retrieved in the Home Connect app. 16 Cleaning and servicing Do not use hard scouring pads or cleaning To keep your appliance working efficiently for a long ▶...
Page 19
Cleaning and servicing en Cooking compartment Area Suitable cleaning agents Information Enamel surfaces ¡ Hot soapy water Soak any heavily soiled areas and use a brush or steel wool. Leave the appliance door open to dry the cooking compartment ¡ Vinegar water after cleaning it.
Page 20
en Cleaning aid "humidClean" rust. The stains are not hazardous to health. These Attach the shelf supports. marks do not impair the cleaning ability of the self- → "Rails", Page 23 cleaning surfaces. 17 Cleaning aid "humidClean" The cleaning aid "humidClean" is a quick alternative Confirm the notification.
Page 21
Appliance door en 19 Appliance door To clean the appliance door thoroughly, you can disas- Close the appliance door fully . Grab hold of the semble the appliance door. appliance door with both hands (on the left and right) and pull it upwards and out . 19.1 Detaching the appliance door WARNING ‒ Risk of injury! Components inside the appliance door may have sharp...
Page 22
en Appliance door Open the appliance door fully. If necessary, you can remove the condensate Open the locking levers on the left- and right-hand trough for cleaning. hinges . Open the appliance door. ‒ a The locking levers are open. The hinges are now se- Tilt the condensate trough upwards and remove ‒...
Page 23
Rails en Slide the intermediate pane into the left- and right- Push the inner pane upwards until it is in the left- hand retainers . and right-hand retainers . Push the intermediate pane upwards until it is in the Put the door cover into position ...
en Troubleshooting Pull the whole rail to the front and remove it. ¡ For both rails, ensure that the curved rods are at the front. First, push the rail into the middle of the rear socket until the rail rests against the cooking compartment wall, and then push this back ...
Page 25
Next time, set lower or higher values. ▶ Tip: A lot of other information about the food preparation and corresponding adjustment values can be found in the Home Connect app or on our website siemens-home.bsh- group.com . 21.2 Replacing the oven light bulb WARNING ‒ Risk of electric shock!
en Disposal Pull out the halogen bulb without turning it . Insert the new halogen lamp and press it firmly into the socket. Make sure the pins are positioned correctly. Depending on the appliance model, the glass cover may have a sealing ring. Put the sealing ring in posi- tion.
A detailed Declaration of Conformity can be found on- A detailed RED Declaration of Conformity can be found line at siemens-home.bsh-group.com/uk/ among the online at siemens-home.bsh-group.com among the ad- additional documents on the product page for your ditional documents on the product page for your appli- appliance.
Page 28
en How it works Shelf positions ¡ Follow the manufacturer's instructions for your roast- ing dishes. Baking on one level Height Roasting in uncovered cookware Tall baked items and tins/dishes on ¡ Use a deep roasting dish. the wire rack ¡ If you do not have any suitable cookware, you can Shallow baked items/baking tray use the universal pan.
Page 29
How it works en ¡ Distribute foods that are in the form of separate ¡ Follow the manufacturer's instructions on the pack- pieces, such as bread rolls and potato products, so aging. that they are spread out flat and evenly on the ac- cessory.
Page 30
en How it works Food Accessory/cookware Shelf pos- Type of Temperature in Cooking time in ition heating °C/grill setting mins → Page 7 Pizza, fresh, thin-crust, on a pizza Pizza tray 250-270 8-13 tray Quiche Dark coated quiche 190-210 25-35 Tarte flambée Universal pan...
Page 31
How it works en Immediately place the meat into the pre-warmed 26.6 Special cooking methods and other cookware in the cooking compartment. applications To ensure that the temperature in the cooking com- Information and recommended settings for special partment remains constant, keep the cooking com- cooking methods and other applications, e.g.
en Installation instructions Recommended settings for baking Food Accessory/cookware Shelf pos- Type of Temperature in Cooking time in ition heating °C mins → Page 7 Shortbread Baking tray 140-150 25-35 Shortbread Baking tray 140-150 20-30 Shortbread, 2 levels Universal pan ...
Page 33
Installation instructions en and comply with the applicable national ¡ Check the appliance for damage after un- safety requirements. packing it. Do not connect the appliance if ▶ If the power cord is too short, contact cus- it has been damaged in transit. tomer service.
Page 34
en Installation instructions 27.4 Installation underneath a hob If the appliance is installed under a hob, the following The minimum worktop thickness a is based on the minimum dimensions must be adhered to (including required minimum clearance . substructure, if applicable).
Page 35
Installation instructions en ¡ Ensure that air exchange is guaranteed in accord- ¡ Contact protection must be guaranteed by the in- ance with the diagram. stallation. ¡ If the display on the appliance remains dark, it has not been connected correctly. Disconnect the appli- ance from the mains and check the connection.
Page 36
en Installation instructions Screw the appliance into place. For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece in order to cover ‒ any sharp edges and to guarantee a safe install- ation. Pre-drill aluminium profiles to establish a screw ‒...
Page 40
Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001646755* 9001646755 (020908)
