Summary of Contents for Cygnus electronics S7024
- Page 1 24 Ports Full Gigabit Managed Modular Ethernet Switch User Manual S7024...
- Page 2 Preface The user manual mainly introduces the product shape, product positioning, hardware installation, Web management and other related information. Illustration (1)Format of Graphics Interface Format Description < > “<>”means button name， such as “click <Confirm> button”. “[ ]”means window name, menu name and data table, such as“pop out [New user] window”.
-
Page 3: Table Of Contents
Content 1 Product Introduction 3.3.8 Quit Overview Management 4 Web Product Feature 4.1 System Status Board Diagram 4.2 Port Configuration Specification 4.2.1 Port Settings Installation 4.2.2 Port speed limited Shipping List 4.3 VLAN Setting Installation Precautions 4.3.1 VLAN Configuration 2.2.1 Safety Precautions 4.3.2 4.3.2... -
Page 4: Product Introduction
1 Product Introduction 1.3 Board Diagram 1.1 Overview Board diagram of 24 ports full Gigabit managed modular Ethernet switch 24 ports full Gigabit managed modular Ethernet switch, which provide 24* Front panel Recover IP address Gigabit downlink Ethernet ports or optical fiber ports, 2* Gigabit uplink optical password and VLAN ID fiber ports and 2* Gigabit uplink Ethernet ports. -
Page 5: Specification
1.4 Specification 2 Installation 24 Ports Full Gigabit Managed Modular Ethernet Item Switch Caution Power Supply Mains on load Power Voltage Range AC 100～240V Anti-counterfeiting label is attached to switch's cover. Product damage Consumption 2X60W caused by unauthorized disassembly is not covered under warranty. 1～24 ports: 10/ 100/ 1000Mbps Ethernet ports or 100/ 1000Mbps SFP ports 2.1 Package List... -
Page 6: Installation Requirements
2.3 Installation Way Pull out the power plug before cleaning the switch. Do not use wet cloth nor liquid to wipe or wash the switch; There are 3 installation ways: rack, workbench and wall-hung installation. Do not leave the switch close to water or wet place so as to prevent water or dampness from entering into the switch;... -
Page 7: Workbench Installation
Figure 2-3 Hangers installation diagram (2) Drill holes on the strong position of wall and then drive the rubber plug into the hole; (3) Drive these screws into the hole for the rack and fix the product by aiming at the rubber plug . -
Page 8: Cable Connection
(5) Tighten screws towards right, the modules is fixed well. Blank baffle Figure 2-8 How to install the module-2 (1) unsrew towards the left; 2.4 Cable Connection Figure 2-5 How to remove the baffle-1 2.4.1 Device Connection U s e c r o s s n e t w o r k c a b l e o r c r o s s - o v e r c a b l e t o c o n n e c t P C o r other device with switch's Ethernet port;... -
Page 9: Power Cable Connection
3 Function Configuration Guide 2.4.3 Power cable Connection 3.1 Computer Requirements (1 Connect one side of switch’s power cable with the switch's AC power port, and connect the another side with external AC power socket; Make sure the management PC has already been installed with Ethernet adapter; (2)Turn on the power , check if switch's AC power LED is on, that means Use network cable connect Ethernet ports with network card of PC(Except the... -
Page 10: Confirm The Network Connection By Ping Command
3.2.2 Confirm the Network Connection by Ping Command Click <property> button, enter "local connection property" window. Operation Steps below: (1) Click <Start> button to enter [Start] menu, select [Run], pop out the dialog. (2) Input "ping 192.168.1.200", click <confirm> button. If there is equipment response show in the pop out dialog, that means network connection succeed, otherwise please check if the network... -
Page 11: Web Page Configuration Guide
(2) Select “connection” tabs in [Internet Caution option] window, and click [LAN Setting] button. Please follow the steps to check if the switch is installed correctly: (1) Whether the physical connection of the equipment is correct? Use network cable to connect the product’s Ethernet port(except the console port) with managed computer network card, and ensure the link LED of the port is on. -
Page 12: Common Buttons Introduction
Table 3-2 Default Configuration Options Default Configuration Web English language switching page diagram Username / password admin/admin 3.3.3 Common Buttons Introduction IP Address：192.168.1.200 System IP Address Subnet Mask：255.255.255.0 Table 3-1 Web commonly used function buttons introduction MAC address table aging 300 Seconds time Button... -
Page 13: Web Users Timeout
4 Web Management 3.3.5 Web User Timeout When you have left the Web setting page for a while, the system will log out and 4.1 System Status return to the Web dialog box due to system time-out. Please log in again if you want to proceed the operation. -
Page 14: Port Configuration
4.2 Port Configuration Specification Description Display the data forwarding of the port. If a port is off, you Port Enable / 4.2.1 Port setting Disable can not forward the data. Enabled by default. Display the port configuration’s speed rate, including 10M, 16 port switch panel silkscreen port and Web port corresponding table 100M, 1000M, auto-negotiation. -
Page 15: Port Speed Limited
4.3 VLAN Setting 4.2.2 Port speed limit The Equipment provides port-based entry speed limit. Users can restrict Switch supports two VLAN modes: every port traffic flows or cancel port flow restrictions . Users can choose a (1) Port-based VLAN mode: define VLAN members according to device port. fixed rate, the range is:downlink ports 1～1000Mbps, uplink port 1～... -
Page 16: Vlan Forwarding
Configuration Guide： Caution Such as if port 1-10 has connected to a switch respectively, it is necessary to divided port 1-10 into VLAN 20. The default port VLAN and allowed VLAN must be existed VLAN. Enter 1-10 within the port range(or click on the box in front of the ports); Choose Trunk on the menu(Switches connection is generally used with 4.3.2 VLAN Forwarding Trunk mode);... -
Page 17: Rstp
4.4.2 RSTP 4.4.2.1 RSTP Uses STP ( Spanning Tree Protocol) is established in accordance with IEEE 802. 1D standard. It is developed for the elimination of the data link layer loops in the LAN protocol. Devices running this protocol exchange packets with each other to find loops in the network, and choose to block some certain ports. - Page 18 Table 4-7 Designated port status Classification Designated Bridge Designated Port Equipment connecting directly Port used by with switch and responsible to designated bridge to For equipment transfer BPDU message to transfer BPDU switch message to switch Port used by Responsible to transfer designated bridge to Figure 4-6 RSTP For LAN...
-
Page 19: Port Security
Configuration guide： Parameters Description Enable RSTP function to avoid broadcast storm caused by looped network Static MAC address differs from the general dynamic MAC structure among switch A ,switch B and switch C 1-10 port. address. Once a static address is added, the address will MAC Address remain in effect until be deleted and free the maximum aging Enable switch A, B, C RSTP function;... -
Page 20: Web Management
In [port security / 802.1X authentication] page, you can modify / 802.1X Configuration Guide ： authentication function set, as shown in figure 4-8: EX: Setting port 1-10 to compulsory licensing model, the maximum number of users to 10. Start using 802.1x Certification； Ports Scope choose1-10，... -
Page 21: Email Alarm
Figure 4-10 Email alarm The meanings of main parameters of the pages are as below table. Table 4-12 Parameters description Figure 4-9 SNMP Schematic configuration Parameters Description The meaning of main parameters of the pages are as below. The host computer’s IP address or the host computer that Mail Server Table 4-11 Parameter description provide POP3 mail delivery service to our devices. -
Page 22: Port Mirror
Configuration Guidance: Caution Such as port 3 monitor port 2 Import data traffic Some email service system requires that the " email reply address" Open Port Mirror; should match the" email account”; when sending system test email, the Input3 on monitor port, input 2 on mirror Port, Data collection selected from password should be in plain text. -
Page 23: Network Statistics
Parameter Description Parameters Description IGMP Snooping Opening and Closing Multicast Snooping function ,Default The received address is the number of packets in Receive Frame singlecast On/Off is Close. Package the unicast address. IGMP Inquiry Open IGMP Multicast Inquiry function The received address is the number of packets in Receive Frame multicast Packeage the multicast address. -
Page 24: System Management
The main parameter description are shown as the table. 4.8.2 User Management Table 4-16 Main parameter On this page, you could modify or add one user with password . as figure 4-16. Parameter Description Inquiry by physical Enter detailed physical MAC address to check. port Inquiry by MAC MAC address type consists of static MAC address and... -
Page 25: Log Information
4.8.3 Log Information 4.8.4 File Management On [ System management/ File management] page，You could check The log function allows users to access system operation, When this function is configure document, software upgrade, restore factory setting and reboot enabled, corresponding events are recorded to the log: system as shown in the figure 4-18. -
Page 26: Poe Management
4.9 PoE Management Parameter Description Power Determined by built-in power supply module and can not On PoE management page, you could turn on/off PoE function, set input provided exceed maximum power supply. power , maximum overload, reservation power etc, as shown in figure 4-19. Built- in power supply allows overload rate. -
Page 27: Qos Management
4.10 QoS Management 4.10.2 DSCP/TOS QoS [QoS Setting/ DSCP/TOS QoS] Interface，can modify the setting [DSCP/TOS 4.10.1 QoS setting QoS]，figure 4- 21 On the QoS management/QoS Settings page, you can modify / 802.1 P QoS function setting, as shown in figure 4-20. Figure 4 - 20 802.1P QoS Figure 4 - 21 DSCP / TOS QoS The meaning of parameters in the page is shown in the following table. - Page 28 Environ me nt p r ot e cti o n This product design is environmental friendly and the product should be stored, used and dicarded in accordance with relevant national legal / regulatory requirements.
