Summary of Contents for DEPOT 2 U 99024
- Page 1 (3.6 2 .9 m) ENER L PURP SE SHE ER INSTRUCTION MANUAL odel No.: 99024 Tools required for assembly (not included)
-
Page 2: Intended Use
INTENDED USE The product is designed to provide protection against sun, moderate rain or snowfall, sap, bird/ animal droppings and similar. RE AND MAINTENANCE Do not use strong cleaning materials or bleach, as these can damage the canvas. Clean using ®... - Page 3 Lower support �{ Corner foot piece � Stay I) • Stay with male connec- I ,, . l tion Diagonal stay (part 1) �§) Diagonal stay (part 2) � Connector piece Footplate Tensioner -�" "J/ Cotter © -� Nut M8 Washer M8 Screw M8 x 95 \.
-
Page 4: Step 2: Assembling The Frame
Wire 30 cm · .. -. ••• , ._ •• _ ' v .. •. · ..-·- ·• .. . ,_ ·. - --- - .: . ' . : · : :; · -c : · , ,,_ , -- . - Page 5 c. Place the end of the lower arch support into a footplate (12). Align the holes in the support with the holes in the base plate and insert the pin (14) through the holes. Lock the pin with the cotter (15) and split the cotter legs to secure it in place.
- Page 6 e. Repeat to assemble all arches and the other end wall (Fig. F). NOTE: The other diagonal stay is assembled the opposite way to the first. Fig. F 4. Fitting the roof stay. a. Affix the stay (7) to the underside of the end wall's upper strut using a connector (11), nut (16), washer (17) and screw (18) (Fig.
- Page 7 STEP 3: FITTING THE CANVAS 1. Fitting the canvas to the front and rear end walls. Place the canvas with the zipped door on the desired end wall. The zip should be closed for fitting. The canvas for the rear end wall has no door.
- Page 8 a. Lay out the canvas on the ground next to the frame, with the inside (the side with the eyelets) downwards and the edges with the straps towards the front and rear walls b. Fix lines through the eyelets in each end of the canvas.
- Page 9 Check that the canvas is flat and evenly placed in all directions. Tighten the line securing the canvas. g. Tighten the strap again if needed. Do not pull too hard; this can damage the strap and/or fixing points. The product is now ready for use. Check regularly that the canvas and straps are correctly tightened and that all the frame components fit correctly.
