Aeotec AEOEZWA002 Manual

Aeotec
LED Bulb 6 Multi-Colour
SKU: AEOEZWA002
Quickstart
This is a secure Light Dimmer for Europe. To run this device please connect it to your mains power supply.
1. Ensure the led bulb has been excluded outside the network.
2. Triggered by OFF ->ON (between 0.5-2 seconds each time)3.LED solid yellow Color (0xFFFF00) during the pairing(Timeout is 10 seconds).
Failure: Blinks between 100% White and Red 0x0000FF color for 3 seconds (at a rate of 200ms per flash), Once 3 seconds have passed, the LED should
return to a Warm White LED at 100%
Success: Blinks between 100% White and Green 0x00FF00 color for 3 seconds (at a rate of 200ms per flash). Once 3 seconds have passed, the LED should
return to a Warm White LED at 100%.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not
in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-Wave
device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of
security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The bulb has the standard shape and appearance of an 800 lm bulb, it is dimmable from 5% to 100%, the light color is adjustable from 1800K to 6500K, and 16 million
colors. It can also be integrated into groups, scenes or schedules and is suitable for interior lighting: corridors, bedrooms, living rooms, etc.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this
by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use
the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
1. Assuming led bulb was added to controller and was power on.
2. RGBW bulb re-power 6 times (between 0.5-2 seconds each time).Note: ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON -> OFF -> ON
3. If the 6th power on, the led bulb change to Yellow color(into pairing process ), which means that the reset factory settings are successf.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Inclusion/Exclusion
