- Page 1 Spik Up P 8" passive 2-way ceiling speaker with transformer User’s manual V1.1 - 03/2020...
- Page 2 User’s manual - Spik Up P V1.1 03/2020...
- Page 3 SPIK UP P - USER MANUAL Page 1. Carton Contents 2. Technical Specifications 3. Dimensions 4. Connecting to a CS80DP-W loudspeaker 5. Operating mode selection (low impedance or 100V) 6. Mounting Method User’s manual - Spik Up P V1.1 03/2020...
- Page 4 1. Contenu du carton - 1 Spik Up P speaker - 1 user manual 2. Technical Specifications CS80T-W Ref. 2-way coaxial in-ceiling speaker Type / number of channels Power 40W (8 ohms) or 5 W / 10 W / 20 W / 40 W / 100 V Size of HP 1 woofer 8"...
- Page 5 4. Connection with a Dante™ PoE+ CS80DP-W It is possible to connect a passive Spik Up P speaker to the Euroblock output of the Dante™ PoE+ Spik Up speaker. In this case the 8 ohm operating mode must be selected, and both speakers will output the same audio signal.
- Page 6 6. Mounting Method - Drill a 240 mm diameter hole. - Connect the speaker cable. - Remove the grill. - Attach as shown below, then replace the grill. User’s manual - Spik Up P V1.1 03/2020...
- Page 7 User’s manual - Spik Up P V1.1 03/2020...
- Page 8 FRENETIK - 1 Allée d’Effiat - Le Parc de l’Événement - Bât. H 91160 Longjumeau - France +33 (0)1 69 10 50 81 frenetik.fr...
