CyberPower CP1500AVRLCD3 User Manual

CP1350/1500AVRLCD3
COAX
1
2
14
3
4 5 6
7
BOTTOM OF
ELECTRICAL
8
PRODUCT REGISTRATION
Thank you for purchasing a CyberPower product. Please take a few minutes to register your product at: cyberpowersystems.com/registration. Registration certifies your product's warranty,
confirms your ownership in the event of a product loss or theft and entitles you to free technical support. Register your product now to receive the benefits of CyberPower ownership.
IMPORTANT SAFETY WARNINGS (SAVE THESE INSTRUCTIONS)
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury to persons including the following. This
Manual Contains Important Instructions that should be followed during installation and
maintenance of the UPS and batteries.
CAUTION! To prevent the risk of fire or
CAUTION! To reduce the risk of fire,
electric shock, install in a temperature connect only to a circuit provided with
and humidity controlled indoor area free 20 amperes maximum branch circuit over
of conductive contaminants. (Please see current protection in accordance with the
specifications for acceptable temperature National Electric Code, ANSI/NFPA 70.
and humidity range).
DO NOT USE FOR MEDICAL OR LIFE
CAUTION! To reduce the risk of electric SUPPORT EQUIPMENT! CyberPower
shock, do not remove the cover except to Systems does not sell products for life
service the battery. Turn off and unplug the support or medical applications. DO NOT
unit before servicing the batteries. There use in any circumstance that would affect
are no user serviceable parts inside except the operation and safety of life support
for the battery. equipment, medical applications, or patient
care.
CAUTION! Hazardous live parts inside can
be energized by the battery even when the DO NOT USE WITH OR NEAR
AC input power is disconnected. AQUARIUMS! To reduce the risk of fire
or electric shock, do not use with or near
CAUTION! The UPS must be connected an aquarium. Condensation from the
to an AC power outlet with fuse or circuit aquarium can cause the unit to short out.
breaker protection. Do not plug into an
outlet that is not grounded. If you need to DO NOT USE THE UPS ON ANY
de-energize this equipment, turn off and TRANSPORTATION! To reduce the risk of
unplug the unit. fire or electric shock, do not use the unit
on any transportation such as airplanes
CAUTION! To avoid electric shock, turn off or ships. The effect of shock or vibration
the unit and unplug it from the AC power
caused during transit and the damp
source before servicing the battery. environment can cause the unit to short
out.
CAUTION! Not for use in a computer
room as defined in the Standard for the
Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75.
YOUR ULTIMATE ALLY IN POWER
USER MANUAL
FEATURES
1 . Power Switch
11
13
2 . Power On Indicator
3 . LCD module display
SERIAL
4 . Down/Display button
12
5 . Up/Mute button
6 . Enter/Setup button
7 . USB Charging Ports
8 . Battery and Surge Protected Outlets
9 . Full-Time Surge Protection Outlets
10
10 . Circuit Breaker
REFER TO
UNIT FOR 1 1 . USB Port to PC/DB9 Port
9
CAUTIONS
12 . Wiring Fault Indicator (red)
13 . Communication Protection Ports
14 . Coax/Cable/DSS Surge Protection
INSTALLING YOUR UPS SYSTEM
UNPACKING AUTOMATIC VOLTAGE REGULATOR
Inspect the UPS upon receipt. The CP1350/1500AVRLCD3 stabilizes
The box should contain the following: inconsistent utility power voltage to
(a) UPS nominal levels that are safe for equipment.
(b) User's manual Inconsistent incoming utility power may
(c) USB A+B type cable be damaging to important data files and
(d) Function Setup Guide hardware, but with Automatic Voltage
Regulation (AVR), damaging voltage
*PowerPanel® Personal software is levels are corrected to safe levels. AVR
available on our website. Please visit automatically increases low utility power
cyberpowersystems.com and go to the to a consistent and safe 110/120 volts.
Software Section for free download.
OVERVIEW
The CP1350/1500AVRLCD3 provides
complete power protection from utility
power that is not always consistent. The
CP1350/1500AVRLCD3 features 1500
Joules of surge protection. The unit
provides long lasting battery backup
during power outages with maintenance
free batteries. The CP1350/1500AVRLCD3
ensures consistent power to your computer DETERMINE THE POWER REQUIREMENTS
system and includes software that will OF YOUR EQUIPMENT
automatically save your open files and 1 . Ensure that the equipment plugged into
shutdown your computer system during a the outlet does not exceed the UPS's
rated capacity. If the rated capacity
utility power loss.
of the unit is exceeded, an overload
condition may occur and cause the UPS
to shut down or the circuit breaker to
trip.
2 . There are many factors that can
affect the amount of power that your
computer system will require. It is
suggested that the load placed on the
battery outlets not exceed 80% of the
unit's capacity.
Cyber Power Systems (USA), Inc.
INSTALLING YOUR UPS SYSTEM - Continued
HARDWARE INSTALLATION GUIDE 4 . Press the power switch to turn the unit
1 . Your new UPS may be used on. The Power On indicator light will
immediately upon receipt. However, illuminate and the unit will "beep". If an
after receiving a new UPS, to ensure overload is detected, an audible alarm
the battery's maximum charge capacity, will sound and the unit will emit one
it is recommended that you charge the long beep. To correct this, turn the
battery for at least 8 hours. Your UPS is UPS off and unplug at least one piece
equipped with an auto-charge feature. of equipment from the battery power
When the UPS is plugged into an AC supplied outlets. Make sure the circuit
outlet, the battery will automatically breaker is depressed and then turn the
charge whether the UPS is turned on or UPS on.
off. 5 . To maintain optimal battery charge,
Note: This UPS is designed with a leave the UPS plugged into an AC
safety feature to keep the system from outlet at all times.
being turned on during shipment. The 6 . To store the UPS for an extended
first time you turn the UPS on, you will period, cover it and store with the
need to have it connected to AC power battery fully charged. While in storage,
or it will not power up. recharge the battery every three
2 . With the UPS months to ensure battery life.
7 . Ensure the wall outlet and UPS are
unit turned off
and unplugged, located near the equipment being
connect your attached for proper accessibility.
computer, monitor,
and any other peripherals requiring
battery backup into the battery power
supplied outlets. DO NOT plug a
laser printer, paper shredder, copier,
space heater, vacuum, sump pump
or other large electrical devices into
the "Battery and Surge Protected
Outlets". The power demands of these
devices may overload and damage the
UPS.
3 . Plug the UPS into a 2 pole, 3 wire
grounded receptacle (wall outlet).
Make sure the wall branch outlet is
protected by a fuse or circuit breaker
and does not service equipment with
large electrical demands (e.g. air
conditioner, copier, etc.). The warranty
prohibits the use of extension cords,
outlet strips, and surge strips.
REPLACING THE BATTERY
Replacement of batteries located in an OPERATOR ACCESS AREA.
1 . When replacing batteries, replace with the same number of the following battery:
CyberPower / RB1290x2E
2 . CAUTION! Risk of Energy Hazard, 24 V, maximum 9 Ampere-hour battery. Before
replacing batteries, remove conductive jewelry such as chains, wrist watches, and rings.
High energy conducted through these materials could cause severe burns.
3 . CAUTION! Do not dispose of batteries in a fire. The batteries may explode.
4 . CAUTION! Do not open or mutilate batteries. Released material is harmful to the skin
and eyes. It may be toxic.
5 . CAUTION: A battery can present a risk of electrical shock and high short circuit current.
The following precautions should be observed when working on batteries:
1 ) Remove watches rings, or other metal objects.
2) Use tools with insulated handles.
CAUTION - RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO LOCAL REGULATIONS.
1 2 3
REMINDER: Batteries are considered HAZARDOUS WASTE and must be disposed of properly. Most retailers that sell lead-acid batteries collect used batteries for recycling, as required by
local regulations.
4241 12th Avenue East, Suite 400 | Shakopee, MN 55379 | CyberPowerSystems.com
BASIC OPERATION
1 . Power Switch: Used as the master on/ of your equipment during a power
off switch for equipment connected to failure. (DO NOT plug a laser printer,
the battery power supplied outlets. paper shredder, copier, space heater,
2 . Power On Indicator: This LED is vacuum, sump pump or other large
illuminated when the utility power electrical devices into the "Battery
is normal and the UPS outlets are and Surge Protected Outlets". The
providing power, free of surges and power demands of these devices may
spikes. overload and damage the unit.)
3 . LCD module display: The LCD 9 . Full-Time Surge Protection Outlets:
display shows all the UPS information The UPS has six surge suppression
using icons and messages. For outlets.
10 . Circuit Breaker: Located on the back
more information please review the
"Definitions for Illuminated LCD of the UPS, the circuit breaker serves to
Indicators" section. provide overload and fault protection.
4 . Down/Display button: The button 11. USB Port to PC: The USB port allows
can be used to select the LCD display connection and communication
between the USB port on the computer
contents including Input Voltage,
Output Voltage, and Estimated Run and the UPS unit.
Time. Short press the button to scroll DB9 Port: The DB9 port is used for
down the function menu. Pressing the connecting between the UPS and
button for 2 seconds will keep the equipment designed to operate with a
LCD display always on or turn the LCD dry contact closure.
display off while in AC/Utility power 12. Wiring Fault Indicator (red): This LED
mode. For more information about the indicator will illuminate to warn the
Down/Display Button, please refer to user that a wiring problem exists, such
the Function Setup Guide. as bad ground, missing ground or
5 . Up/Mute button: Short press the reversed wiring. If this is illuminated,
button to scroll up the function menu. disconnect all electrical equipment
Holding the button for more than 2 from the outlet and have an electrician
verify the outlet is properly wired. The
seconds will silence the alarm. For
PLUG IN
more information about the Up/Mute UPS will not provide surge protection
Button, please refer to the Function without being plugged into a grounded
Setup Guide. and properly wired wall outlet.
6 . Enter/Setup button: Press the button 13 . Communication Protection Ports
for 2 seconds to enter the setup menu (RJ45): Communication protection
and then select the functions for ports, bi-directional, will protect a
configuration. For more information 10/100/1000 Ethernet connection.
14 . Coax/Cable/DSS Surge Protection:
about the Enter/Setup Button, please
refer to the Function Setup Guide. The Coax/Cable/DSS protection ports
7 . USB Charging Ports: The USB will protect any cable modem, CATV
Charging ports provide 5Vdc,3A converter, or DSS receiver.
Max(USB-C), and 5 Vdc, 2.4A
Max(USB-A). Total Output Current:4A
8 . Battery and Surge Protected
Outlets: The UPS has six battery
powered/surge suppression outlets
for connected equipment to ensure
temporary uninterrupted operation
BATTERY REPLACEMENT PROCEDURE
1 . Switch off and unplug all the connected equipment.
2 . Switch off the UPS and disconnect it from the wall outlet.
3 . Place the product on its side, on a solid and stable surface.
4 . Loosen the battery compartment cover screws.
5 . Press on the locking latch and slide the battery compartment cover.
6 . Using the handles on both sides of the battery pack, lift the battery pack 30 degrees
upward to expose the battery connector. Connect the wires as shown above.
7 . Replace the new battery pack into the unit and connect the wires as above steps
8 . Align the side rails on the cover with the rails on the UPS and slide the cover till it locks
and screws in position.
9 . Recharge the UPS for 8-16 hours to fully charge the battery.
CONNECT BATTERY
(+) RED
(-) BLACK
4 5
K01-0000946-00
