RGT SIRBOT User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RGT Inc.
SIRBOT User Manual
Round Type SIRBOT User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIRBOT and is the answer not in the manual?

Questions and answers

Summary of Contents for RGT SIRBOT

  • Page 1 RGT Inc. SIRBOT User Manual Round Type SIRBOT User Manual...

  • Page 2: Table Of Contents

    Contents 3. How to Use 1. Product Serving Mode Product Composition Cruise Mode Product Specification Serving place Wait place 2. SIRBOT Setting Charge place Power on /off Charge Method Volume Screen Brightness Advanced Settings 4. Precautions Stop During Operation Precautions...

  • Page 3: Product

    Robot Global Team ■ Product 1.1 Product Composition Tray with Cup holder Enlarged image LCD Display Switch Terminal tray Charging Port Emergency Charging Switch Switch *STOP: Pressed Bus Tub *Working: Protruded Power Swtich *On : I , Off : O LiDAR sensor RGBD Camera...
  • Page 4 Robot Global Team ■ Product 1.1 Product Composition Tray with Cup holder LCD Display tray tray Bus tub Example 1 Example 2 Example 3...

  • Page 5: Product Specification

    Robot Global Team ■ Product 1.2 Product Specification Specifications Detail 440 x 440 x 1145 (mm) Size(diameter, height) about 50 kg Weight 1.2m/s Speed Use charging code (240v ac 3.5A) Charging Method 5hrs Charging Time 3days (full working time) Operating Time Tray Quantity/Size 3ea, 405mm...

  • Page 6: Sirbot Setting

    Robot Global Team ■ SIRBOT Setting 2.1 Power on Open switch terminal ② It takes about 1 minute to complete booting. ③ A standby screen appears and booting is complete. ① bottom back robot change the power switch to ‘I’.
  • Page 7 Robot Global Team ■ SIRBOT Setting 2.1 Power off ① Touch the + icon on the main screen. ② Touch the settings icon. ③ Touch the exit button. ④ After about 5 seconds after exiting from the user screen, change the power switch at the bottom of the back of the robot to ‘O’.

  • Page 8: Volume

    Robot Global Team ■ SIRBOT Setting 2.2 Volume Setting ① Touch the standby screen. ② Touch the + icon on the main screen. ③ Touch the settings icon. ④ Adjust the volume by adjusting the volume setting bar with the speaker icon.

  • Page 9: Screen Brightness

    Robot Global Team ■ SIRBOT Setting 2.3 Screen Brightness ① Touch the standby screen. ② Touch the + icon on the main screen. ③ Touch the settings icon. ④ Adjust the brightness by adjusting the brightness setting bar with the...

  • Page 10: Advanced Settings

    Robot Global Team ■ SIRBOT Setting 2.4 Advanced Settings - Detail Set. 2.4.1 Table window number/table mode change ① Touch the settings icon. ② Touch the Advanced settings icon. ③ On the Advanced Settings screen, check the ‘Use number pad’.
  • Page 11 Robot Global Team ■ SIRBOT Setting 2.4 Advanced Setting - Detail Set. 2.4.2 Automatic tray selection ① Check ‘Use tray auto-focus’. ② When entering the serving position, it is automatically entered from the top of the tray. 2.4.3 table sort ④...
  • Page 12 Robot Global Team ■ SIRBOT Setting 2.4 Advanced Setting - Drive Set. 2.4.4 Pause function setting ⓐ ⓑ ⓒ ⓐ When this part is activated, if you touch the screen while driving the robot, it will be paused. ⓑ When this part is activated, the ‘Skip’ function is activated on the pause screen.

  • Page 13: Stop During Operation

    Robot Global Team ■ SIRBOT Setting 2.5 Stop During Operation 2.5.1 Stop during operation ⓐ ⓑ ① When the robot is moving, if you ②-ⓐ . When the 'Skip' icon is touched in the stopped ③ If you touch the screen again in the paused state, it will drive...

  • Page 14: Reset Location

    Robot Global Team ■ SIRBOT Setting 2.6 Reset Location 2.6.1 Reset from current location ⓐ ① Touch the setting icon. ② Touch the initial position setting icon. ③ Check the robot's current location, and if the location is different, specify it directly on the map. The red circle (ⓐ) is the current position recognized by the robot.
  • Page 15 Robot Global Team ■ SIRBOT Setting 2.6 Reset Location 2.6.1 Reset from current location ⑦ Touch the Return button.
  • Page 16 Robot Global Team ■ SIRBOT Setting 2.6 Reset Location 2.6.2 Reset after moving to initial position ① While pressing the emergency stop button, move it to ② Release the emergency stop button in the emergency ③ Touch the cancel button.
  • Page 17 Robot Global Team ■ SIRBOT Setting 2.6 Reset Location 2.6.2 Reset after moving to initial position ⑦ Touch the restart button. ⑧ It will reboot. When rebooting, the current location is set to the initial location.

  • Page 18: How To Use

    Robot Global Team ■ How to use 3.1 Serving Mode 3.1.1 How to use serving mode ① Touch the standby screen. ② Touch the main screen. ③ Touch the tray you want to serve. ③ Please select the table number you want to serve. You can also enter the same table number in another tray.
  • Page 19 Robot Global Team ■ How to use 3.1 Serving Mode Table Favorites 3.1.2 ① Touch and hold the table you want to Favorites for 3 ② When you click a table that needs setting as a favorite, ③ When you have finished setting your favorites, at the bottom seconds.

  • Page 20: Cruise Mode

    Robot Global Team ■ How to use 3.2 Cruise Mode ① Touch the move button in the upper left corner of the ② When the menu icon is displayed, ③ The word ‘cruise mode’ is displayed serving mode. touch the cruise mode icon. in the upper right corner and the cruise mode starts at the designated location.

  • Page 21: Serving Place

    Robot Global Team ■ How to use 3.3 Serving place ① Touch the move button in the upper left corner of the ② When the menu icon is displayed, ③ The word ‘moving to Serving place’ is displayed in the serving mode.

  • Page 22: Wait Place

    Robot Global Team ■ How to use 3.4 Wait place ① Touch the move button in the upper left corner of the ② When the menu icon is displayed, ③ In the upper right corner, ‘Moving to Wait place’ is serving mode.

  • Page 23: Charge Place

    Robot Global Team ■ How to use 3.5 Charge place ① Touch the move button in the upper left corner of the ② When the menu icon is displayed, ③ In the upper right corner, ‘Moving to Charging place’ is serving mode.

  • Page 24: Charge Method

    Robot Global Team ■ How to use 3.6 Charge Method ① Touch the + icon on the main screen. ② Touch the setting icon. ③ Touch the Power button. ④ Change the power switch at the ⑤ After the power is completely turned off, plug the cord into the charging terminal and switch the charging bottom of the back of the robot to the ‘O’...

  • Page 25: Precautions

    Robot Global Team ■ Precautions 4.1 Precautions ※ If you do not follow the following precautions, it may cause product failure or shortening of life, so please read and follow them. When charging, change the robot power to OFF. It may cause malfunction. When powering on the robot, the emergency power switch behind the robot must not be pressed.

  • Page 26: Faq

    Robot Global Team ■ Precautions 4.1 Precautions FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 27 Robot Global Team ■ Precautions 4.2 Frequently Asked Question & Answer Q. Power does not turn on. A. The robot may be discharged. Charge it and turn it on again. Q. The robot does not drive. A. ① Check for obstacles blocking or narrowing the path the robot is moving, and keep them out of the way. ②...
