- Page 1 Porodo Portable MiFi 3G/4G Router CAT4 V2 without Display SKU: PD-PT4GRWD...
-
Page 2: Table Of Contents
Table of Contents Overview Features Schematic View Specifications LED Indicators Compatibility Sleep Mode Installation Instructions Internet Connection Managing the Web UI Page Web UI Introduction Precautions Warranty Contact Us... -
Page 3: Overview
Overview This device is a portable 4G WiFi Router that enables multiple end users and mobile devices to share a 3G or 4G mobile broadband Internet connection, creating a personal network. It supports FDD-LTE, TDD-LTE, TD-SCDMA, and WCDMA networks. Users can access the internet via WiFi or a USB connection. This manual introduces the installation and usage of this equipment. -
Page 4: Specifications
Item Description To power on/off: Long press the power button for 3 seconds. 1. Power Button To awaken from sleep mode: Simply click the device. Display AP Information: Press the WPS button for 3 seconds to initiate WPS (PBC). Double-click to reveal the SSID and KEY information of 2. - Page 5 Detailed: Item Value Model PD-PT4GRWD Product Type MIFI Size 105×63×15.7mm Basic Info LED/LCD Battery 2100mAh Power Supply USB/Battery 5V/1A ZX297520 V3 WiFi /Bluetooth Chip AIC8800DW SIM Card Slot NANO / MICRO SIM Flash 512M Baseband T-Card Type C Wi-Fi Users...
-
Page 6: Led Indicators
OPEN/WPA2 （ AES) -PSK/WPA - PSK/WPA2 WiFi Supported Security -PSK/WPA3/WPA3/WPA2 Support Button Power Support Reset Support -10 ~60° C Working temperature Working -30 ~ 80° C Storage temperature Environment 5 % ~ 59 % （No condensation) Humidity LED Indicators The LED display configuration upon powering on should be as follows: LED Indicator Instruction Red flashing: Power is below 20 %. -
Page 7: Sleep Mode
Sleep Mode When the equipment is in WAN and battery mode, and no devices are connected to WiFi for a certain period, the device will enter sleep mode. Installation Instructions Installation of the Micro-SIM Card, TF Card, and Battery Open the back cover. Insert the Micro-SIM card and TF card into the slots following the direction of the arrows. -
Page 8: Internet Connection
Connection via USB does not count towards the total number of access users. If your computer system does not support automatic installation, run the "Driver Setup.exe" program. For more information, contact us at support@porodo.net . Upon successful installation of the CD-ROM drive, the router software installation is complete. -
Page 9: Managing The Web Ui Page
Managing the Web UI Page Web Ul management interface can help users to manage the device efficiently. Follow these steps to login: Connect your computer or phone to your router's WiFi network. Open your web browser and enter the URL: http://192.168.0.1 . Input the default password "admin"... - Page 10 Change Password Quick Settings APN Settings SSID The user can toggle the SSID broadcast on or off and also change the network name (SSID). To navigate to Security Mode Settings, click “Next”.
- Page 11 Security Mode To access the configuration settings, click “Next”. Configuration Settings Network Settings Network settings encompass network connection and wireless network config- urations. Connection Mode There are two available connection modes: automatic and manual.
- Page 12 Network Selection In most cases, the automatic option should suffice. If the automatic setting fails, please select the manual option. APN Settings In automatic mode, the APN will be automatically configured based on the inserted SIM card.
-
Page 13: Precautions
WiFi Settings Precautions Please utilize original AC adapters. We cannot be held liable for potential damages resulting from the use of incompatible adapters. Adapter specifications: 5V=1A. Refrain from using this device near metallic objects or devices emitting electrom- agnetic waves, as it may adversely affect signal reception. This device is not waterproof;... -
Page 14: Warranty
Products that you buy directly from our Porodo website or shop come with a 24-month warranty. When you buy Porodo products from any of our approved sellers, you only get a 12-month warranty. If you want to extend this warranty, go to our website at https://porodo.net/warranty and fill out the form with your information.
