Summary of Contents for Cambridge Audio Evo One

  • Page 1 Evo One Manual Generated: 09/08/2024 - 11:54...

  • Page 2: Table Of Contents

    Table of Contents Evo One ........................................... Introduction ........................................What's included with the Evo One? ................................Front panel controls ..................................... Display ..........................................Rear panel connections ....................................Remote control ......................................Getting connected ....................................... Connecting to a network .................................... StreamMagic app - Setup ...................................

  • Page 3: Evo One

    This guide is designed to make installing and using this product as easy as possible. Information in this document has been carefully checked for accuracy at the time of publishing; however, Cambridge Audio’s policy is one of continuous improvement, therefore design and specifications are subject to change without prior notice.

  • Page 4: What's Included With The Evo One

    What's included with the Evo One? Last updated: August 9, 2024 09:04. Revision #13489 Inside the box of your Evo One you will receive: 1. Evo One Player 2. Quick Start Guide 3. Remote control 4. AAA batteries x 2 5.

  • Page 5: Front Panel Controls

    Front panel controls Last updated: August 9, 2024 09:04. Revision #13490 1. Standby/On Switches the unit between Standby mode (indicated by a dimly lit standby button) and On mode. 2. Info During playback, pressing this button will cycle through the different ‘Now Playing’ screens. Press and hold to display the product info, as well as options for updating the firmware, network setup mode and factory reset.

  • Page 6: Display

    Display Last updated: August 9, 2024 09:05. Revision #13491 1. Album/Source artwork Displays the album artwork. Alternatively, if no artwork is available this will display the source input icon. 2. Track title, artist and album For Internet Radio, this will display the radio station name and the current playback. 3.
  • Page 7 9. Mute volume Displays when the speaker is muted. 10. Firmware update This indicates when new firmware is available. Press the 'Info' button on the front panel or use the StreamMagic app to update the network streamer's firmware. 11. Shuffle, Repeat and Repeat +1...

  • Page 8: Rear Panel Connections

    For connecting a turntable without an integrated phono stage that uses a moving magnet cartridge. If connecting your turntable to the phono input, please make sure you connect the ground of your turntable to the Ground tab of the Evo One.

  • Page 9: Remote Control

    Remote control Last updated: August 9, 2024 09:05. Revision #13493 1. Standby/On Switches the Player between On and Standby mode. 2. Mute Press to mute or un-mute the audio. 3. Volume up/down Volume level adjust. 4. Skip previous/next Skips between previous and next tracks. 5.

  • Page 10: Getting Connected

    A turntable without an integrated phono stage that uses a moving magnet cartridge can be connected to the MM Phono input. When connecting a turntable to the Phono input, you will need to ensure that the turntable ground is connected to the ground tab of the EVO One, as shown below.

  • Page 12: Connecting To A Network

    Failure to maintain your device with regular firmware updates as provided by Cambridge Audio will void the product warranty and is likely to cause major issues to the unit in time. Please ensure that your unit is updated to the most current firmware version. Information on the latest firmware version for the Evo One can be found here.

  • Page 13: Streammagic App - Setup

    StreamMagic app - Setup Last updated: August 9, 2024 09:07. Revision #13496 Your player is network connected, not only can you listen to devices connected to the inputs on the product but you can also stream music from many different sources both on your home network and from the internet. To set up your player, please first download the StreamMagic app from the Apple app store or Google Play store.

  • Page 14: Google Home / Google Cast

    Google Home / Google Cast Last updated: June 27, 2024 11:47. Revision #13470 Your player features Google Cast and can be incorporated in to your Google Home. To set up your player, download the Google Home app on your smart phone or tablet. With Google Cast built in to your player, your phone becomes your remote.

  • Page 15: Airplay

    AirPlay Last updated: February 26, 2024 07:48. Revision #13469 AirPlay is an Apple technology designed to control home audio systems and speakers in any room — with a tap or by just asking Siri — right from iPhone, iPad, HomePod, or Apple TV. Play a song in the living room and kitchen at the same time or adjust the volume in any room, all in sync.

  • Page 16: Built-In Streaming Services

    Built-in streaming services Last updated: June 27, 2024 02:34. Revision #13468 Your player has the following built-in streaming services: Spotify Connect TIDAL Qobuz Deezer Note: It is essential that the device you are streaming from (smartphone, tablet, computer, etc.) is on the same Wi-Fi network as your player, to ensure that the units can communicate with each other.
  • Page 17 2. Choose the playlist, album, song, etc. that you wish to stream to your player. 3. Deezer should now be streaming your chosen content to your player. *Deezer is only available within the StreamMagic app when running firmware version 129-b-004 or later and StreamMagic app version 2.9.0 or later.

  • Page 18: Internet Radio

    Internet radio Last updated: June 27, 2024 02:19. Revision #13467 You can browse and play a wide variety of Internet Radio stations in the StreamMagic app Radio tab. You can also assign up to 99 of your favourite Internet Radio stations and other media as presets on your player, which can then be recalled using the StreamMagic app. A limited amount of presets can be recalled via the remote control if your player includes one.

  • Page 19: Streaming Your Local Digital Music Collection

    To stream local content, you will need the following hardware and software running in your network: 1. Your Cambridge Audio Player. 2. A mobile device such as a smartphone or tablet on which you can run the StreamMagic app, or by accessing your collection via the front panel controls.

  • Page 20: Bluetooth

    Bluetooth Last updated: October 26, 2023 12:56. Revision #13465 The Bluetooth source allows your player to receive wireless Bluetooth audio from most phones, tablets and laptops. Pairing To begin streaming high-quality music from your chosen media source it will first need to be paired with your player. Within the StreamMagic App navigate to the Home tab.

  • Page 21: Tv - Earc Input

    TV - eARC input Last updated: June 19, 2024 03:34. Revision #13464 The ARC or eARC function on a TV allows it to send audio and control commands to a connected audio product. This allows the TV to switch on the audio product when needed, and also to control the volume from the TV remote. In addition to allowing connection and control, eARC compatible TVs should also automatically set their output to an appropriate format compatible with the connected device.

  • Page 22: Usb Media

    USB Media Last updated: June 27, 2024 02:31. Revision #13463 You may connect a USB SSD, USB HDD or flash drive to your player via the USB Media input located on the rear of the unit for playback. Once connected, the following formats are supported: ALAC, WAV, FLAC, AIFF, DSD, WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis Note: your player will read large capacity hard drives connected to the USB input.

  • Page 23: Settings

    Settings Last updated: August 9, 2024 09:09. Revision #13497 Device Name This is how your player will appear in your StreamMagic app and on your home network when using services like Spotify, Google Cast and TIDAL Connect. Giving your player a unique name makes it easier to distinguish when using streaming and smart home services. AirPlay Name This is how your player will appear when using AirPlay or the Apple Home app.
  • Page 24 Restart This will restart your player. Factory Reset This will return your player to its factory settings. You can also do this from the info screen by following the steps below: Hold down the ‘i’ (Info) button on the front panel. As instructed on the display, hold down the ‘reverse skip’...

  • Page 25: Audio Settings

    Audio Settings Last updated: August 9, 2024 09:10. Revision #13498 Your player offers a lot of flexibility for customizing the sound to your personal preferences and room acoustics. Speaker Placement This function can be found under 'Room Settings' in the StreamMagic app home page. Adjusts for placing the player near walls.

  • Page 26: Technical Specifications

    Technical specifications Last updated: August 9, 2024 11:48. Revision #13531 POWER OUTPUT 14 x 50W into 4 Ohms AMPLIFICATION Class-D DRIVERS 14 channels: 4 x 1" silk dome tweeters 4 x 2.25" aluminium cone mid-range 6 x 2.75" long-throw woofers FREQUENCY RESPONSE 38Hz to 20kHz +/-3dB ANALOGUE AUDIO INPUTS...

  • Page 27: Source Quality Matrix

    Source quality matrix Last updated: August 9, 2024 09:10. Revision #13501 SOURCE DELIVERY METHOD MAXIMUM RESOLUTION Spotify Connect Mobile/Desktop App 320kbps Spotify AirPlay Mobile/Desktop App 320kbps Spotify Chromecast Mobile/Desktop App 320kbps Spotify Bluetooth Mobile/Desktop App TIDAL Connect Mobile/Desktop App 24bit / 192 kHz TIDAL (via StreamMagic app) StreamMagic App 24bit / 192 kHz...

  • Page 28: Troubleshooting

    Troubleshooting Last updated: August 9, 2024 09:12. Revision #13506 If you have trouble connecting the Player to your network or the StreamMagic app to your Player, these steps may help to resolve the problem: Ensure that you have followed the 'Connecting to WiFi' steps in the manual here.
  • Page 29 There is a buzz or hum when connecting a turntable to the Phono input: Check that the ground lead is securely connected to both the turntable and the Player's ground tab. Ensure all cable connections are secure.

  • Page 30: Frequently Asked Questions

    Can I access features such as Internet Radio and streaming services via the front panel? It is not possible to access services and features via the front panel of the Evo One. You will be able to access many features via the StreamMagic app, as well as integrated services such as TIDAL, Spotify etc.
