- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WTTD6W/B/S TABLE TOP DISHWASHER Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
- Page 3 PART Ⅰ: Generic Version Please read this manual carefully before using the dishwasher Keep this manual for future reference.
-
Page 4: Table Of Contents
CONTENTS SAFETY INFORMATION PRODUCT OVERVIEW USING YOUR DISHWASHER Loading The Salt Into The Softener MAINTENANCE AND CLEANING External Care Internal Care Caring For The Dishwasher INSTALLATION INSTRUCTION About Power Connection Water Supply And Drain Connection Of Drain Hoses Positioning The Appliance TROUBLESHOOTING TIPS Availability Of Spare Parts LOADING THE BASKETS... -
Page 5: Safety Information
SAFETY INFORMATION WARNING When using your dishwasher, follow the precautions listed below: Installation and repair can only be carried out by a qualified technician This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments;... - Page 6 Packaging material could be dangerous for children! Children should be supervised to ensure that they do not play with the appliance. This appliance is for indoor household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid. Please unplug before cleaning and maintenance the appliance .
- Page 7 Do not modify the plug provided with the appliance if it does not fit the outlet. Have a proper outlet installed by a qualified electrician. Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place.
- Page 8 For unmarked plastic items not so marked, check the manufacturer's recommendations. Use only detergent and rinse agents recommended for use in an automatic dishwasher. Never use soap, laundry detergent, or hand washing detergent in your dishwasher. The door should not be left open, since this could increase the risk of tripping.
-
Page 9: Product Overview
PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Spray arm Salt container Filter assembly Dispenser Cup rack Basket Cutlery rack NOTE: Pictures are only for reference, different models may be different. -
Page 10: Using Your Dishwasher
USING YOUR DISHWASHER Before using your dishwasher : Inside Outside 1. Set the water softener 2. Loading the salt Into the softener 3. Loading the basket 4. Fill the detergent dispenser Please check the section 1 “Water Softener” of PART Ⅱ: Special Version, Please check the section 1 “Water Softener”... - Page 11 Please follow the steps below for adding dishwasher salt: 1. Remove the lower basket and unscrew the reservoir cap. 2. Place the end of the funnel (if supplied) into the hole and pour in about 1 kg of dishwasher salt. 3.
-
Page 12: Maintenance And Cleaning
MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. These surfaces are outside the wash cabinet and are not accessed by water from the spray arms. - Page 13 Fine filter Main filter Main filter Open Open Hold the coarse filter and rotate it Lift fine filter up from main filter. anticlockwise to unlock the filter. Lift the filter upwards and out of the dishwasher. Larger food remnants can be Reassemble the filters in the reverse cleaned by rinsing the filter under order of the disassembly, replace the...
-
Page 14: Caring For The Dishwasher
Spray arm It is necessary to clean the spray arm regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arm, follow the instructions below: To remove the spray arm, pull Wash the spray arm in soapy and out the spray arm upward. - Page 15 Remove the plug Before cleaning or performing maintenance, always remove the plug from the socket. No solvents or abrasive cleaning To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning products. Only use a cloth with warm soapy water. To remove spots or stains from the surface of the interior, use a cloth dampened with water an a little vinegar, or a cleaning product made specifically for dishwashers.
-
Page 16: Installation Instruction
INSTALLATION INSTRUCTION WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. About Power Connection WARNING For personal safety: Do not use an extension cord or an adapter... -
Page 17: Water Supply And Drain
Water Supply And Drain Cold water connection Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure ordinary supply hose that the water is clear. -
Page 18: Connection Of Drain Hoses
Connection Of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than 600 mm. The free end of the hose must not be immersed in water to avoid the back flow of it. -
Page 19: Positioning The Appliance
How to drain excess water from hoses If the connection to the drain pipe is positioned higher than 1000 mm, excess water may remain in the drain hose. It will be necessary to drain excess water from the hose into a bowl or suitable container that is held outside and lower than the sink. Water outlet Connect the water drain hose. -
Page 20: Troubleshooting Tips
TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible causes Solution Fuse blown, or the Replace fuse or reset circuit breaker. Dishwasher doesn't circuit breaker tripped. Remove any other appliances sharing the start same circuit with the dishwasher. - Page 21 Problem Possible Causes What To Do There are rust The affected items Avoid washing items that are not stains on cutlery are not corrosion corrosion resistant in the dishwasher. resistant. A program Always run the quick wash program. was not run after without any crockery in the dishwasher dishwasher salt was and without selecting the Turbo...
- Page 22 Problem Possible Causes What To Do Combination of soft Use less detergent if you have soft Cloudiness on water and too much water and select a shorter cycle to glassware. detergent. wash the glassware and to get them clean. Aluminium utensils Use a mild abrasive cleaner to Black or grey have rubbed against...
-
Page 23: Availability Of Spare Parts
Availability Of Spare Parts Seven years after placing the last unit of the model on the market: Motor, circulation and drain pump, heaters and heating elements, including heat pumps (separately or bundled), piping and related equipment including all hoses, valves, filters and aqua stops, structural and interior parts related to door assemblies (separately or bundled), printed circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including reset software. -
Page 24: Loading The Baskets
LOADING THE BASKETS ACCORDING TO EN60436: Loading the dishwasher to its full capacity will contribute to energy and water savings. 1.Basket: with the cup rack without the cup rack Item Item Number Number Cups Dessert dishes Mugs dessert plates Oval platter Glasses bowl Small pot... - Page 25 Item Number Forks Soup spoons Dessert spoons 4 4 4 Teaspoons Knives Information for comparability tests in accordance with EN60436 Serving spoons Capacity: 6 place settings Gravy ladles Program: ECO Rinse aid setting: Max Serving forks Softener setting: H4...
- Page 27 PART Ⅱ: Special Version WTTD6W WTTD6B WTTD6S Please read this manual carefully before using the dishwasher and Keep this manual for future reference.
- Page 28 CONTENTS USING YOUR DISHWASHER Control Panel Water Softener Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Saving Energy Starting A Programme Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES TECHNICAL INFORMATION...
- Page 29 QUICK USER GUIDE Please read the corresponding content on the instruction manual for detailed operating method. Install the dishwasher (Please check the section 5 “INSTALLATION INSTRUCTION ” of PART Ⅰ: Generic Version.) Inside Outside Load the baskets Remove larger residue from dishes. Avoid pre-rinsing.
-
Page 30: Using Your Dishwasher
USING YOUR DISHWASHER Control Panel Operation (Button) Press this button to turn on your dishwasher Power Press this button to select the appropriate washing programme, Program the programme indicator will be lit. Press the Delay button to increase the delay start time. Delay a cycle for up to 24 hours in one-hour increments. - Page 31 This is standard program, it is suitable to clean normally soiled tableware and it is the most efficient program in terms of its combined energy and water consumption for that type of tableware. Glass For lightly soiled crockery and glass. Program 90 Min indicator...
-
Page 32: Water Softener
Water Softener The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The more minerals there are, the harder your water is. -
Page 33: Preparing And Loading Dishes
Please check the section 3 “Loading The Salt Into The Softener” Please check the section 3 “Loading The Salt Into The Softener” of PART Ⅰ: Generic Version, If your dishwasher lacks salt. Ⅰ: of PART Generic Version, If your dishwasher lacks salt. NOTE: If your model does not have any water softener, you may skip this section. - Page 34 Recommendations for loading the dishwasher Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not necessary to rinse the dishes under running water. For best performance of the dishwasher, follow these loading guidelines. (Features and appearance of baskets and cutlery baskets may vary from your model.) Place objects in the dishwasher in...
- Page 35 Loading the basket All tableware can't be placed face up, in order to improve the cleaning area and washing performance, it is recommended to place the dirty side towards the spray arm. Please don't let tableware out of basket bottom to make sure not block the moving of the spray arm.
-
Page 36: Function Of The Rinse Aid And Detergent
Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher. -
Page 37: Filling The Rinse Aid Reservoir
Filling The Rinse Aid Reservoir Remove the rinse aid reservoir cap Carefully pour in the rinse aid into by rotating it counterclockwise. dispenser, whilst avoiding it to overflow. NOTE: Clean up any spilled rinse aid with an absorbent cloth to avoid excessive foaming during the next wash. -
Page 38: Filling The Detergent Dispenser
Filling The Detergent Dispenser Push latch to open Press the release latch on the detergent Add detergent into the larger cavity dispenser to open the cover. (A) for main wash. For more heavily soiled wash loads, also add some detergent into the smaller cavity (B) for release during pre-wash Close the cover and press on it until it locks into place. -
Page 39: Programming The Dishwasher
PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. Consumption values and program duration are only indicative except for ECO program. -
Page 40: Saving Energy
NOTE: The ECO program is suitable to clean normally soiled tableware, that for this use, it is the most efficient program in terms of its combined (*EN60436) energy and water consumption, and it is used to assess compliance with the EU ecodesign legislation. Saving Energy 1. -
Page 41: Forget To Add A Dish
Forget To Add A Dish? A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1. Press the Start/Pause button to pause the washing. 2. Wait 5 seconds then open the door. 3. -
Page 42: Error Codes
ERROR CODES If there is a malfunction the dishwasher will display an error code. The following table shows possible error codes and their causes. Codes Meanings Possible Causes Faucets is not opened, or water intake is Longer inlet time. restricted,or water pressure is too low. Not reaching required Malfunction of heating element. -
Page 43: Technical Information
TECHNICAL INFORMATION Height (H) 438mm Width (W) 550mm Depth (D1) 500mm (with the door closed) Depth (D2) 812mm (with the door opened 90°) - Page 44 Product information sheet(EN 60436) Supplier's name or trade mark: WILLOW Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ Supplier's address ( ): WTTD6W _ B _ S Model identifier: General product parameters: Parameter Value Parameter Value Height Rated capacity ( ) (ps)
- Page 45 01759 487837 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ...
- Page 46 ‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier.
- Page 47 The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice.
- Page 48 WTTD6W/B/S TABLE TOP DISHWASHER...
