ASSEMBLY INSTRUCTIONS
Important Safety Instructions:
● Please read all instructions before beginning assembly
● Please make sure receive all the parcels to start the assembly
● For your safety and convenience,assembly by two people is recommended
● Use the parts and hardware lists to identify and separate each of the components included
● Save all packing materials until assembly is completed to avoid the accidental discarding
of smaller parts or hardware
ITEM#: KWF130WG
KWF130BC
KWF130WT
THANK YOU FOR PURCHASING
Advertisement
Related Manuals for BUSH FURNITURE KWF130WG
Summary of Contents for BUSH FURNITURE KWF130WG
- Page 1 ASSEMBLY INSTRUCTIONS ITEM#: KWF130WG KWF130BC KWF130WT Important Safety Instructions: ● Please read all instructions before beginning assembly ● Please make sure receive all the parcels to start the assembly ● For your safety and convenience,assembly by two people is recommended ●...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING File cabinets may tip over causing serious injury if not assembled, installed, or used properly. • Before using, check that only one drawer opens at a time. If both drawers can open at the same time, the interlock mechanism is not functioning properly due to incorrect assembly or a defect and must be corrected before use. - Page 3 MAXIMUM RECOMMENDED WEIGHT LOADS MAXIMUM WEIGHT: 200 LBS (90.9 KG) PESO MÁXIMO: 200 LIBRAS (90.9 KILOGRAMO) POIDS MAXIMUM: 200 LIVRES (90.9 KILOGRAMME) MAXIMUM WEIGHT: 50 LBS (22.5 KG) PESO MÁXIMO: 50 LIBRAS (22.5 KILOGRAMO) POIDS MAXIMUM: 50 LIVRES (22.5 KILOGRAMME)
-
Page 4: Exploded View
EXPLODED VIEW... - Page 5 HARDWARE Fasteners are shown in actual size. Los fijadores son demonsrtados en su tamaño actual. Les attaches sont montrées dans l'échelle grandeur. H180604 H181468 KD Cam H38169 H35251 Wood Dowel8 x 30mm H23198 H101725 #10 x 1-1/2'' [ 4 ] H34174 H160803 M4 x 19mm...
- Page 6 HARDWARE H89793 H181031 Front File Extrusion File Bar 22-5/8"(576mm) 12-1/2" (318mm) Z39433 H180792 [ 4 ] File Extrusion 14" Slide 12-3/4" (323mm) H181032 H100446 [ 4 ] File Extrusion 22-5/8" (576mm) Drawer Bracket H92331 H180971 Handle Anti Tip Wedge H92330 Anti Tip Mechanism TIP OVER RESTRAINT HARDWARE...
- Page 7 STEP 1 [ 3 ] [ 6 ] H 180604 Wood Dowel KD Bolt 8 x 30mm Safety glasses Gafas de seguridad Lunettes de protection...
- Page 8 STEP 2 [ 3 ] KD Cam...
- Page 9 STEP 3...
- Page 10 STEP 4 [ 1 ] [ 3 ] H92330 H147488 #8 x 5/8" Anti Tip Mechanism 14" Slide Mount H101725 [ 6 ] Z39433 [ 2 ] #6 x 1/2" Orientation Orlentaclón L'orlentation Orientation Orlentaclón L'orlentation...
- Page 11 STEP 5 [ 3 ] [ 6 ] H 180604 KD Bolt Wood Dowel 8 x 30mm Safety glasses Gafas de seguridad Lunettes de protection...
- Page 12 STEP 6 [ 3 ] KD Cam...
- Page 13 STEP 7 14" Slide Mount Z39433 H101725 [ 6 ] [ 2 ] #6 x 1/2" Orientation Orlentaclón L'orlentation Orientation Orlentaclón L'orlentation...
- Page 14 STEP 8 [ 6 ] [ 2 ] H 180604 KD Bolt Wood Dowel 8 x 30mm Safety glasses Gafas de seguridad Lunettes de protection...
- Page 15 STEP 9 [ 2 ] KD Cam...
- Page 16 STEP 10 [ 3 ] KD Cam An assistant is required. Es necesario un ayudante. Un assistant est nécessaire.
- Page 17 STEP 11 [ 3 ] KD Cam An assistant is required. Es necesario un ayudante. Un assistant est nécessaire.
- Page 18 STEP 12 [ 2 ] [ 4 ] H 180604 KD Bolt Wood Dowel 8 x 30mm Safety glasses Gafas de seguridad Lunettes de protection...
- Page 19 STEP 13 H23198 #10 x 1-1/2''...
- Page 20 STEP 14 [ 4 ] KD Cam An assistant is required. Es necesario un ayudante. Un assistant est nécessaire.
- Page 21 STEP 15 [ 14 ] [ 2 ] #3 x 3/4'' [ 2 ] With assistant carefully flip unit over. Con un assistente cuidadosamente acueste la unidad. Avec l'aide d'une autre personne, retourner lentement l'unite sur le rebord frontal. Safety glasses Gafas de seguridad Lunettes de protection...
- Page 22 STEP 16 M4 x 19 Drawer Bracket H180971 Handle #10 x 1/2''...
- Page 23 STEP 17 H181031 #6 x 1/2" Front File Extrusion 22-5/8"(576mm)
- Page 24 STEP 18 H92331 Z39433 [ 2 ] [ 4 ] Anti Tip Wedge 14" Slide Runner Orientation Orlentaclón [ 18 ] H101725 L'orlentation #6 x 1/2" Orientation Orlentaclón L'orlentation Orientation Orlentaclón L'orlentation...
- Page 25 STEP 19 [ 8 ] H23198 H101725 #10 x 1-1/2'' #6 x 1/2" Finished Side Lado Terminada Cote Fini H23198 Finished Side H23198 Lado Terminada Cote Fini...
- Page 26 STEP 20 File Extrusion File Extrusion 12-3/4" (323mm) 22-5/8" (576mm) H89793 File Bar 12-1/2" (318mm) H180792 H181032 H180792 H180792 H180792...
- Page 27 STEP 21 Must adjust this before installing drawer Lower Drawer Gaveta Inferior Tiroir Inferieur An assistant is required. Es necesario un ayudante. Un assistant est nécessaire.
- Page 28 STEP 22 Must adjust this before installing drawer Upper Drawer Gaveta Superior Tiroir Superieur An assistant is required. Es necesario un ayudante. Un assistant est nécessaire.
- Page 29 STEP 23 REQUIRED TOOL: PHILLIPS SCREWDRIVER HERRAMIENTA REQUERIDA: DESTORNILLADOR PHILLIPS OUTIL REQUIS: TOURNEVIS CRUCIFORME 1. LOOSEN SCREWS. 2. ADJUST DRAWER FRONTS. 3. TIGHTEN SCREWS. 1. Afloje los tornillos 2. Ajustar frentes de cajón 3. Apriete los tornillos 1. Desserrer les vis 2.
- Page 30 STEP 24 x2pcs 1. Place unit in desired location. 2. Mark stud location on the wall, 1” below top and side of unit. 3. Drill 5/16”hole 2” deep at marks on the wall. Wall Wall...
- Page 31 STEP 25 x2pcs x2pcs x2pcs Pull to verify lock Wall Wall...
- Page 32 What is Proposition 65? Proposition 65 is a California law that requires warning labels on products that may contain one of more than 800-plus chemicals or ingredients that the California Office of Environmental health Hazard Assessment(OEHHA) has deemed to cause cancer or other reproductive toxicity. chemicals and elements on this list include wood dust , brass , and other everyday substances, which can be found in very common household items, such as : lamps , tableware , jewelry , crystal glasses , electric cords , beauty products , automobiles , and furniture.
