System Specifications - Acer Veriton 3700GX User Manual

System specifications

Component
Processor
System memory
Chipset
Graphics
Audio
LAN
IDE
FDD
PS/2
USB
Serial port
Printer port
Thermal
Security
Specification
• Intel® Pentium® 4 2.8 - up to 3.8 GHz
• Intel® Celeron® 2.8 - up to 3.4 GHz
Four SDRAM slots support a maximum of 4 GB dual-channel
DDR2 memory
• Intel® 915G Express + ICH6 chipset
• With support for both the built-in Intel® Graphics Media
Accelerator (GMA) 900, which supports widescreen LCD
displays and accelerated DirectX 9 3D, plus support for
PCI Express graphics cards.
• Dynamic Video Memory Technology (DVMT) 3.0
supports up to 224MB of video memory; system memory
is allocated where it is needed dynamically.
Intel® High Definition Audio, HD Audio hardware is capable
of delivering the support and sound quality for up to eight
channels at 192 kHz/32-bit quality.
10/100/1000 Base-T Gigabit Ethernet connectivity
One 40-pin parallel ATA IDE slot
Four Serial ATA ports
1.44 MB 3.5 inch floppy drive
• PS/2 keyboard port
• PS/2 mouse port
Eight external USB 2.0 ports
One serial port on I/O bracket
(Optional 2nd serial port connection)
One parallel printer port
Dynamic fan speed control
• Chassis lock pad
• Chassis intrusion alarm
3
