No. Component
1 PCI Express x 16 connector
3 LAN LED
5 Front panel audio
connector
7,8 Front daughter board
connector
11 System fan connector
13 Clear CMOS jumper
1-2 Normal (Default),
2-3 Clear CMOS
15 Front panel connector
17 Lithium battery
19 BIOS
21 Chassis intrusion connector
23 Diskette drive connector
25 Memory slots (4)
27 CPU fan connector
29 Alternate power connector
No. Component
2 PCI Express x1 connector
4 S/PDIF output connector
6 PCI Conventional bus
connectors (2)
9,10 Front panel USB connector
12 One Button Recovery connector
14 Serial ATA IDE connectors (4)
16 TPM connector
18 GPIO connector
20 BIOS write protect jumper
1-2 Protected
2-3 Not protected (Default)
22 Parallel ATA IDE connector
24 Main power connector
26 External COM port connector
28 CPU socket
30 ATX 12V power connector
