Summary of Contents for NRS KIOSK
- Page 1 SELF-INSTALLATION INSTRUCTIONS...
- Page 2 (1) Open bottom panel with key...
- Page 3 (2) Plug in power cord Power supply port is located inside of the bottom panel of the Kiosk. [The Kiosk’s power supply cord.]...
- Page 4 (3) Turn on red switch next to power input hole The red power switch is located inside of the bottom panel of the Kiosk. (4) Connect ethernet cable between Ethernet Port 1 and your internet source Ethernet Port 1 is located inside of the bottom panel of the Kiosk.
- Page 5 (5) Install credit card machine bracket Use the three (3) small screws to screw the bracket into the side of the Kiosk. [Side view of the bracket after it has been screwed into the Kiosk.]...
- Page 6 Use the single screw to screw the credit card machine into the bracket. The screw should go through the center hole on the bracket and into the center hole on the back of the credit card machine. [Front view of the Kiosk after the PAX has been secured to the bracket.]...
- Page 7 (7) Connect ethernet cable between Ethernet Port 2 and the credit card machine Ethernet Port 2 is located inside of the bottom panel of the Kiosk. [The red ethernet port wire that is attached to the credit card machine.]...
- Page 8 (8) Close the bottom panel and lock it. Store the keys someplace safe! The wires should be put through the openings in the panel door. Color of Ethernet cables may vary (9) Plug in the power cord for the credit card machine The wire for the power cord should be connected to the credit card machine’s power input wire and into the power cord box.
- Page 9 Once the power cord is plugged in, the PAX machine should turn on and you should see the NRS Pay home screen. (10) Power on the Kiosk Press the circle power button on top of the Kiosk screen to power on the Kiosk.
- Page 10 Once the power is turned on, the Kiosk software will take about 1 minute to load and then you should see the Kiosk home page. You may see an internet connection error while you wait for the software to load, but this is normal.
- Page 11 *Self-ordering Kiosk subject to terms and provided by National Retail Solutions, Inc. (“NRS”). Contract required. NRS is not responsible for installation of Kiosk and/or any liability or damage that may occur due to poor or faulty installation by merchant or its agents. NRS Pay services required for kiosk operation and subject to separate contract.
