Two handle wall mounted tub filler with handshower faucet trim

Advertisement

Quick Links

Model Number: ____________________
Número del modelo
Numéro de modèle
Date of Purchase: ____________________
Fecha de compra
Date d'achat
Register Online
Regístrese en línea
S'enregistrer en ligne
www.deltafaucet.com/registerme
To reference replacement parts and access additional
technical documents and product info,
visit www.deltafaucet.com
Para referencia sobre las piezas de repuesto y acceder
a documentos técnicos adicionales e información del
producto, visite www.deltafaucet.com
Pour obtenir la référence des pièces de rechange ainsi
que pour avoir accès à d'autres documents techniques et
renseignements sur le produit, allez à www.deltafaucet.com
?
1-800-345-3358
www.deltafaucet.com/service-parts
Read all instructions prior to installation.
CAUTION
!
Failure to read these instructions prior to installation may result in personal
injury, property damage, or product failure. Manufacturer assumes no
responsibility for product failure due to improper installation.
Lea todas las instrucciones antes de hacer la instalación.
ADVERTENCIA
!
El no leer estas instrucciones de instalación puede resultar en lesiones
personales, daños a la propiedad, o falla en el funcionamiento del producto.
El fabricante no asume ninguna responsabilidad por la falla del producto
debido a una instalación incorrecta.
Veuillez lire toutes les instructions avant l'installation.
AVERTISSEMENT
!
L'omission de lire les présentes instructions avant l'installation peut
entraîner des blessures, des dommages matériels ou le bris du produit. Le
fabricant se dégage de toute responsabilité à l'égard d'un bris du produit
causé par une mauvaise installation.
You may need:
Usted puede necesitar:
Articles dont vous pouvez avoir besoin :
1/8" (3.17mm)
06/26/2024
TWO HANDLE WALL MOUNTED TUB FILLER
115591
WITH HANDSHOWER FAUCET TRIM
GRIFERÍA MURAL DE BAÑERA DE DOS
MANECILLAS CON COMPONENTE DE GRIFO
DE DUCHA MANUAL
REMPLISSEUSE DE BAIGNOIRE MURAL
À DEUX POIGNÉES AVEC DOUCHETTE À
GARNITURE
Trim only. Rough-in R3500-WL required for installation
Solo componentes del grifo. Se requiere R3500-WL para la instalación
Garniture seulement. La plomberie brute R3500-WL est nécessaire pour
l'installation
1
115591 Rev. B

Advertisement

loading
Need help?

Need help?

Do you have a question about the Broderick T5784-BLLHP-WL-H583BL and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta Broderick T5784-BLLHP-WL-H583BL

  • Page 1 TWO HANDLE WALL MOUNTED TUB FILLER 115591 WITH HANDSHOWER FAUCET TRIM GRIFERÍA MURAL DE BAÑERA DE DOS MANECILLAS CON COMPONENTE DE GRIFO DE DUCHA MANUAL REMPLISSEUSE DE BAIGNOIRE MURAL Model Number: ____________________ À DEUX POIGNÉES AVEC DOUCHETTE À Número del modelo Numéro de modèle GARNITURE Date of Purchase: ____________________...
