Care and Maintenance -
Do not leave canopy extended during heavy snow storms or any extreme weather conditions.
Reasonable care should be taken to remove accumulated dirt and debris in track.
Canopy Tracks may have sharp corners. Always use gloves when handling to prevent cuts.
Lubrication (supplied in kit) of wing wheels and track should be done annually.
Wing and canopy can be removed seasonally to improve longevity. Check Wheels and Axel to
ensure proper working order. Do not operate if cracked or broken. Call OLT for replacement.
Check Track Screws for wear annually. Remove and replace any screws showing excessive wear.
To keep the Harbor-Time canopy fabric looking clean and bright, wash periodically with a soft brush,
warm water and mild soap. Do not use detergent.
5 year limited manufacturer's warranty on the Harbor-Time canopy fabric.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
www.outdoorlivingtoday.com
Page 1
Revision #5
September 7, 2021
sales@outdoorlivingtoday.com
Advertisement
Related Manuals for Outdoor living today OLM
Summary of Contents for Outdoor living today OLM
- Page 1 Outdoor Living Today products. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase.
-
Page 2: Troubleshooting
Once your pergola and retractable canopy have been correctly installed, do a water test to confirm water is draining properly from the canopy. Please contact us immediately if large amounts of water remain in each fabric fold when extended. The Canopy is designed to hold several gallons of water per fold. - Page 3 14x16 - 4 Post Retractable Canopy Parts List 1 1/2” Torx Screws - 1 1/4” - 7 pcs / 2 1/2” - 20 pcs / 4” - 25 pcs 4” Torx Screws 24 Pcs. Brown Wood Screws. 8 Pcs. B - 96” long Canopy Tracks - 2 Pcs. A - Canopy Lowering Cleats - 6 Pcs.
- Page 4 Installation of the OLM Retractable Canopy couldn’t be easier. Just 4 Easy Steps! 1. Attach lowering cleat and canopy tracks to pergola framing. 2. Lift aluminum wings with canopy and feed wheels into track. 3. Position aluminum wing stops and attach.
- Page 5 Counter sunk 3 Cleats drill holes. With a Step Ladder, install Part A - Canopy Lowering Cleats - 3 pcs Total. (2 pcs. @ 1 1/2” x 2 1/2” x 37 1/4”) & (1 pc. @ 1 1/2” x 2 1/2” x 66”). Attach with 2-3 - 4” Torx Screws. Cleats will lower the canopy on one side and drain water off the fabric so it doesn’t collect excessively.
- Page 6 With a Step Ladder, install remaining Part A - Canopy Lowering Cleats - 3 pcs Total. (2 pcs. @ 1 1/2” x 2 1/2” x 37 1/4”) & (1 pc. @ 1 1/2” x 2 1/2” x 66”). Attach onto the bottom of other Part A - Canopy Lowering Cleats from Step 1 with 2-3 - 2 1/2”...
- Page 7 Position Part H -High Side Track Brace - 6 pcs Total. (1 1/2” x 2 1/2” x 5 1/2”) directly under D joist and flush against C Girder on opposite Girder as per Steps 2-3. Braces are counter sunk. Attach with 2 - 2 1/2”...
- Page 8 Carefully lift connected track up supporting in the center. Place tight against post and underneath lower cleats and against braces. 4 - 1 1/2” Torx Screws per track. Pre-drill track first with 1/4” bit included. Attach track with 1 - 1 1/2” Torx Screw on gap end screwing up through the track into bottom of wood joist.
- Page 9 Align and attach second Canopy Track directly underneat joist ladders and against high side brace and attach as per Steps 6-8. Use 1 1/2” Torx Screws to secure. When screwing into track, drill with 1/4” bit first. Lubricant Prior to feeding Part C - Aluminum Wings Part C and Canopy into track, locate Lubricant in (8 Wings)
- Page 10 Rope Knot on inside Anchor Rope on Pull Rope on Lead Wing last wing facing out Gap side Before feeding Part C - 157” long Aluminum Wings (6) with Canopy into track, make sure canopy fabric is facing the correct direction. First, locate Lead and Anchor Wings in set.
- Page 11 Continue to feed wings into the track until all wings are installed. 3rd Wing 8 Wings Both sides Install Part D - 4 1/2” long Aluminum Wing Stops - 2 Pcs. where track ends and gap exists. Use 2 - 1 1/4” brown screws per stop to install. When removing the wings and canopy in the future, simply remove wing stops and roll wing and canopy out carefully with a helper.
- Page 12 Part F - Canopy Pull Handle Using Part F - Canopy Pull Handle, pull canopy Lead Rope back and forth a few times to lubricate wheels and track. If wing binds, stop and pull foward until wings are straight and start again. When wings and canopy are tracking well, pull canopy to anchor side of pergola to install Part E - Wing Anchor Knob.
- Page 13 Lead wing tight against corner bracket Lead Rope Pull canopy out using pull han- dle on lead rope. Fully extend canopy until outside lead wing con- tacts corner bracket or until canopy cannot extend further. Follow Step 16 to position and attach wing anchor knob to outside girder.
- Page 14 Congratulations on installing your OLM Retractable Canopy from Outdoor Living Today. Care and Maintenance - Do not leave canopy extended during heavy snow storms or any extreme weather conditions. Reasonable care should be taken to remove accumulated dirt and debris in track.
