- Page 1 AeroWave E Series USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS Safety Information Key Features Product Contents Specifications Product Anatomy Installation Local Operation Smart Grow System Controller Setup Maintenance Complete Your Setup Warranty... -
Page 4: Safety Information
SAFETY INFORMATION Please carefully read the following information before use. Failure to follow these safety instructions may result in injury and will release VIVOSUN of all liability and void all product warranties. IMPORTANT SAFETY INFORMATION: This fan is designed to operate exclusively with the provided power adapter. - Page 5 SAFETY INFORMATION Do not place any part of this product near sources of high heat such as stovetops or fireplaces. Do not cover the power cable with carpets, electrical equipment, or any other objects. Do not pass the power cable beneath hot objects or other electrical equipment. Make sure the mains voltage and frequency are within the range as indicated on the power adapter before plugging in this device.
- Page 6 SAFETY INFORMATION The fan's motor circuit board includes an overcurrent protection component. If the motor draws too much current due to an unexpected surge or internal issue, this component triggers an automatic shutoff. This prevents the motor from overheating, which could lead to deformation or fire.
-
Page 7: Key Features
VIVOSUN SGS PWM SMART CONTROL SLIM BASE COMPATIBLE PWM tuning enables precise Features a minimized Compatible with VIVOSUN fan speed control at each level base design that is Smart Grow System for and features a dedicated natural highly efficient and precise, remote, and wind mode. -
Page 8: Product Contents
PRODUCT CONTENTS Clip x 1pc x 1pc Type-C Extension cable Cable Tie Wire Tie x 1pc x 3pcs x 1pc... -
Page 9: Specifications
SPECIFICATIONS VSF-AWE6 VSF-AWE9 6 in. / 152 mm 9 in. / 228 mm Diameter Color White/Black/Green White/Black/Green Number of Speed Settings Engine EC-motor EC-motor √ √ Auto Oscillation Horizontal Oscillation 90°(±45°) 80°(±40°) Vertical Angle 80° 80° Adjustment Range Power Usage... - Page 10 SPECIFICATIONS VSF-AWE6 VSF-AWE9 Power Drive 12V/1.0A 12V/1.5A Input 100-240V AC 50/60Hz 100-240V AC 50/60Hz Warranty 2 years 2 years Airflow 320 CFM 580 CFM Noise Level 33 dB(A) 36 dB(A) Waterproof Rating IP54 IP54 32-140°F / 0-60°C 32-140°F / 0-60°C Operating Temperature 100 in.
-
Page 11: Product Anatomy
PRODUCT ANATOMY Protective Front Cover Control Button Fan Blade Type-C Interface Pitching Knob Power Adapter Retaining Clip... -
Page 12: Installation
INSTALLATION STEP 1 STEP 2 Rotate the knob counter-clockwise until it Slide the fan's attachment piece into the detaches from the grip clip. body of the swivel clip. Ensure that the fan is securely attached by opening the swivel Pull the smaller button piece away from the clip around the fan. - Page 13 INSTALLATION STEP 3 STEP 4 Push the pitching knob through the shaft Clip your fan onto your tent pole or another hole and retighten clockwise. pole and ensure that it is securely attached.
- Page 14 INSTALLATION STEP 5 STEP 6 Plug the power adapter into an outlet. Find a clean and secure surface where you can attach the fan. Once the mounting point is secure, use the included zip tie to bundle the cable and fasten it to the designated location.
-
Page 15: Local Operation
LOCAL OPERATION ADJUSTING FAN SPEED Fan Speed Indicator Press the speed button once to turn the fan on. Press the button repeatedly to cycle through the speed levels (Level 1 to 5). Natural Wind Mode: After reaching Level 5, another press will switch the fan to the natural wind mode. - Page 16 Auto oscillation can only be activated/deactivated by the swivel button, and cannot be controlled by external controllers or the VIVOSUN app. Oscillation Off: If the oscillation function is turned off on the fan itself, it will not oscillate even when your controller sets it to oscillate.
-
Page 18: Controller Setup
Wi-Fi configuration mode. During this process, the green LED on the AeroWave will flash rapidly. Mobile App Setup: Open the VIVOSUN app on your smartphone or tablet and follow the on-screen instructions to complete the Wi-Fi configuration and connect to your AeroWave. - Page 19 Connect the Type-C extension cord into the Type-C port on your AeroWave. Then plug the other end into Port B on the GrowHub E42/E42A controller. Mobile App Setup: Open the VIVOSUN app on your smartphone or tablet and follow the on-screen instructions to complete the Wi-Fi configuration and connect to your AeroWave.
- Page 20 CONTROLLER SETUP STEP 1 / I n VIVOSUN APP, select your GrowHub E42/E42A and enter settings by tapping the top right button .
- Page 21 CONTROLLER SETUP STEP 2 Click "Additional Settings" to view Control Port B settings. Set Control port (B) to Circulation fan. Now you can control AeroWave through GrowHub E42/E42A and the VIVOSUN app.
- Page 22 VIVOSUN app, you can control the fan speed through either method: GrowHub Controller: Use the controls on your GrowHub controller to adjust the fan speed. VIVOSUN App: Open the VIVOSUN app on your smartphone or tablet and adjust the fan speed settings within the app.
-
Page 23: Maintenance
MAINTENANCE Always unplug the power adapter from the outlet before cleaning the fan. Never clean the fan while it is running. Step 1 Disassemble the fan as follows before you clean the device. 1. Loosen the fastening screws at the bottom of the front cover by turning them counterclock- wise with a screwdriver. - Page 24 MAINTENANCE Step 2 Clean any oil, dust, and grime by wiping the blades and parts down with a soft, wet cloth and then wipe it with a dry cloth. Do not use gasoline or other plastic/paint-corrosive solvents. Do not bend or press the device too hard while cleaning as this can damage the blades. Step 3 Follow Step 1 in reverse to reassemble the fan.
-
Page 25: Complete Your Setup
COMPLETE YOUR SETUP CONTROLLER GrowHub E42 & E25 & E42A - WiFi remote control with VIVOSUN App - Complete control of lights, inline fans and circulation fans - Temp./Humidity monitoring and control - Compatible with VIVOSUN devices such as AeroLight, AeroZesh, VS series lights... - Page 26 COMPLETE YOUR SETUP INLINE DUCT FAN AeroZesh - Efficient airflow with high static pressure - 4'' / 6'' / 8'' for different sized tents - Energy efficient and quiet EC motor - Dual ball bearings with long lifespan - Precise fan speed adjustment by PWM - Compatible with GrowHub controller for multiple professional operation modes CARBON FILTER...
-
Page 27: Warranty
WARRANTY INFORMATION VIVOSUN provides a 2-year warranty against defects on all AeroWave E Series products purchased directly from us or through our authorized dealers. This policy serves as our commitment to promptly address any manufacturing defects or premature breakage that may occur during normal use of our products.
