Summary of Contents for Dell C2722DE
- Page 1 Dell C2422HE Dell C2722DE Dell Display Manager User’s Guide Model: C2422HE/C2722DE Regulatory model: C2422HEt/C2722DEt...
- Page 2 NOTE: A NOTE indicates important information that helps you make better use of your computer. Copyright © 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Overview .........4 Using the Quick Settings Dialog. -
Page 4: Overview
Overview Dell Display Manager is a Microsoft Windows application used to manage a monitor or a group of monitors. It allows manual adjustment of the displayed image, assignment of automatic settings, energy management, window organization, image rotation, and other features on selected Dell monitors. After installed, Dell Display Manager runs each time when the system starts and places its icon in the notification tray. -
Page 5: Using The Quick Settings Dialog
Using the Quick Settings Dialog Clicking Dell Display Manager’s notification tray icon opens the Quick Settings dialog box. When more than one supported Dell monitors are connected to the computer, a specific target monitor can be selected using the menu. The Quick Settings dialog box allows you to easily adjust the brightness, contrast, resolution, window layout, and so on. -
Page 6: Setting Basic Display Functions
Auto Mode that applies a preset mode based on the active application. An on- screen message displays the current preset mode whenever it changes. The selected display’s Brightness and Contrast can also be directly adjusted from the Basic tab. C2422HE C2722DE Setting Basic Display Functions... - Page 7 NOTE: When multiple Dell monitors are connected, select “Enable display matrix control” to apply brightness, contrast and color presets controls to all monitors. C2422HE C2722DE Setting Basic Display Functions...
-
Page 8: Assigning Preset Modes To Applications
Dell Display Manager is pre-configured for many popular applications. To add a new application to the assignment list, simply drag the application from the desktop, Windows Start Menu or elsewhere, and drop it onto the current list. -
Page 9: Organizing Windows With Easy Arrange
Organizing Windows with Easy Arrange Easy Arrange helps you to effectively organize your application windows on the desktop. You first choose a pre-defined layout pattern which suits your work, then you just need to drag the application windows into the defined zones. Press “>” or use Page Up/Page Down key to find more layouts. - Page 10 If you are using multiple monitors in an array or matrix, Easy Arrange layout can be applied across to all the monitors as one desktop. Select “Span multiple monitors” to enable this feature. You need to align your monitors properly to make it effective. There are other advanced usage of Easy Arrange.
-
Page 11: Managing Multiple Video Inputs
Managing Multiple Video Inputs The Input Manager tab provides convenient ways for you to manage multiple video inputs connected to your Dell monitor. It makes it very easy to switch between inputs while you work with multiple computers. All video input ports available to your monitor are listed. You can give each input a name as you like. - Page 12 If you want to use the KVM function, click KVM, enter the number of PCs you want to connect to, and then press NEXT. In PC1-PC3, select the Video Input Port to connected to the port and select the USB Upstream Port to connected to the port, then press NEXT.
- Page 13 Then click Finish to complete your options. NOTE: DDM communicates with your monitor even when the monitor is displaying video from another computer. You can install DDM on the computer you frequently use and control input switching from it. You may also install DDM on other computers connected to the monitor.
-
Page 14: Restoring Application Positions
Restoring Application Positions DDM can help you restore application windows into their positions when you reconnect your computer to the monitor(s). You can quickly access to this feature by right- clicking on DDM icon in the notification tray. If you choose “Auto-restore window layout”, your application windows’ positions are tracked and remembered by DDM. -
Page 15: Applying Energy Conservation Features
Applying Energy Conservation Features On supported Dell models, an Options tab is available that provides PowerNap energy conservation options. You can choose to set the display’s brightness to the minimum level, or to put the display to sleep when the screensaver is activated. -
Page 16: Other Shortcut Keys
Other Shortcut Keys You can define the shortcut keys for quick access to the following DDM functions: • Program shortcut key: to quickly open the Quick Settings dialog box. • Easy Arrange MRU shortcut key: to quickly apply the 5 recently used window layouts. -
Page 17: Attach Ddm To Active Window (Windows 10 Only)
Attach DDM To Active Window (Windows 10 Only) DDM icon can be attached to the active window you are working on. Click on the icon for easy access to below features. Feature Function Description Attach DDM to Change preset or • DDM icon attached to active window and user can easily Active Window snap to different... -
Page 18: Troubleshooting
Click on the icon, DDM shows a more detailed error message. Please note that DDM only works with Dell-branded monitors. If you are using monitors from other manufacturers, DDM doesn’t support them. If DDM is unable to detect and/or communicate with a supported Dell monitor, please take the following actions to troubleshoot: 1. - Page 19 DDM may not work with the following monitors:: • Dell monitor models earlier than year 2013 and D-series of Dell monitors. For more information see www.dell.com/support/monitors. • Gaming monitors using Nvidia-based G-sync technology • Virtual and wireless monitors do not support DDC/CI • Some early models of DP 1.2 monitors, it may be necessary to disable MST/DP...
