Summary of Contents for Daewoo AVS1566
- Page 1 4 in 1 Gaming Combo Model No. AVS1566 User Manual IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
- Page 2 4 in 1 Gaming Combo Model No. AVS1566 User Manual Contents Page No. Contents Reading and Storing the User Manual Important Safety Instructions for Proper Use Explanation of Symbols Before the First Time You Use Your Gaming Combo set About Your 4 in 1 Gaming Combo Gaming Headphones –...
- Page 3 4 in 1 Gaming Combo Model No. AVS1566 User Manual READING AND STORING THE USER MANUAL Before using this product, please read through this manual carefully paying particular attention to the safety instructions. Failure to do so may result in personal injury or damage to the product.
- Page 4 4 in 1 Gaming Combo Model No. AVS1566 User Manual Explanation of Symbols The following symbols or words are used in this instruction manual: Products labelled with UK Conformity Assessment identifies products conforming to UK statutory requirements. Products labelled with this symbol conform to applicable provisions of the European Economic Area.
- Page 5 4 in 1 Gaming Combo Model No. AVS1566 User Manual Gaming Headphones Description of Parts 1. Headband 2. Padded Earpieces 3. Flexible Microphone 4. USB Power Plug 5. Mic 3.5mm Plug (Red) 6. Headphone 3.5mm Plug (Green) 7. Cable 8. Volume Control (Rear) 9.
-
Page 6: Using A Laptop
4 in 1 Gaming Combo Model No. AVS1566 User Manual Connecting up your Gaming Headphones When… …Using a PC a. Insert the green Headphone 3.5mm Plug (6) into the Green coloured Headphone socket on your PC. b. Insert the red Mic 3.5mm Plug (5) into the Red/Pink coloured Mic. - Page 7 4 in 1 Gaming Combo Model No. AVS1566 User Manual …Using a PS4 Controller *PS4 is a registered trademark of Sony Group Corporation. a. Insert the green Headphone 3.5mm Plug (6) into the Green coloured socket in the Adaptor (9).
- Page 8 4 in 1 Gaming Combo Model No. AVS1566 User Manual Gaming Mouse Description of Parts 10. Left Mouse Button 11. Scroll Wheel 12. Forwards Button 13. Backwards Button 14. DPI Button 15. Right Mouse Button 16. Mouse USB plug Connecting up your Gaming Mouse When…...
- Page 9 4 in 1 Gaming Combo Model No. AVS1566 User Manual Adjusting the Resolution (DPI) of Your Gaming Mouse The resolution of this Gaming Mouse can be adjusted so the mouse pointer on the screen moves a large distance or a shorter distance for the same movement.
- Page 10 4 in 1 Gaming Combo Model No. AVS1566 User Manual Connecting up your Gaming Keyboard When… …Using a PC Insert the Keyboard USB Plug (20) into any spare USB socket on your PC: …Using a Laptop Insert the Keyboard USB Plug (20) into any spare USB socket on your Laptop:...
- Page 11 4 in 1 Gaming Combo Model No. AVS1566 User Manual RGB Backlit Key Modes: 1. To Switch the RGB Backlit Keys (17) on and off press the light key. 2. To change the RGB Backlit Keys (17) colour mode from continuous to fading mode, hold the Function [ ] key down and press the light key.
- Page 12 4 in 1 Gaming Combo Model No. AVS1566 User Manual Technical Specifications Model Number AVS1566 Headphones Impedance 16Ω ±15% Speaker Sensitivity 108 ±3dB @1Khz; 1mW Speaker Diameter 50mm Rated Power 10mW (20mW max.) Frequency Response 20Hz – 20Khz Microphone Diameter 6.5mm...
- Page 13 4 in 1 Gaming Combo Model No. AVS1566 User Manual Recycling Information Disposal of the Packaging Dispose of paper and cardboard in appropriate paper re-cycling facilities. Dispose of recyclable plastics in appropriate plastic re-cycling facilities. Dispose of non-recyclable plastics in the appropriate plastics collection service.
-
Page 14: Warranty
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year guarantee Your Daewoo audio product is guaranteed for 1 year from the date of original purchase, with proof of purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty product should be returned to the place of purchase, replacement or refund is at the discretion of the retailer.
