- Page 1 OPERATION, INSTALLATION AND MAINTENANCE MANUAL F l u s h M o u n t E n c l o s u r e f o r H E AT S T R I P C l a s s i c w i t h R e m o t e ( T H H - A R R a n g e )
- Page 2 MARCH 22 The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP into a ceiling. They are available for all HEATSTRIP Classic with Remote models and are supplied as a one-piece unit suitable for mounting individual heaters. Flush mounting can be used with any building grade ceiling materials.
- Page 3 Flush Mount Enclosure Dimensions VIEW FROM UNDERNEATH VIEW FROM TOP PART No MODEL “A” (mm) “B” (mm) “C” (mm) THHAC-013 THH2400AR 1526 1468 1464 THHAC-014 THH3200AR 1936 1878 1874...
-
Page 4: Installation Location
It is recommended to use only the provided holes in the ends of the enclosure for mounting. Ensure all clearances detailed in the HEATSTRIP Classic (In-Built Remote) PRODUCT MANUAL are strictly followed. The diagrams below shows the general location constraints. -
Page 5: View From Below
Installation Clearance Dimensions The diagrams below give the minimum installation clearances of the Flush Mount Enclosure. It is recommended to use only the provided holes in the ends of the enclosure for mounting. • The minimum distance between the back of the enclosure and any building material is 50mm. •... -
Page 6: Installation Instructions
Installation Instructions “D” MODEL DISTANCE FROM END Ensure all minimum clearance requirements are met and the TO BRACKET (mm) materials used are compliant to your local building codes. THH2400AR Before installing the FME, ensure the site to be fixed is fully prepared with the hole cut the correct size and the mounting THH3200AR points securely in place. -
Page 7: Maintenance
Safety In operation, this heater is VERY HOT— do not touch any part of the heater while it is turned on. Do not touch any part until 30 minutes after it is turned off. This appliance is not intended for use by persons (including children) with reduced physical, sensory or intel- lectual capabilities, or lack of experience and knowledge, unless they have been given supervision or instruc- tion concerning use of the appliance by a person responsible for their safety. -
Page 8: Warranty Terms And Conditions
12 months from the date of purchase in accordance with the following warranty terms and conditions. Provision of this warranty is subject to: • The HEATSTRIP FME product must be installed in accordance with the Installation Instructions and relevant electrical stand- ards and codes. •...
