Wurth Elektronik ADRASTEA-I User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U
SER MANUAL
A
-I
DRASTEA
2615011136000
V
1.3
ERSION
A
12, 2024
UGUST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADRASTEA-I and is the answer not in the manual?

Questions and answers

Summary of Contents for Wurth Elektronik ADRASTEA-I

  • Page 1 SER MANUAL DRASTEA 2615011136000 ERSION 12, 2024 UGUST...
  • Page 2 *************** MUST READ Check for firmware updates Before using the product make sure you use the most recent firmware version, data sheet and user manual. This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required.
  • Page 3 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Revision history Manual FW version Notes Date version version ADRASTEA- April 2022 Initial release of the manual I_06.006 Added section Adrastea-I GCF Certification . Added section Minimal pin ADRASTEA- May 2023 connections .
  • Page 4 I_06.006 Footprint . 2024 Added information about LTE antenna in section Antenna solutions . Updated General labelling information for Adrastea-I in section General labeling information . Added Information for explosion protection for Adrastea-I in section Information for explosion protection .
  • Page 5 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Abbreviations Abbreviation Name 3GPP 3rd Generation Partnership Project Analog-to-Digital Converter ASCI Advanced Speech Call Items Access Point Name Binary Coded Decimal Clock signal Deep Hibernation EJTAG Embedded Joint Test Action Group GLONASS Global Navigation Satellite System...
  • Page 6 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Subscriber Identity Module Serial Peripheral Interface Software Version Number Terminal Adaptor TCXO Temperature Compensated Crystal Oscillator Terminal Equipment TTFF Time To First Fix UART Universal Asynchronous Receiver/Transmitter User Equipment UICC Universal Integrated Circuit Card...

  • Page 7: Table Of Contents

    1 Introduction Adrastea-I GCF Certification ......Adrastea-I Deutsche Telekom Certification ..... 10 Benefits of Deutsche Telekom Certified Module .
  • Page 8 5 Functional description Adrastea-I State Transition ......47 Adrastea-I Power Saving Modes ......48 5.2.1 DH0 Mode .
  • Page 9 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 7 Design in guide Advice for schematic and layout ......71 Dimensioning of the micro strip antenna line .

  • Page 10: Introduction

    LTE-Cat.M or LTE-Cat.NB-IoT. The Adrastea-I EV-Kit and "Adrastea Commander" tool ([1]) allow getting started with the mod- ule and testing its functionalities. The EV-Board can be connected to an USB port of a PC. The EV-Board also represents our reference design. For further information, please refer to the EV-Board manual [2].

  • Page 11: Adrastea-I Gcf Certification

    User manual Adrastea-I 1.1 Adrastea-I GCF Certification Adrastea-I is GCF certified module. Major advantage with GCF certified module integrated in end IoT application is that it reduces efforts for industry and operator specific certifications. However, customer shall check certification requirements with network operator before com- mercial deployment of IoT devices.

  • Page 12: Adrastea-I Deutsche Telekom Certification

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 1.2 Adrastea-I Deutsche Telekom Certification Adrastea-I is certified by Deutsche Telekom. Würth Elektronik Ravindra Singh Forward to Miguel Rodriguez (Deutsche Telekom AG) From Contact E-Mail: miguel.rodriguez@telekom.de February, 2022 Date Limited Certification for Würth Elektronik ADASTREA-I Communication Module Subject Dear Würth Elektronik Team,...

  • Page 13: Benefits Of Deutsche Telekom Certified Module

    Network Operator Certification: Vodafone, Deutsche Telekom, AT&T etc. Figure 4: Normal Cellular Certification Process Pre-Certified Adrastea-I module from Deutsche Telekom brings the following key advantages: It enables integration to end device without further end device label Industry specific Certification (i.e. GCF) and Network Operator Certification (Deutsche Telekom).
  • Page 14 (IoT SIM cards) from Deutsche Telekom. To get the certification benefit, the customer must use connectivity (IoT SIM cards) from Deutsche Telekom To do on device level, Adrastea-I offers CE declaration Figure 5: Benefits of Deutsche Telekom Certified Module Order code 2615011136000 Version 1.3, August 2024...

  • Page 15: Connectivity

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 1.4 Connectivity IoT SIM cards can be ordered from WE-DTAG Connectivity Portal https://iotcreators.com/wuerth/ . Strong partnership of Würth Elektronik eiSos and Deutsche Telekom offers many advantages for message based connectivity: End device label certification Industry specific Certification and Network Operator Cer- tification is not required.

  • Page 16: Module Key Features

    Module Interfaces - SPI Master - GPIO - ADC - JTAG Adrastea-I includes a fully integrated global navigation satellite Integrated GNSS system solution that supports GPS and GLONASS positioning system. User MCU is exclusively for user application software: - ARM Cortex-M4...

  • Page 17: Block Diagram

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 1.6 Block diagram Adrastea-I Shielding 32.768 kHz 26 MHz Crystal VTCXO SIM, UART, I2C, ALT1250 SoC SPI, JTAG, GNSS GNSS RF GPIO Antenna User MCU ARM Cortex M4 LTE Processor Power Power supply...

  • Page 18: Electrical And Radio Specifications

    User manual Adrastea-I 2 Electrical and Radio Specifications Unless otherwise stated, all the values given in the manual were measured on the Adrastea-I EV-Board under the following conditions: T = 25 °C and powered via 5 V/1A Power Jack. The voltage regulator of the EV-Board regulates the connected voltage 5 V down to 3.6 V and sup-...

  • Page 19: Lte-Cat.nb-Iot Mode

    Table 5: NB-IoT Current consumption 2.3 LTE Radio Characteristics Module performance is based on the quality of the RF link from LTE network to the Adrastea-I module. The following factors and tasks are critical for the performance of the Adrastea-I module: External LTE antenna for signal reception from LTE network.

  • Page 20: Lte Supported Bands

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 2.3.1 LTE Supported Bands 2.3.2 LTE-Cat.M Mode Band Transmit Band (Tx) Receive Band (Rx) Unit 1850 - 1910 1930 - 1990 1710 - 1785 1805 - 1880 1710 - 1755 2110 - 2155...

  • Page 21: Rf Receiving Sensitivity

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 2.3.4 RF Receiving Sensitivity Unless noted otherwise, the Adrastea-I evaluation boad is in static mode, values were mea- sured with Rohde and Schwarz CMW500 equipment. 2.3.5 LTE-Cat.M Reference sensitivity Band Band Width Value Unit 1.4 MHz...

  • Page 22: Maximum Output Power

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 2.3.7 Maximum Output Power Unless noted otherwise, the Adrastea-I evaluation boad is in static mode, values were mea- sured with Rohde and Schwarz CMW500 equipment. 2.3.8 LTE-Cat.M Maximum Output Power Band Band Width...

  • Page 23: Gnss Radio Characteristics

    The device key target is to allow GNSS positioning for asset management applications where infrequent position updates are required. The Adrastea-I GNSS shares the RF Rx path with the LTE modem and, therefore, cannot operate in parallel with LTE data transfer. Hence this GNSS is not suitable for products that inherently require this co-existence, LTE connection and GNSS tracking.

  • Page 24: Gnss: Rx Sensitivity

    fix, once the module is powered up or returns from a period of signal blockage. GNSS update rate for Adrastea-I is 1 Hz (once per second). Depending on the type of start (cold or hot), a different TTFF performance is given below.

  • Page 25: Gnss: Position Accuracy

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 2.4.5 GNSS: Position Accuracy Parameter Test Condition Value Unit GPS-GLONASS, Position Accuracy Power Level = -120dBm Table 15: GNSS Position Accuracy Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 26: Pinout

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 3 Pinout RESERVED RESERVED RESERVED RESERVED AT_IN RESERVED RESERVED WAKEUP AT_OUT RESERVED /RESET UART1_CTS EJ_TCK UART1_TX RESERVED UART1_RX STATUS EJ_TDO EXT_ALARM UART1_RTS EJ_TDI ADC1/GPIO2 I2C0_SCL ADC0/GPIO1 EJ_TMS RESERVED I2C0_SDA EJ_TRST UART0_RTS UART2_RTS UART0_CTS...
  • Page 27 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Designation Description Number Supply Negative Supply Voltage Supply Negative Supply Voltage Supply Power supply for module Supply Power supply for module Supply Power supply for module AT_IN Input Anti-tamper input WAKEUP Input Wakeup active high...
  • Page 28 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Designation Description Number Power supply for FEM VDD_FEM Supply (Front End Module) Power supply for FEM VDD_FEM Supply (Front End Module) Power supply for FEM VDD_FEM Supply (Front End Module) Supply Negative supply voltage...
  • Page 29 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Designation Description Number Reserved (Shall be sol- RESERVED – dered but not connected.) UART2 Request to Send UART2_RTS Output (CLI port) Auxiliary Analog to Dig- ADC1/GPIO2 Input/Output ital Converter Input/Pro- grammable GPIO Supply...
  • Page 30 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Designation Description Number MCU_SPIM1_MISO/ SPIM1_MISO/GPIO39 Input/Output Programmable GPIO SIMCLK Output SIM Clock MCU_SPIM1_CLK/ SPIM1_CLK/GPIO41 Input/Output Programmable GPIO SIMRST Output SIM Reset Reserved (Shall be sol- RESERVED – dered but not connected.) SIMIO Input/Output...

  • Page 31: Module Power Up

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Designation Description Number Supply Negative supply voltage Supply Negative supply voltage Supply Negative supply voltage Supply Negative supply voltage Supply Negative supply voltage Supply Negative supply voltage Supply Negative supply voltage Table 20: Pinout4 3.1 Module Power Up...

  • Page 32: Module Power Down

    RTC starts Retention DCDC Core FLASH Figure 8: Adrastea-I Power up Sequence 3.2 Module Power Down Power down sequence of the regulators will occur in following conditions: Turn off VDD. Shutdown is requested by /RESET pin pulled to low. 3.3 Module Reset Module reset will occur in following conditions: Perform power cycle - Turn off/on VDD and power up the device from reset state.

  • Page 33: Wakeup Pin

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 3.4 WAKEUP pin This pin can be used to immediately wake up the module when being in low power state. This pin allows the module to get out of sleep mode when pulled HIGH.

  • Page 34: Ext_Alarm Pin

    Please refer to our hardware layout recommendations (chapter 7 ). 3.10 VBACKUP and VCAP pins Adrastea-I supports a battery backup mechanism which allows seamless replacement of a weak battery. The battery should be replaced after the device is placed in DH0 state, and only when the RTC circuitry is operational, and is applied by VRTC.

  • Page 35: Vcap Pin

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 3.10.1 VCAP pin The capacitor value should be large enough to keep the VCAP supply voltage above 1.8 V for as long as it takes for the battery to be replaced. Equation 1 should be used for calculating the...

  • Page 36: Digital Io Pins Specifications

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 3.11 Digital IO Pins Specifications These characteristics are applicable for VDDIO in the 1.7V - 1.9V range. Parameter Min. Max. Unit Input LOW Level, input and I/O pins 0.3 x VDDIO Input HIGH Level, input and I/O pins 0.7 x VDDIO...

  • Page 37: Module Interfaces

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 4 Module Interfaces Adrastea-I interfaces and specific pin connections for different interfaces are described in this chapter. 4.1 UART Interface Adrastea-I supports 3 UART interfaces. UART Number Description UART0 MCU UART, this interface is used for AT Commands.

  • Page 38: Uart0 Pin Interface

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Flow control is needed for firmware upgrade. UART communication is not possible when Adrastea-I is in deep hibernate mode (DH0, DH1 and DH2). 4.1.2 UART0 Pin Interface Electrical Designation Description Number Characteristic UART0_RTS...

  • Page 39: Uart2 Pin Interface

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Electrical characteristics (operation voltage) of UART1 pins are 1.8 V. 4.1.4 UART2 Pin Interface Electrical Designation Description Number Characteristic UART2_RTS Output UART2 Request to Send (CLI port) 1.8 V UART2_CTS Input UART2 Clear to Send (CLI port) 1.8 V...

  • Page 40: Uart0 Host Interface

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Adrastea-I Host UTXD UTXD controller URXD URXD Figure 9: UART0 Host Interface Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 41: Spi Interface

    User manual Adrastea-I 4.2 SPI Interface The SPI interface is available when using a customized firmware. It is not implemented within the Adrastea-I default MCU firmware. 4.2.1 SPIM Pin Interface Electrical characteristics (operation voltage) of SPIM pins are 1.8 V.

  • Page 42: Spim Connection

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Device (SPI Slave) Adrastea (SPI Master) SPIM_MOSI SPIM_MISO SPIM_CLK SPIM_EN Figure 10: SPIM Connection Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 43: I 2 C Interface

    User manual Adrastea-I 4.3 I C Interface Adrastea-I provides an I C interface with clock rate up to 400 kbps. Its operation voltage is 1.8 V. This interface is enabled but connecting to the external device is subjected to a customized firmware and not supported by the default firmware.
  • Page 44 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Device Adrastea-I I2C_SDL I2C_SDL I2C_SDA I2C_SDA external pull-up resistors External 1.8V Figure 11: I C Connection Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 45: Adc Interface

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 4.4 ADC Interface Adrastea-I includes two auxiliary A/D converters to sense external analog inputs. Electrical characteristics (operation voltage) of ADC pins are 1.8 V. ADC Interface Description Max. Unit Auxiliary Analog to digital...

  • Page 46: Adc Pin Interface

    Auxiliary Analog to Digital Converter Input ADC0/GPIO1 /Programmable GPIO Table 34: ADC Pin Interface 4.5 SIM Interface Adrastea-I supports 1.8 V SIM Cards. 4.5.1 SIM Pin Interface Electrical characteristics (operation voltage) of SIM pins are 1.8 V. Pin Number Designation...

  • Page 47: Rf Interfaces

    (DEBUG_SEL). The DEBUG_SEL has an internal Pull Down by default. Adrastea-I has an internal PD for EJ_TRST, as it is a very sensitive line (in case it will toggle high the processor will enter debug mode), we suggest not keeping it unconnected but to connect it to an external 10K ohm PD.

  • Page 48: Gpio Pin Information

    Table 38: GPIO Pin Information These GPIO pins are available when using a customized MCU firmware. These are not implemented within the Adrastea-I default MCU firmware. 1. SW can configure these pins in different state for DH2. 2. There is ESD protector in ALT1250. During DH0/DH1, it should not have any PU externally to avoid current leakage.

  • Page 49: Functional Description

    User manual Adrastea-I 5 Functional description The Adrastea-I LTE-M/NB-IoT module is intended to be used as a radio sub-system in order to provide LTE-M/NB-IoT communication capabilities to the system. The Adrastea-I modem firmware is 3GPP Release 13 compliant, which is upgradable to Release-14.

  • Page 50: Adrastea-I Power Saving Modes

    User manual Adrastea-I 5.2 Adrastea-I Power Saving Modes This section summarizes the various low power operating modes of the Adrastea-I module. The Adrastea-I selects the described power modes according to the the maxi- mum allowed chip power mode configuration. The currently configured power mode can be checked with AT command: at%getacfg="pm.conf.max_allowed_pm_mode"...

  • Page 51: Dh2 Mode

    Wakeup event initiates a boot flow. This mode is similar to DH1; however, it also enables output IOs to latch and wakeup from digital inputs. Adrastea-I is set by default in DH2 state. 5.2.4 DH0 Mode Setting 1. Check whether the DH0 state is configured at%getacfg="pm.conf.max_allowed_pm_mode"...
  • Page 52 7. The "sleepSet enable" command is used to enable MCU shutdown state. >>sleepSet enable Configured to Shutdown mode, duration 0ms After following the above steps, the Adrastea-I module will now be in DH0 state and the MCU is shutdown. Order code 2615011136000 Version 1.3, August 2024...

  • Page 53: Dh1 Mode Setting

    2. If the DH1 state is not already configured, configure the module to DH1 state with below AT command. AT+CFUN=0 at%setacfg="pm.conf.max_allowed_pm_mode","dh1" 3. Reset the Adrastea-I. 4. Turn off the RF with the below AT command. AT+CFUN=0 5. Enter "CTRL+D" to close the CLI.

  • Page 54: Dh2 Mode Setting

    7. The "sleepSet enable" command is used to enable MCU shutdown state. >>sleepSet enable Configured to Shutdown mode, duration 0ms After following the above steps, the Adrastea-I module will now be in DH1 state and the MCU is shutdown. 5.2.6 DH2 Mode Setting 1.
  • Page 55 7. The "sleepSet enable" command is used to enable the MCU shutdown state. >>sleepSet enable Configured to Shutdown mode, duration 0ms After following the above steps, the Adrastea-I module will be in DH2 state and the MCU is shutdown. Order code 2615011136000 Version 1.3, August 2024...

  • Page 56: Gnss Receiver

    GLONASS 5.3.2 GNSS Co-existence with LTE Modem The Adrastea-I GNSS shares the RF Rx path with the LTE modem and, therefore, cannot operate in parallel with LTE data transfer. Hence this GNSS is not suitable for products that inherently require this co-existence, LTE connection and GNSS tracking.
  • Page 57 Fill the Sony MCU access request form: https://forms.office.com/r/TZbT1FimMA Important to fill in Module vendor "Wurth Elektronik" at 6 in the link above. Sony receives and will process the request. Sony will provide 7 digit registration number to email id provided in above form.

  • Page 58: Adrastea-I: Sony Mcu Portal Registration

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 13: Adrastea-I: Sony MCU portal registration Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 59: Adrastea-I: Sony Mcu Portal Access

    Click on "Develop->IoT->Sony’s Altair Development Portal". Figure 14: Adrastea-I: Sony MCU portal Access Adrastea-I MCU is verified with Sony MCU SDK version 2.1. Refer documentation for MCU SDK version 2.1. To access documentation of SDK version 2.1 click below link (Note: Login into portal is required to access below link).

  • Page 60: Quick Start Guide

    LTE-M/NB-IoT module into operation. The EV-Kit has external GNSS and LTE antennas. Please refer to the [2] for detailed information. 6.1 Minimal pin connections The following image shows the steps to be performed to integrate the Adrastea-I into a custom end device. VDD/VDD_FEM...

  • Page 61: Prerequisites

    If the module has to be connected to a PC, a converter (TTL to RS-232 or TTL to USB) has to be used. See chapter Pinout for details on all pins. Please refer to the Adrastea-I EV-Board schemes for a Reference design .

  • Page 62: Adrastea Commander

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I GNSS satellites in view GNSS Antenna Adrastea-I Antenna Adrastea-I Evaluation USB Cable Board LTE Base station Adrastea Commander running on PC Figure 16: Adrastea Commander Figure 17: Adrastea Commander Order code 2615011136000 Version 1.3, August 2024...

  • Page 63: Taking Into Operation

    Otherwise, a terminal program (like "PuTTY" or "Tera Term" for Windows) has to be run and the corresponding COM port has to be opened using the default settings of the mounted Adrastea-I module. 5. Press the reset button on the EV-Board to ensure a clean start-up of the module. See figure 19 .

  • Page 64: Miniconsole Start View - Adrastea Commander

    Figure 19: MiniConsole start view - Adrastea Commander The "map" command is required before sending AT commands to modem. When the AT Command UART port is opened, the Adrastea-I output console displays: %SCMNOTIFYEV:"ADRASTEA-IReady". 7. Check if the SIM card is detected. Send command MAP follow by the command AT+CPIN?.

  • Page 65: Sim Card Detected - Adrastea Commander

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 20: SIM card detected - Adrastea Commander Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 66: Select Lte-M Or Nb-Iot Mode

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 6.4 Select LTE-M or NB-IoT Mode Adrastea-I can be operated through one of the two available cellular communication technolo- gies: LTE-Cat.M or LTE-Cat.NB-IoT. Two different configurations can be applied for selection of LTE-Cat.M or LTE-Cat.NB-IoT mode.

  • Page 67: Automatic Selection Of Lte-M Or Nb-Iot Mode

    Default configurations of Adrastea-I are as below: at%getacfg=radiom.config.multi_rat_enable true at%getacfg=radiom.config.preferred_rat_list none at%getacfg=radiom.config.auto_preference_mode none Configure Adrastea-I as below for automatic selection of LTE-M or NB-IoT mode: 1. Disable LTE radio: AT+CFUN=0 2. Enable multi-technologies: Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...
  • Page 68 Note: In case of the above configuration, Adrastea-I will scan all the frequencies in the NB-IoT technology first. If Adrastea-I does not find coverage in NB-IoT, it will scan all the frequencies in the LTE-M technology. Because of this frequency scanning process, power consumption in automatic selection process is higher than in manual selection process.

  • Page 69: Register To Network

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I To set default factory configurations follow below commands: at%setacfg="radiom.config.multi_rat_enable",true at%setacfg="radiom.config.preferred_rat_list","none" at%setacfg="radiom.config.auto_preference_mode","none" 6.5 Register to Network The configurations "Select LTE-M or NB-IoT Mode" (see Chapter 6.4 ) should be done before registering to the LTE network.

  • Page 70: Activate Gnss

    AT%CMATT=0 6.6 Activate GNSS This section shows how to enable the GNSS feature of the Adrastea-I module. GNSS cannot co-exist with LTE data transfer. LTE communication has higher priority over GNSS and, therefore, GNSS is automatically shut down once LTE is active (if it was active).
  • Page 71 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 2. Allow unsolicited notifications: AT%IGNSSEV="SESSIONSTAT",1 3. Get available satellites: It is necessary to check that there are at least 4 satellites available with an SNR>25. AT%IGNSSINFO="SAT" %IGNSSINFO: 11 %IGNSSINFO:03,36,294,49 %IGNSSINFO:06,53,263,50 %IGNSSINFO:14,42,180,50 %IGNSSINFO:15,13,042,50 %IGNSSINFO:16,08,251,50...
  • Page 72 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I AT%IGNSSACT=1,1 The following command is used for hot GNSS Start. AT%IGNSSACT=1,2 6. Get fix: AT%IGNSSINFO="FIX" %IGNSSINFO: 2,"11:17:02","04/05/2020","32.195970","34.892572"," 10.500000",1588580222000,1,"0.000000","B" The following AT command is used to stop GNSS functionality: AT%IGNSSACT=0 Order code 2615011136000 Version 1.3, August 2024...

  • Page 73: Design In Guide

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 7 Design in guide 7.1 Advice for schematic and layout For users with less RF experience it is advisable to closely copy the relating EV-Board with respect to schematic and layout, as it is a proven design. The layout should be conducted with particular care, because even small deficiencies could affect the radio performance and...
  • Page 74 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Elements for ESD protection should be placed on all pins that are accessible from the outside and should be placed close to the accessible area. For example, the RF-pin is accessible when using an external antenna and should be protected.

  • Page 75: Dimensioning Of The Micro Strip Antenna Line

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 7.2 Dimensioning of the micro strip antenna line The antenna track has to be designed as a 50 feed line. The width W for a micro strip can Figure 22: Dimensioning the antenna feed line as micro strip be calculated using the following equation: 5.98...

  • Page 76: Wire Antenna

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Keep the antenna as far as possible from large metal objects to avoid electro- magnetic field blocking. The choice of antenna might have influence on the safety requirements. In the following chapters, some special types of antenna are described.

  • Page 77: Antennas Provided By Würth Elektronik Eisos

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 7.3.4 Antennas provided by Würth Elektronik eiSos 7.3.4.1 2600130084 - Hati-I - LTE antenna Figure 23: Hati-I antenna Specification Value Frequency range [MHz] 700 – 2700 Impedance [ ] VSWR 3 / 3.5...

  • Page 78: Reference Design

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 8 Reference design Adrastea-I was tested on the EV-Board which serves as reference design. Further information concerning the use of the EV-Board can be found in the manual of the Adrastea-I EV-Board [2].

  • Page 79: Schematic

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 8.1 Schematic Figure 24: Circuit diagram 1 Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...
  • Page 80 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 25: Circuit diagram 2 Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...
  • Page 81 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 26: Circuit diagram 3 Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...
  • Page 82 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 27: Circuit diagram 4 Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...
  • Page 83 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 28: Circuit diagram 5 Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 84: Layout

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 8.2 Layout PCB edge Figure 29: Assembly diagram Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 85: Top Layer (Upper Left), Second Layer (Upper Right), Third Layer (Bottom Left), Fourth Layer (Bottom Right)

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I Figure 30: Top layer (upper left), second layer (upper right), third layer (bottom left), fourth layer (bottom right) Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 86: Manufacturing Information

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 9 Manufacturing information 9.1 Moisture sensitivity level This wireless connectivity product is categorized as JEDEC Moisture Sensitivity Level 3 (MSL3), which requires special handling. More information regarding the MSL requirements can be found in the IPC/JEDEC J-STD-020 standard on www.jedec.org.

  • Page 87: Cleaning

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I by the customer at their own risk. Rework is not recommended. –5°C Max. Ramp Up Rate Max. Ramp Down Rate Preheat Area s max s min Time 25°C to Peak Time Figure 31: Reflow soldering profile After reflow soldering, visually inspect the board to confirm proper alignment...

  • Page 88: Potting And Coating

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 9.2.3 Potting and coating If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the component. Expansion could damage components. We recom- mend a manual inspection after potting to avoid these effects.

  • Page 89: Safety Recommendations

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 9.4 Safety recommendations It is your duty to ensure that the product is allowed to be used in the destination country and within the required environment. Usage of the product can be dangerous and must be tested and verified by the end user.

  • Page 90: Physical Specifications

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 10 Physical specifications 10.1 Dimensions Dimensions 13.4 * 14.6 * 1.85 mm Table 40: Dimensions Tolerances: see chapter 10.3 10.2 Weight Weight 0.80 g Table 41: Weight Tolerance: 0.15 g Order code 2615011136000 Version 1.3, August 2024...

  • Page 91: Module Drawing

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 10.3 Module drawing 12,8 ±0,2 13,4 ±0,3 Figure 32: Module dimensions [mm] Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 92: Footprint

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 10.4 Footprint 1,66 75 68 73 44 47 0,89 12,59 Figure 33: Footprint and dimensions [mm] Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 93: Marking

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 11 Marking 11.1 Lot number The 15 digit lot number is printed in numerical digits as well as in form of a machine readable bar code. It is divided into 5 blocks as shown in the following picture and can be translated according to the following table.

  • Page 94: General Labeling Information

    In case of small labels, additional certification marks are placed on the label of the reel. The information on the label are fixed. Only the serial number changes with each entity of the radio module. For Adrastea-I the label is as follows: Model: ADRASTEA-I WE product name...

  • Page 95: Information For Explosion Protection

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 12 Information for explosion protection In case the end product should be used in explosion protection areas the following information can be used: The module itself has no internal fuse. The maximum output power of the module is 25.7 dBm.

  • Page 96: Regulatory Compliance Information

    RED directive 2014/53/EU of the European Union (EU). The Adrastea-I can be operated without notification and free of charge in the area of the Euro- pean Union. However, according to the RED directive, restrictions (e.g. in terms of duty cycle or maximum allowed RF power) may apply.

  • Page 97: Eu Declaration Of Conformity

    74638 Waldenburg This declaration of conformity is issued under the sole responsibility of the manufacturer. Object of the declaration: Adrastea-I The object of the declaration described above is in conformity with the relevant Union har- monisation legislation Directive 2014/53/EU and 2011/65/EU with its amending Annex II EU 2015/863.

  • Page 98: References

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 14 References http://www.we-online.com/ [1] Würth Elektronik. Adrastea Commander. Adrastea-Commander . [2] Würth Elektronik. ADRASTEA-I EVALUATION BOARD MANUAL. https://we-online. com/katalog/en/manual/2615029236001 . Order code 2615011136000 Version 1.3, August 2024 www.we-online.com/wcs...

  • Page 99: Important Notes

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I 15 Important notes The following conditions apply to all goods within the wireless connectivity and sensors product range of Würth Elektronik eiSos GmbH & Co. KG: General customer responsibility Some goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas.

  • Page 100: License Terms

    WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I provided information related to their accuracy, correctness, completeness, usage of the products and/or usability for customer applications. Information published by Würth Elektronik eiSos GmbH & Co. KG regarding third-party products or services does not constitute a license to use such products or services or a warranty or endorsement thereof.
  • Page 101 WIRELESS CONNECTIVITY & SENSORS User manual Adrastea-I The incorporated firmware created by Würth Elektronik eiSos is and will remain the exclusive property of Würth Elektronik eiSos. Firmware update(s) You have the opportunity to request the current and actual firmware for a bought wireless connectivity product within the time of warranty.
