INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To prevent electric shock, switch off the mains power supply until installation is complete and AC input power is
supplied to this product.
2. This product requires an unswitched AC power supply of 120-277V, 50/60Hz.
3. Make sure all connections are in accordance with the National or Canadian Electrical code and any local
regulations.
4. To reduce the risk of electrical shock, disconnect both normal power, emergency power supplies and unit
connector of this product before servicing.
5. For emergency operation of LED, incandescent, fluorescent fixtures and screw-base lamps.
6. The product is UL Listed for field installation, and use with grounded, Listed, damp location rated fixtures.
7. Use this product in 0°C minimum, 50°C maximum ambient temperatures (Ta). It can provide minimum 90 minutes
illumination under the emergency mode.
8. This product is suitable for use in dry or damp locations. Do not use outdoors. Do not mount
it near gas, heaters, air outlets or other hazardous locations.
9. Do not attempt to service the batteries. A sealed, non-maintenance battery is used that is not field replaceable.
Contact the manufacturer for information or service.
10. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition and void
warranty.
11. Do not use this product for other than intended use.
12. Installation and service should be performed by qualified service personnel.
13. This product should be mounted in locations and at heights where it will not readily be subjected to tampering by
unauthorized personnel.
THIS PRODUCT CONTAINS A RECHARGEABLE LI-ION BATTERY.
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Li-ion
116 Ryan Patrick Dr. Salisbury, NC 28147 | (800) 223-0853 | www.shatrshield.com
MIP-100
MINI INVERTER PACK
BC
Advertisement
Summary of Contents for Shat-R-Shield MIP-100
- Page 1 MIP-100 MINI INVERTER PACK INSTALLATION AND OPERATING INSTRUCTIONS IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS 1. To prevent electric shock, switch off the mains power supply until installation is complete and AC input power is supplied to this product.
- Page 2 230V/50Hz 230V/50Hz 277V/60Hz 277V/60Hz 2. INSTALLING THE MIP-100 The MIP-100 can be mounted inside or outside (nearby or on top of *) the luminaire. INSIDE THE LUMINAIRE OUTSIDE THE LUMINAIRE OUTSIDE THE LUMINAIRE One 7/8" (22mm) hole for conduit connector for MIP-100...
- Page 3 CAUTION: DO NOT MATE BROWN WIRE UNIT CONNECTOR UNTIL INSTALLATION IS COMPLETE AND AC POWER IS SUPPLIED. 1. The MIP-100 requires an unswitched AC power supply of 120-277 volt, 50/60Hz. 2. Refer to the wiring diagrams below. Make connections in the following order 1 2 3 4 5 6 7 3.
- Page 4 MIP-100 automatically switches to emergency power, operating the lighting load at rated emergency power. During power failure, the LED test switch will be off. When the AC power is restored, the MIP-100 switches the system back to normal mode of operation and resumes battery charging.
