  • Page 1 USER MANUAL SA40 www.esslsecurity.com...

  • Page 2: Table Of Contents

    Table of Contents INSTALLATION DIAGRAMS ......................... 6 WIRING ..............................6 BASIC CONCEPTS ..........................9 ....................................9 ESCRIPTION OF ......................................9 ATEGORIES ......................................10 ATEGORIES ...................................... 10 IRING EFINITION OPERATIONS ............................10 APPENDIX 1: FAQ ............................16 APPENDIX 2: PACKING LIST ........................16...

  • Page 3: Installation Diagrams

    Installation Diagrams Place the side of the rear hanging plate with screw holes downward In the arrow directions shown Align the screw holes on the rear Sort out and connect the cables, above, remove the screws, and hanging plate with the holes drilled and install the device onto the remove the rear hanging plate from on the wall, and x the rear hanging...
  • Page 4 (1) The device and the lock share the power supply, as shown in Figure 1-1: = 12 V, I ≥ I Note: U , and the lock is close to the device. LOCK DEVICE LOCK Power on the NC lock Power on the NO lock Figure 1-1 (2) The device and the lock do not share the power supply, as shown in Figure 1-2:...
  • Page 5 (3) Connect the power supply. The device uses a DC 12V power supply and external cables are connected directly to the main board. The operating current is equal to or less than 200mA, and the standby current is equal to or less than 150mA.

  • Page 6: Basic Concepts

    Basic Concepts The following lists some basic concepts to help you quickly understand functions and operation methods of the all-in-one device. Description of Keys Enter the administrator password or directly swipe the administrator card to enter the administrator settings mode. Description Modify the administrator password or set the administrator card Add a card-based user...

  • Page 7: User Categories

    based users state. When the deletion card is directly wiped, it enters the batch deleting card- based users state. Addition card This is used to add user cards. Deletion card This is used to delete user cards. User Categories Category Description Card-based user This category of users can open the door only by swiping the card.
  • Page 8 2. Initial Password Item Description Administrator The default initial password is 1234. The administrator password must password contain 1-8 digits. General door The default initial password is 8888. This password must contain 4-6 digits opening and it is a general password set by the administrator for opening the door. password No default password is set.
  • Page 9 When the administrator card is directly swiped once, the access control device enters the administrator mode. When the administrator card is swiped twice, the door sensor switches between the NO and NC modes. When the addition card is directly wiped, it enters the batch adding user cards state. When the deletion card is directly wiped, it enters the batch deleting user cards state.
  • Page 10 For example: *#12344123456# (You can consecutively enter the password to delete multiple users.) Press *#administrator password4swipe the card (You can consecutively swipe the card to delete multiple users.) For example: *#12344swipe the card (You can consecutively swipe the card to delete multiple users.) Press *#administrator password4enter the decimal card ID# (You can consecutively enter the decimal card IDs to delete multiple users.)
  • Page 11 Card-and-password users: Press *#administrator password6swipe the card new password of 4- 6 digits# For example: *#12346swipe the card123456 # Note: You can perform operations consecutively in administrator state and press * to exit the state. 15. Set Door Opening Delay Time Press *#administrator password71enter the delay time# For example: *#1234713s# Note: The door opening delay time is 0-60s.
  • Page 12 21. Set Door Sensor Alarm Switch Press *#administrator password720/1 (0: o ; 1; on) For example: *#1234720/1 22. Set Switch for Alarm for Pressing a Key by Mistake Press *#administrator password780/1 (0: o ; 1: on) For example: *#1234780/1 Note: The alarm for pressing a key by mistake is enabled by default.

  • Page 13: Appendix 1: Faq

    Appendix 1: FAQ Solution Check whether your card has been registered. Failed to open the door Check whether the wiring is correct. by swiping the card Check whether the access control device is in the correct mode. Check whether the card category is correct or whether the card is damaged.
