- Page 1 User’s Operating Instructions Baxi System 100 HE Plus Wall Mounted Powered Flue Condensing Gas Fired Central Heating Boiler Please keep these instructions safe. Should you move house, please hand them over to the next occupier.
-
Page 2: Natural Gas
Notified Body 0087. success. Product/Production certified by: Notified Body 0086. We hope you get a satisfactory service from Baxi. If not, please let us know. For GB/IE only. Baxi is a BS-EN ISO 9001 Accredited Company This product has an energy rating (A) on a scale of A to G. -
Page 3: This Appliance Must Be Earthed
Safe Installation This appliance must be installed in accordance with the manufacturer’s instructions and Baxi declare that no substances harmful to health are the regulations in force. Read the instructions fully before installing or using the contained in the appliance or used during appliance appliance. -
Page 4: Frost Protection
2.0 Introduction Introduction 1. Your Baxi System 100 HE Plus is a high efficiency condensing boiler, providing central heating for your home and domestic hot water. 2. Due to the high efficiency and the resulting low flue gas temperature a white plume of condensate will be emitted from the flue outlet terminal. -
Page 5: Boiler Controls
3.0 Boiler Controls Temperature Control Central Heating 1. The lower the flow temperature is set to, the higher the efficiency the boiler will operate at. The flow temperature can be adjusted between approx 55 °C minimum and approx 82 °C maximum by turning the Flow Temperature Control Knob (Fig. -
Page 6: Care Of The Boiler
Spare Parts 1. Any repairs to the boiler will usually be the responsibility of the Installer during the guarantee period after which spare parts may be obtained through approved Baxi stockists if required. Refer to Page 3 for the definition 2. -
Page 7: Servicing Your Appliance
4.0 Care of the Boiler Guarantee 1. Your Baxi System 100 HE Plus is designed and produced to meet all the relevant Standards. 2. Baxi provide a 12 month guarantee on the boiler. The guarantee operates from the date installation is completed for the customer who is the original user. -
Page 8: Operation Of Safety Devices
5.0 Safety Devices Operation of Safety Devices 1. Your Baxi System 100 HE Plus is fitted with safety devices which shut down the appliance if: a) the system overheats. b) the condensate drain is blocked. c) there is no gas to the boiler. - Page 9 6.0 Clearances 490mm 5mm Min 5mm Min Clearances around the Boiler 1. The minimum clear spaces needed around the boiler measured from the casing are as follows: 200mm 200mm Bottom 200mm Both sides Front 500mm (For Servicing) (In Operation) 2. These areas must not be obstructed in any way. Blocking the clearance spaces may result in the boiler overheating and damage may occur.
-
Page 10: Check List
7.0 Fault Finding/Emergency Check List 1. If a fault develops, or is suspected, call a Competent Person as soon as possible. 2. Go through the following check list before you make contact. Is the electricity supply on ? Is the Red “Fault” light illuminated ? If the boiler fails to light or the boiler is running and the gas is turned off, the light will start to flash red. - Page 11 8.0 Notes...
- Page 12 When contacting Baxi Potterton please have the following information to hand: Appliance Name Model Number Serial Number A label giving these details is situated on the rear of the lower door panel attached to the users operating instruction label. Users Operating...
