Summary of Contents for Reece Thermann TH160GLG
- Page 3 Important Safety Instructions Introduction Water Heater Operations Overview Time and Block Out Setting Considering A Service Call? Technical Data - Heat Pump Unit 11-12 Technical Data - Tank Water Supply Quality Warranty Policy...
- Page 4 Note: The information contained in this owner's manual must be read carefully and understood before proceeding to operate the water heater. Symbol indicates potentially hazardous condition which, if not avoided, may result in serious injury or death. Symbol indicates potentially hazardous condition which, if not avoided, may result in injury or damage to property.
- Page 5 WARNING This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 The Thermann Split Heat Pump is designed to efficiently and effectively heat potable water in a domestic dwelling. The split heat pump is supplied as a kit, consisting of a heat pump unit that uses CO as the refrigerant and a storage tank that stores heated water.
- Page 7 Storage Tank Hot Water Return Outlet Hot Water Return Heated Water To Tank PTR Valve Expansion Control Temperature 850kPa Heat Pump Unit Valve Control Device (Where Required) Tempred Water Pressure Limiting Valve (Where Required) Water Water Flow Supply Supply Cold Water flow To Heat Pump Unit Isolation Valve Cold Water...
- Page 8 WARNING The piping cover must only be removed by a qualified person. The clock and block-out timer functionalities must only be set by a qualified person. CURRENT TIME SETTING This product contains a built-in clock as part of the water heating cycle logic and refers to the current time.
- Page 10 Water discharged from the PTR valve may be extremely hot. Stand clear of the point of discharge and ensure the lever is operated gently to reduce splashing of the discharged water.
- Page 15 REECE CUSTOMER CARE For after sales assistance and enquiries, please call Ph: 1800 080 055...
- Page 16 AUSTRALIAN CONSUMER LAW (ACL) Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Need help?
Do you have a question about the Thermann TH160GLG and is the answer not in the manual?
Questions and answers
BUILDING CERTIFIER NEEDS WATER TEMPERATURE 60 DEGREES AT SINK. hOW DO WE GET THE THERMANN HEAT PUMP TEMPERATURE OUT SETTING CHNAGED FROM 57 TO 62 DEGREES.
