Summary of Contents for CyClone Z-020
- Page 1 AZ2000 Z-010 Z-011 Z-020 User's Guide...
- Page 2 General Safety and Personal Safeness Attention: This manual, especially safety instructions, MUST be read and understood completely in detail BEFORE installing, repairing, maintaining, changing accessory, or in use of this Device. Afterward the manual MUST be put at an adequate place where it is easily reachable by any user.
- Page 3 hands and arms. Make sure to keep a safe posture and firm footing. • Do not over-extend your body, take care on a stable balanced body as well as secure footing to control the Device when an unexpected situation happens. •...
- Page 4 Technical Data AZ2000 Z-010 Z-011 Z-020 Air Inlet Range 5.0~7.5 Bar 5.0~7.5 Bar 5.0~7.5 Bar 5.0~7.5 Bar Recommended Air lnlet 6.2 Bar 6.2 Bar 6.2 Bar 6.2 Bar Rotating Speed Range 1,000~8,000 3,000rpm 3500rpm Air Consumption 80~160 NL/min 75 NL/min...
- Page 5 Operating Instruction (For Reference:AZ2000) 1 A qualified and well-trained user is required for the use of this Device. 2 Hold a firm grip on this Device so that your body and arm can resist the counterforce from this Device. 3 Make sure that the cup of this Device filled with diluted and neutral cleaner. 4 Make sure that one end of a hose connected with an air-compressed source and the other end of the hose is plugged into the air-inlet of this Device.
- Page 6 then press the trigger of this Device all the way so that the dust or dirt of the nozzle inside will be removed. 13 If this Device is not in use, please unplug the hose away from the air-inlet of his Device.
- Page 7 4 Push the TIRGGER, making the air pressure returning back to the bottle/cup. In this way the air could circulate fluently. Please note that you have to hold tightly and make the ALUMINUM TUBE no rotating. 5 After using this method, you can see the water flowing from the INNER TUBE without pushing the trigger.
- Page 8 We strongly suggest to use the Device should adapt with the AIR CONDITIONING UNIT. The Air conditioning unit includes 1. Air Filter, 2. Air Regulator, 3. Air Lubricator, and using it could filter the dirt and water, which will not into the pneumatic tools and also could prolong the working life of every pneumatic tool.
