Summary of Contents for DSIC MobileBase DS70

  • Page 1: Ds70 User Manual

    DS70 USER MANUAL Android 11 ISO 9001 Certified Quality Management System...
  • Page 2 Revision History Changes to the original Manual are listed below Date Version Description July 2022 Initial release Aug 2022 Revise images/details...
  • Page 3 While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, DSIC Co., Ltd. can assume to no liability for any errors. Changes and corrections to the information in this document might be incorporated in future release.
  • Page 4: Table Of Contents

    Contents DS70 User Manual ........................1 Safety Instruction ........................6 Chapter 1: Introduction ......................7 Overview of terminal features ..................8 Front View ....................... 8 Back View ........................ 9 Hand Strap Removal and Replacement ..............10 Battery ..........................10 Battery power source ................... 10 Chapter 2: Getting Started .......................
  • Page 5 Emoji ........................28 Use next-word suggestions ................... 28 Chapter 5: Try some apps ......................29 All Apps ........................... 29 Phone ..........................30 Camera ........................... 31 Gallery ..........................32 Contacts .......................... 33 Chapter 6: Settings ........................34 Chapter 7: Accessibility ......................35 Chapter 8: Device Management ....................
  • Page 6: Safety Instruction

    SAFETY INSTRUCTION Read this instruction carefully to keep yourself safe and to avoid loss of property.  Make sure that battery terminals (metal part) should not contact with any conductive materials like a necklace or coin. Also make sure that batteries should not be damaged by teeth or a nail. Impact may cause an explosion of batteries ...
  • Page 7: Chapter 1: Introduction

    CHAPTER 1: INTRODUCTION DS70 is designed with a focus on convenience to provides users with an optimal user experience. Adopting a 5.5-inch display to provide users with excellent visibility with its HD+ resolution, while ergonomic design minimizes fatigue while carrying during the work. This chapter describes the front, back, battery or power adapter of the DS70.
  • Page 8: Overview Of Terminal Features

    Overview of terminal features Front View Receiver LED Indicator Function key (Fn) 5.5 inch HD+ Display Scan button Loud Speaker Micro USB Port (Type C)
  • Page 9: Back View

    Back View Hand belt hook Barcode Scanner Power Button 16MP AF Camera Volume Key (up / down) Battery Lock Lever POGO (Gun trigger) Scan Button Battery Hand belt hook POGO...
  • Page 10: Hand Strap Removal And Replacement

    Hand Strap Removal and Replacement To remove hand strap: 1. Un-screw two points on the top 2. Force to pull out lower loop to upward from the terminal Battery Caution If the Product is wet, do not put it in a device that may heat the terminal (heater, microwave oven, etc.). Heating batteries may cause an explosion, deformation or fault.
  • Page 11: Chapter 2: Getting Started

    CHAPTER 2: GETTING STARTED This chapter will describe how to install and charge battery, mount micro SD card and start up the terminal. To start up the terminal:  Installation Micro SD / SAM / SIM card  Battery Mounting and Operation ...
  • Page 12: Installation Micro Sd / Sam / Sim Card

    Installation micro SD / SAM / SIM card Insert the card carefully as shown in the following illustrations. Make sure the card terminal position before insert the card. Push the back end of the card to fix it at the last step. Card types Insert direction SAM card...
  • Page 13: Battery Mounting And Operation

    European Guideline 2006/66/EC, defective or used battery packs/ batteries, must be collected separately and disposed of in an environmentally correct manner. Batteries no longer suitable for use can be directly returned at DSIC Co., Ltd. PDA Dept. DSIC Bldg. 205-28, Gasan digital 1-ro, Guemchun-gu, Seoul, Korea Tel: +82-2-2107-5178 Fax: +82-2-2107-5128 Email: dsic_pda@dsic.co.kr...
  • Page 14: Connecting Power Source

    Connecting Power Source Connect power, using one of the methods listed below. Caution Verity that the terminal battery is installed prior to connection. If the battery is not properly installed and the wall charger is connected, the terminal may power off and on continuously, preventing proper operation. Note Failure to unplug the wall charger before you remove the battery, can cause damage to the terminal To use mini USB Travel Charger...
  • Page 15: To Use Multi-Slot Cradle

    To use Multi-Slot cradle You can connect cradles for using them as a multi-slot cradle. (Up to 4 cradles) Bumper Installation Install bumper as shown below.
  • Page 16: Operating Power Of The Terminal

    Operating power of the terminal Power on / off Make a long press Power button at the right bottom side of the keyboard. When you turn on your device for the first time, you’ll see a Welcome screen. Choose the language & time you want and touch Start or Start icon. To turn off the device, make a long press Power button and select Power off.
  • Page 17: Organize Your Home Screens

    DS70 navigation buttons At the bottom of DS70 screen, you’ll always find the navigation bar with three buttons: Back Opens the previous screen you were working in, even if it was in a different app. Once you back up to Home screen, you can’t go back any further. Home Opens the central Home screen.
  • Page 18: Touch & Type

    Touch & type To select or activate something, touch it. To type something, such as a name, password, or search terms, just touch where you want to type. A keyboard pops up that lets you type into the field. Other common gestures include: Touch &...
  • Page 19: Chapter 3: Basic Use

    CHAPTER 3: BASIC USE Notifications & settings Notifications alert you to the arrival of new messages, calendar events, and alarms, as well as ongoing events. When a notification arrives, its icon appears at the top of the screen. Icons for Pending notifications appear on the left, and system icons showing things like Wi-Fi signal, mobile carrier signal, or battery strength on the right: TIP: Wi-Fi and mobile signal strength are indicated at the top of the screen by white bars.
  • Page 20: Quick Settings

    Quick Settings Use Quick Setting to easily access Wi-Fi settings, manage display brightness, open the main Settings menu, and more. To open Quick Settings, swipe down from the top of the screen twice with one finger. Data Sync How to Connect with PC 1.
  • Page 21: Wi-Fi

    Wi-Fi Go to Settings > Network & Internet > Wi-Fi You can activate Wi-Fi by touching ON/OFF switch. Connecting to Wi-Fi Access point From the list, select an AP to connect If the AP needs password, enter it to complete the access.
  • Page 22: Bluetooth

    Bluetooth Go to Settings > Connected devices > Connection preferences > Bluetooth. You can activate Bluetooth by touching ON/OFF switch. Pairing via Bluetooth Go to Bluetooth menu and touch Pair new device. After select the device, enter or check PIN number to pair to the device.
  • Page 23: Lock Screen

    Lock screen If a lock is set for your screen, the screen goes dark and locks when the display goes to sleep or if you press the Power button. You can set locks of different strengths using lock settings: 1. Go to Settings > Security > Device Security > Screen lock. 2.
  • Page 24: Nfc (13.56 Mhz)

    NFC (13.56 MHz) Reading NFC Cards To read NFC card, move it close to back of DS70 until it detects the card. (Reading only)
  • Page 25: File Manager

    File Manager Android 11 makes it easy to store and browse through pictures, videos, and other files on your device and attach them to an email, Hangout message, and so on. Location : All app screen > Files File manager helps you to find every file in internal or external memory of device.
  • Page 26: Screenshots

    Screenshots To take a screenshot from DS70: 1. Make sure the image you want to capture is displayed on the screen. 2. Press the Power button and Volume down button simultaneously. The screenshot is automatically saved in your Gallery. TIP: To easily share your screenshot via message, or Bluetooth, and email, swipe down the notification shade and touch the Share icon, and select application you want to share with.
  • Page 27: Chapter 4: Use The Keyboard

    CHAPTER 4: USE THE KEYBOARD Enter & edit text Use the onscreen keyboard to enter texts. Here’s what it looks like on a DS70 device: To make the keyboard go away, touch the Back button at the bottom of screen. Some apps open the keyboard automatically.
  • Page 28: Emoji

    Emoji Android 11 vastly expands the variety of emoji available at your fingertips. Touch and hold the Enter key to display emoji. You will see a panel like this. To move between categories, swipe left or right or touch the symbols in the top row. To type an emoji, touch it: Use next-word suggestions 1.
  • Page 29: Chapter 5: Try Some Apps

    CHAPTER 5: TRY SOME APPS All Apps To see all your apps, touch the All Apps icon in the Favorites tray on any Home screen. This is where you can see all your apps. You can move app icons to any of your Home screens. From All Apps, you can: ...
  • Page 30: Phone

    Phone Make a call, manage your contacts, and see recent calls with Phone app To place a call to one of your contacts: 1. Touch the Phone icon on a Home or All Apps screen 2. To choose someone to call, scroll or search. If the keypad’s in the way, touch the Back button to lower it. 3.
  • Page 31: Camera

    Camera The Camera app lets you take photos and videos. To open Camera:  From the lock screen, swipe the Camera icon.  From the Home screen, touch the Camera icon. The first time you open Camera, you may be asked if you want it to remember photo locations. The shutter and other controls float above the framed image at the bottom of the screen.
  • Page 32: Gallery

    Gallery The Gallery app gives you an easy way to browse pictures and videos you’ve taken with Camera. It also displays screenshots and auto backups from other devices. To open Gallery from the:  Camera app. Touch the thumbnail image at the bottom. ...
  • Page 33: Contacts

    Contacts The Contacts app gives you quick access to everyone you want to reach. To open it, touch the Contacts icon on All Apps screen. When using a new device, you can import contacts via “.vcf” file When you open the Contact app, you can: ...
  • Page 34: Chapter 6: Settings

    CHAPTER 6: SETTINGS Most apps include their own settings, typically available from Menu > Settings on DS70 devices. The fastest way to adjust system settings that you access frequently, such as Wi-Fi or brightness, is through Quick Settings. To open Quick Settings, swipe down from the top of the screen the Settings icon. The Settings app controls the core Android settings for networks, hardware, location, security, language, accounts, and so on.
  • Page 35: Chapter 7: Accessibility

    CHAPTER 7: ACCESSIBILITY To use the accessibility options, open Settings > System > Accessibility. Accessibility settings let you modify your device’s display and sound options, such as increasing the text size, changing the speed at which text is spoken, and more. You can also try magnification gestures which allow you to zoom in and out, as well as temporarily magnify what’s under your finger.
  • Page 36: Chapter 8: Device Management

    Mobilebase products to effectively deploy, use, and manage devices. Main menu EDM features 3 main menus for IT manager. Menu Description Tools for IT administrative DSIC (FOTA, Backup, AutoSetting, KIOST, Dedicated App Barcode Tray, and etc) Device Info & Device Diagnostics & Device info Functional testing Device Security &...
  • Page 37: Barcode Tray

    Barcode Tray To activate Barcode Tray program, touch barcode tray icon at your screen. Scan Test It is to test the barcode, and check the barcode type and data. Barcode Module Setting You can change the setting of the barcode module. Scan Setting You can set how you will scan the barcode such as max scan time / data receive method / prefix or suffix and so on.
  • Page 38 Barcode Module Setting : Setting to enable, or Scan Test disable barcode types. Scan Setting : Setting scanning feature, such as Image Capture : View image and capture the view time out, prefix and suffix, scanner key setting, from the imager scanner notification options and etc.
  • Page 39 Setting Export / Import : Set up barcode Information : Demonstrate the installed barcode configuration by programming, or export the set up scanner to your device and application version to file. information of your barcode scanner. Manual...
  • Page 40: Key Mapping

    Key Mapping It is enabling you to create a shortcut for repeating a sequence of keys or commands. Go EDM Kit > Key Mapper Belows are the list of keys which is programmable to be set as your sequenced key or short cut to execute application.
  • Page 41 3) Or, swipe the screen to left to set sequence. When 4) You can use it to do Macro you select No use, then the key has no function. 6) Press Menu icon to import, export, remove, or 5) To reset the function key, press the icon. Then you reset your key mapping configuration.
  • Page 42: Os Update

    OS Update You shall need to download file as “DS70-r-XXX-user.zip” from the FTP server. Update Instruction Download your OS and install on your device as below Copy the firmware file to the SD card Change the file name as “ds.zip” Input micro SD card into your device WHILE pressing and holding Power key, long press Left Scan key simultaneously to enter OS update screen.
  • Page 43: Fota Update

    Initial Setting Default setting to use FOTA is “Wifi Only” & “Update check Period : 1day”. If you want to change this setting, please move EDM Kit > DSIC FOTA > Menu . You can set according to your usage.
  • Page 44: For It Manager

    Details Company name, or Brand name Profile name ex) Brand : Coca-cola, Nike Company : DSIC, SK hynix Manual or Automatic Manual update is the server asks update when you ask. Type of update Automatic update is the server asks update when there is new released firmware.
  • Page 45 Details about FOTA site Reason of Unenrolled (Failed to update) Even though the server sent the message for FOTA update, sometimes, it isn’t updated. In case the device isn’t turned on In case the device is turned on, but isn’t connected to Wifi/3G In case the wrong OS is delivered.
  • Page 46: Kiosk Mode

    KIOSK MODE Kiosk mode is enabling to lock down unwanted device misuse. It is to control which application and device features can be used by user such as blocking access to games, social media apps and etc. When you allow access to business application apps, KIOSK MODE will ensure that the user cannot access anything other than those allowed application.
  • Page 47 Admin Setting Settings Go to “Setting” Block USB connection Limit access by USB connection Select USB Configuration Choose how to set when PC sync connected. Block Storage Limit access to storages not allowed. Block App install and update Limit installation and update the apps. Access Wi-Fi &...
  • Page 48: Appendix Ⅰ Auto Setting

    APPENDIX Ⅰ AUTO SETTING DS70’s Auto Setting is PC-based program. It can create barcodes and apply the DS70 setting quickly. Below are the functions you can set by Auto Setting. Wifi Set Sound volume Radio Set General Mobile APN Keymap Set Kiosk Set Barcode Set ETC Set...
  • Page 49: Version Select

    Version Select Select the model / GMS or noGMS / Phone or Nohone. List Description Model Select the model. ex) DS70. Select the GMS or NOGMS. (GMS : You can find the Playstore in your Menu) Phone Select the PHONE or NOPHONE. Common Interface You can add the functions you need and create the barcode.
  • Page 50: Autosetting 1 - Wifi Set

    AutoSetting 1 – Wifi Set Specify the wifi setting. When you scan the barcode, the setting will be applied automatically and the defined wifi will be connected. List Description SSID · Duplicate SSID is over-written automatically. · Password cannot be “null” when Security setting is ‘WEP’ or ‘ WPA/WPA2 PSK’ Password ·...
  • Page 51: Autosetting 2 - Sound Volume

    AutoSetting 2 – Sound volume You can control the volume sound or vibration as you need. List Description · Choose Don’t care, Level 1~7 or Vibration System Volume · It includes ring, system and notification Alarm Volume · Choose Don’t care or Level 0~7 Music Volume ·...
  • Page 52: Autosetting 3 - Radio Set

    AutoSetting 3 – Radio Set You can ON/OFF GPS, Bluetooth or Wifi automatically List Description · Choose Don’t care / Enable / Disable Bluetooth · Choose Don’t care / Enable / Disable WIFI · Choose Don’t care / Enable / Disable...
  • Page 53: Autosetting 4 - General

    AutoSetting 4 – General Set time or date. List Description Locale · Choose your Language TimeZone · Choose your local Time zone AutoTime · Set the time automatically. Use Internet time zone. AutoTimeZone · Set the date and time automatically. Use network time. ·...
  • Page 54: Autosetting 5 - Mobile Apn

    AutoSetting 5 – Mobile APN You can set APN automatically. Put the APN information according to your use. List Description Name · Enter the APN Name · Ex) SKT · Enter APN info · Ex) lte.sktelcom.com · Enter only numbers. Max. 3 digits ·...
  • Page 55: Autosetting 6 - Keymap Set

    · Enter Mmsc info Mmsc · Ex) http://omms.nate.com:9082/oma_mms Mms Proxy · Enter Mms Proxy info · Ex) lteoma.nate.com Mms Port · Enter Mms port number · Enter only numbers. Number range is 0~65535 · Ex) 9093 · Choose Auth type – None / PAP / CHAP / PAP_CHAP Auth type ·...
  • Page 56 - You can enter the Key code and search directly · Select the Application from Data list Applications · You can input the Application directly Example : com.dsic.test/com.dsic.test.MainActivity · You can select the application from dialog box. APK Load · The file extension is ‘.apk’...
  • Page 57: Autosetting 7 - Kiosk Set

    · The length of Password is 4~10 digits · Select the Application from the list Apps · You can input the Application directly Example : com.dsic.test/com.dsic.test.MainActivity · You can select the application from dialog box. APK Load · The file extension is ‘.apk’...
  • Page 58: Autosetting 8 - Barcode Set

    AutoSetting 8 – Barcode Set You can import Barcode Tray configuration automatically. First, export the barcode setting file from ‘Setup Export/Import’ menu of Barcode Tray. (ex. SE4500_SETTINGS.xml). Then, apply this setting to other devices by AutoSetting barcode. List Description Path ·...
  • Page 59: Autosetting 9 - Etc Set

    AutoSetting 9 – ETC Set You can configure NTP server. List Description · Enter the NTP. ex : time.google.com...
  • Page 60: Barcode Form

    Barcode Form Select the item you want to create barcode, and click Barcode button. The barcode pops up as below. List Description File · The barcode can be saved or printed Save · Save the barcode image file. You can save as jpg, bmp, gif, or png ·...
