PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING AND/OR OPERATING
GETTING STARTED
We appreciate your purchase of the InVision
Gas Range for RVs. Prior to operating your new
appliance, please read this manual carefully. This
instruction manual contains information for safe
use, installation and maintenance of the appliance.
You will want to keep this manual handy for
future reference. Using the range by following the
directions in this manual will help ensure safe use
and reduce the risk of injury. Please pass on this
manual to future owners of your range.
The manufacturer accepts no responsibility for
any damage caused by not observing these
instructions.
GAS RANGE
17" & 21" Stainless Steel
MODELS:
THE APPLIANCE.
2525 John Weaver Parkway
2525 John Weaver Pkwy, Elkhart, IN 46514 | customerservice.invision@airxcel.com | 574.247.9235
OPERATION and USER'S GUIDE
400-2730
400-2230
Warning: If the instructions in this manual are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
-Do not store or use gasoline or other flammable
vapors or liquids near this or any appliance.
-WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance
• Do not touch any electrical switch
• Do not use any phone in your recreational vehicle
• Clear the recreational vehicle of all occupants
• Turn off the gas supply tank valve(s) or main gas
supply
• From a location away from the gas smell,
Immediately call your gas supplier for instructions
• If you cannot reach your gas supplier, call the fire
department
-Have the gas system checked and leakage source
corrected by a qualified installer, service agency,
manufacturer of dealer of the gas supplier.
|
Elkhart, IN 46514
|
574 -247-9235
INSTALLATION,
PRODUCT OVERVIEW
SAFETY PRECAUTIONS
WARNING
|
www.Invisionrvproducts.com
12-12-2023
Advertisement
Summary of Contents for Invision 400-2730
- Page 1 -Have the gas system checked and leakage source corrected by a qualified installer, service agency, manufacturer of dealer of the gas supplier. 2525 John Weaver Parkway Elkhart, IN 46514 574 -247-9235 www.Invisionrvproducts.com 2525 John Weaver Pkwy, Elkhart, IN 46514 | customerservice.invision@airxcel.com | 574.247.9235 12-12-2023...
- Page 2 The recess in which an oven is to be installed shall be constructed so is the safety alert symbol. This symbol alerts you to potential hazards that as to be framed in or guarded to prevent creation or storage space can result in property damage and/or serious bodily harm or death.
-
Page 3: Installation
WARNING: Installation of this appliance must adhere to the written instructions in this manual. No agent, representative or employee of the manufacturer of InVision appliances or other person has the authority to change, modify or waive any provision of the instructions of this manual. - Page 4 6. & 7. Check the pipe fittings for leaks using a soapy solution. Never use a flame. If touch the “ON/OFF” touch button once more, the system will turn off Push to insert the top glass cover assembly into the metal dip and place it into all functions and backlight, leaving only “ON/OFF”...
- Page 5 Click the “ON/OFF” key on the control panel to start the panel, and then Immediately strike and place a lit, long wooden match or a butane Lighter click the “OVEN” key to start the control display screen, Press “TEMP” with extension) through the spaces in the grate near the ports of the key to set the internal temperature of the oven, and set the desired burner to light the burner.
- Page 6 Make sure all control knobs are turned to OFF position. TROUBLESHOOTING Apply a gas leak detection liquid such as soapy water to the connections. PROBLEM/SYMPTOM POSSIBLE CAUSE/SOLUTION Gas leaks will be detected with the presence of bubbles. Surface control knob has not been fully rotated to the LIGHT position.
-
Page 7: Exploded View Drawing
EXPLODED VIEW DRAWING Knob for stove Handle for Glass Lid Ceramic Needle Burner Knob for oven Front Pan Support Grill Furnace Head Fixer Hinge LED PCB Glass Cover ODS Fixator Door Fixing Piece Decoration Ring Non-slip Pad for Glass Lid Door Inner Frame Knob Holder Glass Cover Hinge... -
Page 8: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY Please read and retain this warranty. Invision does not require Warranty Registration for this appliance. Your InVision appliance is covered by a one-year limited warranty. For one FOR FUTURE REFERENCE, YOU SHOULD year from your original date of purchase of the original purchaser, InVision...
Need help?
Do you have a question about the 400-2730 and is the answer not in the manual?
Questions and answers
Why does the oven still click after it is lit and up to temp.
The Invision oven model 400-2730 may continue to click after it is lit and at temperature because the electronic ignition system is still active. This can happen if the burner flame is not properly detected or if the control knobs are not fully in the ON position.
