Summary of Contents for Powerhorse 212cc
- Page 1 212cc Stump Grinder Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item 5858444 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Powerhorse product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): _____________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................5 Technical Specifications ........................5 Important Safety Information ....................... 5 Specific Operation Warnings ....................... 8 Fuel Safety ............................. 8 Main Parts of Product ........................... 9 Assembly Instructions .......................... 9 Before Each Use ..........................12 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use A stump grinder is a powerful machine used to remove tree stumps from the ground. It is equipped with a rotating cutting disk that grinds away at the stump until it is reduced to wood chips or sawdust. The primary function of a stump grinder is to eliminate tree stumps that are left after a tree has been cut down. -
Page 5: Packaging Contents
wheel(left/right) (2) manual bag (1) desiccant bag (1) Technical Specifications Property Specification Engine 212cc, 4-Stroke Brake Hole Brake Belt 2pc V Belt clutch Centrifugal Clutch Blades Blades W Tungsten (2 x left,2 x right,2 x middle) packing size 39 X 22.8 X 31.5in... - Page 6 intended. DO NOT use this equipment for a purpose for which it was not intended. Industrial or commercial applications must follow OSHA requirements. ⚠WARNING PROP 65 California Proposition 65AWARNING: Crude oil , gasoline , diesel,fuel and other petroleum products can expose you to chemicals such as toluene and benzene that are known to the State of California to cause cancer and birth defects or other reproductive harm .
- Page 7 stump grinder in unexpected situations. If devices are provided for the collection of dust extraction, ensure these are connected and properly used. use of these devices can reduce dust related hazards. Check stumps to be removed for embedded nails, wire, metal fence posts and other metallic objects and for rocks or other buried impediments which may become dangerously thrown or cause unexpected machine movements when hit by the cutting wheel.
-
Page 8: Specific Operation Warnings
than the tool itself. Keep guards in place and in working order. Never operate the product without the guards in place. Do not leave the tool running unattended. Specific Operation Warnings ⚠WARNING This machine can cause serious injury to the operator and bystanders. The warning and safety instructions in this manual must be followed to provide reasonable safety and efficiency in using and storing. -
Page 9: Main Parts Of Product
Main Parts of Stump Grinder Subassembly Main body Handrail bottom part Handrail top part Rubber pad Rear mudguard Adjust screw Wheel(left/right) Assembly Instructions ⚠WARNING Read and understand all instructions, safety precautions, and/or warnings listed in “Important safety information” and “Specific Operation Warning before operating the STUMP GRINDER. If any doubt or question arises about the correct or safe method of performing anything found in this manual, please contact the dealers in your area. - Page 10 Step 1: Assemble Left Wheel: Step 2: Assemble Right wheel: Step 3: Assemble handrail bottom part: Page 10 of 24...
- Page 11 Step 4: Assemble handrail top part: Step 5: Assemble Rear mudguard: After machine Assembled: Page 11 of 24...
-
Page 12: Before Each Use
Before Each Use ⚠WARNING Operators must be fully trained before using this machine. User Manual is read and understood. Teeth are in good condition and secure. All teeth are checked or replaced in sets. All fasteners are checked for tightness. ADDING OIL TO THE ENGINE ... -
Page 13: Operating Instructions
REMOVE STUMPS Remove all loose pieces of wood, stones, wire and other debris from the area before beginning stump removal. wind direction should be considered, as it influences the direction in which dust and woodchips are directed. Never operate the grinder after dark. - Page 14 3.should the chip build-up become excessive when cutting, shut of the machine wait for the cutting. wheel to stop rotating retract the machine from the stump and rake away the chips. It’s also possible. to use the cutter wheel to push chips of to the side. 4.To prevent any of the wheels becoming stuck in the hole.
-
Page 15: After Each Use
Cutting the full stump 1. Make sure the throttle is set to fast speed, so the cutter wheel will accelerate to cutting speed 2. Direct the cutter wheel against the stump, beginning with the nearest top corner of the stump and steadly sweep it across the stump left and right , cutting away1/2inch of ood with each sweep. - Page 16 SHUTTING OFF THE GRINDER 1. When stopping the machine after normal operation. lower engine speed to slow, and push the emergency switch. 2. set park brake before leaving the controls. 3. shut of the engine by pushing the on/off switch. NORMAL SHUT DOWN PROCEDURE In consideration of your own safety and that of others, you should always use the following normal shutdown procedures before departing from the controls for any reason including cleaning, servicing...
-
Page 17: Maintenance
Maintenance ⚠WARNING Make sure all nuts, bolts and screws are tightened. Never store the equipment with petrol in the tank inside a building where fumes can reach an open flame or spark. Allow the engine to COOI before moving the grinder. ... -
Page 18: Troubleshooting
Troubleshooting ⚠WARNING Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool. Disconnect the spark plug wire, keeping it away from the spark plug. Use the table below to troubleshoot problems before contacting service personnel or your local dealer. -
Page 19: Parts Diagram
Parts Diagram Page 19 of 24... -
Page 20: Parts List
Part List Part Number Part Description Quantity main frame belt cover inner plate belt cover blade cover engine clutch belt left flange wheel 145/70-6 right flange bearing 6002 seal 32 M16 flat washer M14 lock nut side-mudguard fitting bar rear mudguard side mudguard brake chuck brake pin... - Page 21 Part Number Part Description Quantity M6 rivet nut M16*360 hex bolt torsional spring brake cable fitting plate brake cable M8*70 hex bolt M5*16 hex bolt M6 lock nut M6*16 hex bolt M8 nut throttle cable assembly M16 handle assembly rubber ring for wire protective switch wire blade disk pully spacer 4.78*4.78 keyway...
-
Page 22: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 23: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Powerhorse product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two year from date of purchase. - Page 24 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in CHINA Page 24 of 24...
Need help?
Do you have a question about the 212cc and is the answer not in the manual?
Questions and answers
How much oil do I put in it for initial start up.It says check the dipstick and there is no dipstick.I checked the web and it says 21 ounces.Is that correct for the 212cc engine?
The manual does not specify the exact amount of oil needed. However, it states to use 10W-30, 10W-40, 15W-30, or 15W-40 non-synthetic engine oil and to fill to the correct level using the dipstick before use. The engine is shipped without oil, and running it without oil will destroy the engine.
This answer is automatically generated
proper oil level how to properly guage the dip stick level.
What is the size of the transport/shipping box? I need to know what size trailer is needed to transport.
