INSTALLATION INSTRUCTIONS
DXV Belshire
Free Standing Tub
Model D12040004 SERIES
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of tub or components.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and
plumbing supply stores. It is essential that the tools and materials be on hand before work has begun.
Tools
• Level
• Square
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2020
™
• Standard Woodworking Tools
• Personal Safety Equipment
• Caulking Gun
• Suction Cups/Lifting Straps
For Roughin information,
see Spec Page or Web Site for details.
Materials
• Silicone Caulking
• Tub & Tile Caulk
- 1 -
755707-100 (2/2020)
Advertisement
Related Manuals for DXV Belshire D12040004 Series
Summary of Contents for DXV Belshire D12040004 Series
- Page 1 Spec Page or Web Site for details. Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
- Page 2 If you are or think you may be pregnant, consult your physician before using the bathtub. Use this unit only for its intended use as described in this manual. Do not use any attachments not recommended by DXV. GENERAL INSTALLATION INFORMATION If you have installation or warranty questions please do not return the unit to the place of purchase.
- Page 3 INSTALLATION INSTRUCTIONS: NOTE: Provide adequate floor support. The tub is heavy. Obtain sufficient help and use suction cups/lifting straps to carefully lift or move tub. • Make sure the factory-installed drain connections to the tub have not become loose during shipping. Tighten as needed to prevent leakage.
- Page 4 Ecatepec, Estado de México 55540 Canada For residents of the United States, warranty Toll Free: 01-800-8391200 information may also be obtained by calling Toll Free: 1-800-387-0369 www.DXV.mx the following toll free number: (800) 227-2734 Local: 905-306-1093 www.DXV.com Fax: 1-800-395-1498 www.DXV.ca...
