- Page 1 INSTALLATION MANUAL Bolden™ Pot Filler with Knob KPF-5003 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing L LC I Rev. July 14, 2023...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: DO NOT RETURN TO STORE...
-
Page 3: Prior To Installation
Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·... - Page 4 Diagram and Parts List A. Faucet Assembly B. Flange C. Seat D. Screw E. Anchor F. Hex Wrench...
- Page 5 Faucet Dimensions 13 3/8" [339.7mm] 10 5/8" [268.9mm] 8 1/8" [207.5mm] 2 5/8" [67.3mm] 5 1/8" [130.2mm] Installer Tip: Shut off main water supply before installing new faucet.
- Page 6 Install the supply piping so that the 1/2-14NPSM-2A threaded connection protrudes approximately 1/2-14NPSM-2A beyond the finished wall. 1/2-14NPSM-2A Step 2: Marking the location for the seat piping and mark the locations for the NOTE: When marking the location for the seat screws, be sure that the screws will not interfere with or come into contact with any water supply piping that is concealed...
-
Page 7: Step 3: Drilling The Holes
Step 3: Drilling the holes Remove the seat and drill four holes on the positions marked in step 2 using a 6mm (1/4 in.) diameter drill bit. Step 4: Installing the anchors Insert the anchors (E) into the holes (1) and tap flush with the wall. - Page 8 Step : Installing the seat Apply pipe sealant tape to the threads of the supply pipe in a clockwise direction, as shown. Screw the seat (C) onto the supply piping and insert the screws (D) through the mounting bracket holes (1) and tighten until the seat (C) is flush with the wall.
- Page 9 Step 7: Flush faucet After the installation is complete, remove the aerator and housing by unscrewing it from the spout in a counterclockwise direction. Turn on the two handles to the right, turn on the water supply and allow water to run for at least one minute.
-
Page 10: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. Index GR, BL* KP27002 2. Set Screw KP27001 SFBB, SFACB, 3. Handle KP27450 MB, ORB, SFS* 4. Washer KP27474 GR, BL* 5. Cartridge KP27432 6. Aerator Assembly KP27447 SFBB, SFACB, 7. -
Page 11: Troubleshooting
Troubleshooting PROBLEM CAUSE ACTION Cartridge (5) has come loose. with hex wrench (12). Remove the handle (3) and washer (4). Tighten cartridge (5) with an adjustable wrench. Loosen the aerator shell (7), then remove The aerator assembly (6) Remove index (1) and loosen set screw with hex wrench (12). - Page 12 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 13 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
