Installation Instructions

Model:

Description:

Part Number:

Assembly Time:

Before you begin, read through these instructions and check that

all parts are present. Always disconnect negative battery terminal

prior to installation. Please note that MB Quart cannot assume any

responsibility for damage resulting from incorrect installation.

No.

GMR-LED with Housing (MBQG-RAD-1)

Bojo Tool

7mm wrench

T25 Torx Driver

Polaris General

Radio Install

MBQG-RAD-1

45 Min

Parts List

Component Name

Tools Required

Page 1 of 8

Qty

Need help?

Do you have a question about the MBQG-RAD-1 and is the answer not in the manual?

Page 1 Assembly Time: Before you begin, read through these instructions and check that all parts are present. Always disconnect negative battery terminal prior to installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation. Parts List...
Page 2: Dash Disassembly
Dash Disassembly ● Remove hood by turning two latches ● Remove seven push clips from front of dash Page 2 of 8...
Page 3 Dash Disassembly ● Remove top two push pins from driver and passenger door opening ● Lift front of dash at eight locations with Bojo tool Page 3 of 8...
Page 4 Dash Disassembly ● Remove upper pocket assembly Page 4 of 8...
Page 5 Radio Install ● Install two double threaded bolts in back of radio with 7mm wrench ● Place radio and dash kit from the front side of the dash ● Position rear bracket and loosely install the two nuts on back of radio Loosely install four High-Low threadforming screws with a T25...
Page 6 Reassembly ● Install top of dash, snapping eight push clips on front of dash ● Install six push pins on front of dash Page 6 of 8...
Page 7 Reassembly ● Install hood Page 7 of 8...
Page 8 The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use such marks by MB Quart is under license. All product names, logos, and brands are property of their respective owners. All company, product and service names used in this literature are for identification purposes only.
