TV019 Sweex 19" LCD TV with built-in DVD-player

Dear Customers

Thanks for purchasing this TFT-LCD TV/Monitor. We strongly recommend that you carefully read the safety and operation instructions before operating your

TV/Monitor. FOLLOW INSTRUCTIONS AND HEED ALL WARNINGS on your TFT-LCD TV/Monitor and in this manual.

Safety information

Note:

Before connecting the AC power cord to the DC adapter outlet, make sure that the voltage designation of the DC adapter corresponds to the local electrical

supply. If you are unsure about your power supply, please ask the local power company.

Caution:

To avoid electric shock, never touch the inside of the LCD TV/Monitor. Only qualified technicians should open the case of the LCD TV/Monitor.

Warning:

Do not ignore the safety purpose of grounding-type. A grounding type plug has two blades and a third grounding pin. The third pin is provided for your safety. If

the plug does not fit, ask the electrician to replace the obsolete outlet. Do not modify the plug!

To reduce the risk of fire or electric shock, and annoying interference, use the recommended accessories only.

Table of Contents

Need help?

Do you have a question about the TV019 - QUICK_START_GUIDE and is the answer not in the manual?

Questions and answers

Summary of Contents for SWEEX TV019 - QUICK_START_GUIDE

Page 1: Safety Information
Warning: Do not ignore the safety purpose of grounding-type. A grounding type plug has two blades and a third grounding pin. The third pin is provided for your safety. If the plug does not fit, ask the electrician to replace the obsolete outlet. Do not modify the plug!
Page 2 Opening in the LCD TV/monitor cabinet are provided for ventilation. To prevent overheating, these openings should not be blocked or covered. Never use the unit on a bed, sofa, rug, or other uneven surfaces. Doing so may block the ventilation openings in the bottom of the unit. If you place the LCD TV/Monitor in a bookcase or some other enclosed place, please make sure to provide adequate space for ventilation.
Page 3 English version Unpacking Please make sure that the following items are included with your LCD TV/Monitor. If any item is missing, please contact your dealer. TFT LCD TV/ Monitor Remote control Operation manual DC adapter Power cord RCA cable Base replacement for wall mounting...
Page 4 Front view Back view 1. Remote sensor 12. DVD disc slot in 2. Power button & indication light 13. DC input jack/Car cord input jack 3. DVD play/pause button 14. VGA jack 4. DVD stop playing button 15. SCART jack 5.
Page 5: Remote Control Reference Guide
English version Remote control reference guide...
Page 6 17. View a page of text in teletext mode or DVD fast forward playing. 18. Display the index page in teletext mode or replay the current program from the previous chapter or DVD skip backward playing 19. Change the display size in teletext mode or advance forward to the next chapter or DVD skip forward playing.
Page 7 3. Do not use the remote control for other equipments at the same time 4. If the TV does not operate even when operating the remote control from a close range, you need to replace the batteries. Refer to the label on the back of...
Page 8 English version III. Installation and connection Connect the LCD TV/monitor 1. Connect the TVRF source with the antenna port. TVRF signal including: Receiving antenna /satellite TV/CATV net. You can use 75 coaxial cable to connect the outdoor antenna. Outdoor Antenna Connection:...
Page 9 3. Press the VOL - or VOL + button to adjust the volume output. Press the VOL - button repeatedly to decrease the volume; press the VOL + button repeatedly to increase the volume from 0 to 100.
Page 10: Menu Setting And Adjustment
(5) PC screen Press the INPUT button to select the VGA input (TV into PC) mode. The will be a ‘PC’ mark appears on the right of the top corner of the monitor.The unit has a VGA jack for a normal computer. Connect the monitor with a PC by this jack and the unit can be used as the monitor of the PC.
Page 11: Sound Setting
Volume, Bass, Treble and Balance. And then use the button to adjust the value of each item respectively from 0∼100. After setting, press the LCD MENU button to return to the root menu or exit the setting menu. 3. CHANNEL SETTING( FOR TV SIGNAL SOURCE ONLY)
Page 12 As shown on the menu, the TV will automatically search stations. When searching, press the LCD MENU button to cancel searching. After the searching, the TV will begin to play the station 1.
Page 13 After entered into the number, press button again to move the cursor will on the line of “Swap”, then press button. After setting, press the LCD MENU button to return to the root menu or exit the setting menu.
Page 14: Function Setting
On this menu, the Function setting icon of is in red frame. (1). Language Use the button firstly, the cursor will be on the line of “Language English”. And then, press the button repeatedly to select the language you need. (2). Blue Back Move the cursor to the line of “Blue Back On”.
Page 15 Press the button repeatedly, you could select User, Normal, Warm or Cool according to your request. Note: Only if Color Temp. is set to “User”, then you can adjust “User – R”, “User – G” and “User – B”. (5). DNR Press the button repeatedly, you could select Strong, Normal or Weak.
Page 16: Dvd Player Operation
DVD Player Operation a. Basic operation 1. Press the SOURCE button on the remote control to select the DVD function mode. Insert a disc into the slot of the DVD player and it will start to read the disc automatically.
Page 17 You can repeat a specific section by the A-B button on the remote control. Firstly press the A-B button at the beginning of the section you want, then press it again at the end of the section. The unit will now repeat playing from A to B. If you want to cancel the repeat section, please press the A-B button once again.
Page 18 • For different discs, PROG button may have a different function. • If you press the STOP button once the DVD video player will stop. At this point, press the ENTER button to re-start the disc from the same point.
Page 19: Displaying The Setup Menu Screen
MP3/JPEG playback 1. In DVD mode, Insert a MP3 or JPEG CD into the disc slot, the DVD video player will initialize the disc and the directory (folder) will be shown on screen. The first MP3 or JPEG file will be played automatically.
Page 20: System Setup
This feature is not available on this model TV SYSTEM This menu enables you to set the picture format for your TV/DVD between NTSC/ PAL/ AUTO according to your request and local TV system. TV TYPE This menu enables you to select one of the three aspect ratios:...
Page 21 • 4:3LB (Normal) Choose this setting will allow you to to view the movies in its original aspect ratio. the entire frame of the movie will be displayed on screen but will occupy a smaller portion of the screen.
Page 22: Default Setting
PASSWORD This is used to lock and unlock the RATING setting. The default setting is locked. Enter the default password”0000” by numeric buttons, then press ENTER button to unlock. To change the password just input 4 digits you want in unlock mode.
Page 23: Language Setup
SPDIF/PCM: When selected, the audio contained on the disc is passed directly to the Coaxial output in PCM format. This format ensures a very high quality but it does not support the surround sound effect. Use this setting when connecting the coaxial output to a receiver-amplifier not capable of...
Page 24: Digital Setup
Tone setting. 4. Digital Setup DYNAMIC RANGE Press the buttons to adjust the compression ratio for different audio effect, When selected FULL, the peak signal value is smallest; When selected OFF, the peak signal value is biggest. DUAL MONO Press the...
Page 25: Other Operation
Other Operation PC audio in operation This unit possesses PC audio in jack. Connect this jack to PC main unit with related audio cable n PC mode and adjust the volume to what you want. Wall Mounting Accessoiries To remove the base from the TV, remove the 5 screws on the lower back of the TV.
Page 26 (1) Please read these operating instructions carefully before you operate this unit. (2) When you want to cut off the electricity supply of the whole unit’s power, please press the POWER button on the unit. And take out the plug from wall outlet.
Page 27: Maintenance
(7) It is dangerous to use warped or broken discs since lasers rotate at high speed. Never use discs repaired with plastic tape or glue, as it will lead to damage.
Page 28 Scart Input Composite video, RGB, Audio L+R Output Composite video, Audio OSD language English / German / French / Spanish / Italian / Portuguese / Russian Audio output 3W * 2 Gross weight 8 Kgs Power requirement DC 12V 5A, AC110~240V, 50Hz/60Hz...
Page 29: Display Modes
2. You have 13 available modes compatible with windows. 3. It can happen that the image is disrupted. This can occur as result of a signal from the VGA card, which does not correspond with the usual standard. This is not, however, an error.
Page 30: Warranty
