- Page 1 INSTALLATION GUIDE AND USERS MANUAL OUTDOOR REMOTE BLOWER OUTDOOR 600 Model Name: Single Blower Specification: 600 CFM NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference. Rev.20230324a...
-
Page 2: Table Of Contents
Required Tools.................. 8 Dimensions..................8 Parts Supplied................... 9 Venting Method................. 10 Duct Placement................. 12 Do’s and Don’ts for Duct Venting............ 13 Electrical Wiring Diagram..............13 Remote Blower Operations............. 15 Troubleshooting................15 Warranty..................... 16 Disclaimer..................17 Contact Us..................17 | OUTDOOR 600... -
Page 3: Important Safety Notice
• Use high settings on cooking range only when necessary. • Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. OUTDOOR 600 | 3... - Page 4 The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. | OUTDOOR 600...
-
Page 5: Electrical Requirements
(at the range hood and at the junction box). Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 OUTDOOR 600 | 5... -
Page 6: Venting Requirements
Reducing the duct size will restrict airflow and decrease efficiency. • If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible. Minimum Duct Size: • Round - 6” minimum • Round - 8” recommended/optional | OUTDOOR 600... -
Page 7: Calculating Duct System Length
1. In House Test Static Pressure “0”. 2. One sone is roughly equivalent to the sound of a refrigerator (1kHz) at 40 decibels. 3. Subject to change without notice, please contact your local reseller for details. OUTDOOR 600 | 7... -
Page 8: Required Tools
Pencil Drywall Power Knife Knife Knife Drill Tape Phillips Measure Screwdriver Level Aluminum Tape DIMENSIONS 16 ½ ” 6"-Ø Transition TOP VIEW 6 ¼” 19” 8"-Ø Transition (shown example) FRONT VIEW SIDE VIEW BACK VIEW BOTTOM VIEW | OUTDOOR 600... -
Page 9: Parts Supplied
6” or 8” Ø Backdraft Damper PVC conduit for wiring passthrough NOTE: Where necessary, additional screws will be needed for installation and added support, but is not included. Please review contents before installation. OUTDOOR 600 | 9... -
Page 10: Venting Method
8” shown There is NO BLOWER in this range hood example shown here: VICTORY VERONA. The OUTDOOR 600 CFM Remote Blower is operated by a control switch located on the range hood (typically in between the front lights). | OUTDOOR 600... - Page 11 30” IMPORTANT NOTE: This calculation is for VERONA only. It is based on the height of the hood. The taller the hood the higher the duct hole needs to be. 36” (typical) OUTDOOR 600 | 11...
-
Page 12: Duct Placement
(not included) No Blower in Range Hood Between Joists Joist 600 CFM OUTDOOR Blower 5 Wires Drop down Ceiling +Ground 14-3 14-2 6” to 8” Ø Duct Conductors (not included) No Blower in Range Hood Below Joists | OUTDOOR 600... -
Page 13: Do's And Don'ts For Duct Venting
If purchased with a range hood, the remote blower can be connected to the existing 4-speed motor switch controls typical in most models of our range hoods. The remote blower alone does NOT INCLUDE a 4-speed motor switch, and must be considered for separate purchase. OUTDOOR 600 | 13... - Page 14 ELECTRICAL WIRING DIAGRAM (Continued) | OUTDOOR 600...
-
Page 15: Remote Blower Operations
• Make sure the power is on high speed for heavy cooking. • Refer to DO’S and DON’TS for DUCT VENTING page for illustrative examples. NOTE: For all other inquiries, please contact Victory Range Hoods. OUTDOOR 600 | 15... -
Page 16: Warranty
Outdoor/Remote Blower from Victory Range Hoods. The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. | OUTDOOR 600... -
Page 17: Disclaimer
583 Nicola Avenue, Port Coquitam, BC, Canada Toll Free: 1-800-394-4020 info@victoryrangehoods.com The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. OUTDOOR 600 | 17... - Page 18 NOTES | OUTDOOR 600...
- Page 19 NOTES OUTDOOR 600 | 19...
- Page 20 583 Nicola Avenue | Port Coquitlam | BC | Canada | V3B 0M3 www.victoryrangehoods.com...
