SWEEX PU054 - QUICK_START_GUIDE Introduction Manual

2 port usb 2.0 & 2 port firewire pc card
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

English version
English version
Introduction
First of all, many thanks for purchasing this Sweex 2 Port USB 2.0 & 2 Port FireWire PC Card. This card enables you to easily add two USB 2.0
and two FireWire ports to your laptop. This way, high-speed communication with e.g. video cameras, photo cameras, external hard disks, printers,
scanners and other devices which use USB or FireWire can be realised.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during
installation or operation of this product, go to www.sweex.com and look under the heading service & support.

Connections

The Sweex 2 Port USB 2.0 & 2 Port FireWire PC Card includes the following connections:
• 1 x FireWire IEEE1394a 6-pin connection
• 1 x FireWire IEEE1394a 4-pin connection
• 2 x USB2.0 connection
• Connection for external power supply if required

Important!

Ensure you connect your FireWire cable correctly. A cable which is connected incorrectly may damage the device.
Installation under Windows 98SE
We advise you to ensure the operating system is up-to-date before starting the installation. This can be easily checked by starting up Internet Explorer
and selecting the option "Windows Update" in the "Extra" menu.
Once the hardware has been detected, Windows shows the following screen:
PU054 Sweex 2 Port USB 2.0 & 2 Port FireWire PC Card


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PU054 - QUICK_START_GUIDE and is the answer not in the manual?

Questions and answers

Related Manuals for SWEEX PU054 - QUICK_START_GUIDE

Summary of Contents for SWEEX PU054 - QUICK_START_GUIDE

  • Page 1 Introduction First of all, many thanks for purchasing this Sweex 2 Port USB 2.0 & 2 Port FireWire PC Card. This card enables you to easily add two USB 2.0 and two FireWire ports to your laptop. This way, high-speed communication with e.g. video cameras, photo cameras, external hard disks, printers, scanners and other devices which use USB or FireWire can be realised.
  • Page 2 English version English version Click “Next”. Here, select the option “Search for the best driver” and click “Next”. Untick all options. Then click “Next”. Select the first option and click “next”. To complete this part, click “Next” and then “Finish”.
  • Page 3 Here, select the option “Search for the best driver” and click “Next”. Tick the last option: “Specify a location”. Insert the Sweex CD-ROM in the CD-ROM player. Go to the Sweex CD-ROM via “Browse”, and select the folder “Drivers”. In this folder, select the relevant operating system; win98. Then click “Next”.
  • Page 4 English version Click “Next”. To complete this part, click “Next” and then “Finish”. Click “Next”. Here, select the option “Search for the best driver” and click “Next”.
  • Page 5 Port USB 2.0 & 2 Port FireWire PC Card will be installed automatically. If you do not have the possibility of updating Windows, a separate VIA USB 2.0 driver must be installed in order to use the USB 2.0 feature. It can be found in the Sweex autorun menu (starts automatically after inserting the CD-ROM) under the “VIA USB 2.0 Driver”...
  • Page 6 English version External power supply If so-called bus-powered devices are used, the 2 Port USB 2.0 & 2 Port FireWire PC card offers the possibility of connecting an external power supply. One of the following two can be connected: • 5 Volt DC Adaptor Warranty All products under the Sweex brand are warranted for a period of three years.
