Fontana Showers FS1222 Installation Instruction

Deck mount commercial automatic soap dispenser
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
FontanaShowers
FontanaShowers
©
©
Product code: FS1222
FONTANA CHATOU DECK MOUNT COMMERCIAL
AUTOMATIC SOAP DISPENSER INSTALLATION
INSTRUCTIONS
BEFORE YOU BEGIN
Before you begin, please read the installation instructions below. Observe
all local building and safety codes.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
Please note all products must be installed by a professional and certified
plumber otherwise warranty might be voided.
POSSIBLE TOOLS REQUIRED*
Level
Plumbers Tape
Tape Measure
Adjustable Wrench
Hex Wrench
Thread Sealant
Pencil or Marker
Screwdriver
Drill
*not included
fontanashowers.com
FontanaShowers
FontanaShowers
1
Customer Service: 800-684-4489
