Page 1: Table Of Contents
Remote control unit Insert the battery P8-P11 Getting Started P8-P9 Introduction TFT screen adjust Playing a DVD or Video CD(Operation) P10-P11 Basic operation P12-P15 Audio CD and MP3/WMA Disc Features Playing an Audio CD or MP3/WMA Playing a JPEG Disc...
Page 2 P17-P23 SETUP Menu Setting P9-P10 General Operation General Setup Page P17-P19 P9-P10 P19-P20 P9-P10 Speaker Setup Page P9-P10 Dolby Digital Setup P21-P23 P9-P10 Preference Page Parameters and specifications P24-P25 P9-P10 P9-P10 P9-P10 P9-P10 Troubleshooting tips P9-P10 P9-P10 Definition of terms...
Page 3: Safety Precautions
Warning: Never stare directly into the laser beam. Caution: Do not install this product in a confined space such as a book case or similar unit. Before using the player, please ensure that the local AC voltage is su...
Page 4 SERIAL NUMBER: You can find the ser i al number on the back of the unit.This number is unique to this unit and not available to others.You should record requested information here and retain this guide as a permanent record of your purchase.
Page 5 DVD and finalized DVD+R/RW Video CDs Audio CDs MP3 Discs WMA Discs JPEG Discs JPEG Divx Discs DIVX The above items are true of not only this unit but also most of the hou...
Page 6 Notes on Discs Handling Discs Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc. rous Storing Discs After playing,store the disc in its case.Do not expose the disc to direct...
Page 7: Before Use(Continued)
(or DVD -R, DVD +R, DVD -RW, DVD +RW) discs cannot be played on the unit. 2.Do not attach any seal or label to either side (the labeled side or the recorded side) of a disc. 3.Do not use irregularly shaped CDs (e.g., Heartshaped or octagonal)since they may result in malfunctions.
Page 8 Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your DVD player's region code or the disc cannot play. If you try to play a DVD with a different region code from your player,the message "Check...
Page 9: Identification Of Controls
Identification of Controls Main Unit...
Page 10 1. LCD screen 2. Speakers 3. Previous/Fast backward 4. Next/Fast forward 5. Play/Pause 6. Stop 7. Enter (Left/right/up/down) 9. DC in 10.DC out 11.DC in 9V Jack 12.Headphone Jack 13.AV out 14.Volume knob 15.Power ON/OFF switch...
Page 11: Battery Pack
Identification of Controls Battery Pack 1.Power charge indicator during recharging , indicator is red.If recharging is complete, charge indicator changes to green. 2.Remote sensor. 3.Battery pack. RELEASE...
Page 12 Charge the battery pack before using it for the first time. Attaching the battery pack 1.Match the hooks of the battery pack into the holes on the bottom of the player. 2.Combine the battery pack to push up until you can hear the click sound.
Page 13: Remote Control Unit
2. STOP ( Stops playback. Stops playback. 3. Reverse Skip ( 3. Reverse Skip ( Go to previous chapter / track or to the Go to previous chapter / track or to the beginning. beginning. 4. Forward Skip( 4. Forward Skip( Go to the next chapter / track.
Page 14 19.SETUP 19.SETUP Accesses or removes setup menu. Accesses or removes setup menu. 20.10+ BUTTON 20.10+ BUTTON Add 10+ while your selection is more than10. Add 10+ while your selection is more than10. 21.STEP 21.STEP Step the motion. Step the motion.
Page 15: Insert The Battery
Identification of Controls Insert the battery Refer to the drawing, take the back cover of the remote control off and remove the empty battery receptacle. Prior to shipping, a separating film was applied to the battery. Remove this film. Insert the battery into the receptacle and insert the receptacle into the remote.
Page 16: Getting Started
VCD (Video CD) A VCD holds up to 74 minutes (650 MB disc) or 80 minutes (700 MB disc) of MPEG-1 full-motion video along with quality stereo sound. MPEG MPEG is an international standard for video and audio compression.
Page 17 Chapter (DVD video discs only) A chapter is a segment of a title such as a scene in a film or one interview in a series. Each chapter is assigned a chapter number, enabling you to locate the chapter you want.
Page 18: Tft Screen Adjust
TFT screen adjust If you want to adjust the effect of TFT you can use the"MODE"and " "on the panel."BRIGHTNESS" "CONTRAST" "HUE" and "SCREEN MODE":16:9 / 4:3 are adjustable. Note: If you want to set the parameter to default value.you can go into...
Page 19: Playing A Dvd Or Video Cd(Operation)
Notes: 1.If parental control is set and the disc isn ' t fit for the rating setting you must input the password.(See "parental" on page 21). 2.DVDs may have a region code.Your player does not play discs that have a region code different from your player.
Page 20 Moving to another CHAPTER/TRACK When a title on a disc has more than one chapter or a disc has more than one track, you can move to another chapter/track as follows: 1.Press SKIP briefly during playback to select the next (or previous)chapter/track or to return to the beginning of the current chapter/track.
Page 21 All : repeats all the tracks on a disc. Off : does not play repeatedly. Notes: 1.On a Video CD with PBC, you must set PBC to Off to use the repeat function. 2.If you press SKIP ( ) once during Repeat Chapter(Track)
Page 22 MENU 1. Press MENU.If the current title has a menu, the menu appears on the screen. Otherwise, the disc menu may not appear. 2. The MENU offers features such as camera angles,spoken language and subtitle options, and chapters for the title.
Page 23: Basic Operation
The DVD player can play CD and MP3/WMA formatted recordings on CD-R,CD-RW,DVD+R and DVD+RW discs. Audio Once an Audio CD is inserted it will be played automatically.Its playblack information will be show on screen,such as chapter elapse time. 1. Press select a folder, and press ENTER to see the folder contents.
Page 24 File names should have a maximum of 8 letters and must incorporate an" .mp3" or " .wma" extension. They should not contain special letters such as "/? * : < > l "etc. The total number of files on one disc should be less than 650.
Page 25: Playing An Audio Cd Or Mp3/Wma
Moving to another Track 1. Press SKIP ( ) briefly during playback to go to the next (or previous) track or to return to the beginning of the current track.. 2. Press SKIP twice briefly to go back to the previous track.
Page 26: Playing A Jpeg Disc
1.Insert a disc and close the tray. The file menu appears on the TV screen. 2. Press to select a folder, and press ENTER. A list of files in the folder Appears. If you are in a file list and want to return to the previous Folder list, use the buttons on the remote to highlight and press ENTER.
Page 27 1.Depending upon the size and number of JPEG files, it could take a long time for the DVD player to read the disc•• s contents. If you don•• t see an on screen display after several minutes, some of the files may be too large reduce the resolution of the JPEG files to less than 2M pixels as 2760 x 2048 pixels and burn another disc.
Page 28: Playing A Dvd Vr Format Disc
DVD-recorder. This unit will play DVD-RW discs recorded using the Video recording (VR) format. 1. Insert a disc and close the tray.The DVD-VR menu appears on the TV screen. 2. Press to select a track then press PLAY or ENTER and playback starts.
Page 29: Playing A Divx Movie Disc
TV screen. 2. Press select a folder, and press ENTER. A list of files in the folder appears. If you are in a file list and want to return to the Folder list,use the button on the remote to highlight button and press ENTER.
Page 30 "DIVX3.xx ", "DIVX4.xx ", "DIVX5.xx " Playable Audio format "AC3 ", "PCM ", "MP3 ", "WMA ".Sampling frequency: within 8 - 48 kHz (MP3),within 32 - 48kHz (WMA) Bit rate: within 8 - 320kbps (MP3), 32 - 192kbps (WMA) ved,...
Page 31 4. To resume normal playback from programmed playback,Press PROGRAM and press STOP button on the program menu. Program:TT(06)/CH(- -) TT: 06 CH:01 TT: 05 CH:01 Exit Stop NEXT When this unit is not used, please turn off the power and leave no disc insi...
Page 32 Helpful Hint: - Program can be activated only DVD player. when a disc is in the - When the program menu appears, the setup menu setting is forbiddened. 5'). o disc inside.
Page 33: Setup Menu Setting
OSD lang Captions Screen Saver Go To General Setup Page 1.Press SETUP to enter the setup menu. 2.Press to select the 'General Setup page'. TV Display Set the aspect ratio of the DVD Player according to the TV you have connected.
Page 34 Letter Box Pan Scan Normal/PS If you have a normal TV and want both sides of the picture to be trimmed or formatted to fit your TV screen. Normal/LB If you have a normal TV. In this case , a wide picture with black bands on the upper and lower portions of the TV screen will be displayed.
Page 35: General Setup Page
You can select your own preferred language seetings.This DVD system will automatically switch to the selected language whenever you load a disc.If the language selected is not available on the disc, the disc's default language will be used instead. The OSD language in the system menu will remain once selected.
Page 36 1.Press the keys to highlight 'OSD Lang'. 2.Enter its submenu by pressing 3.Move the cursor by pressing the to highlight the selected item. 4.Select a language and press ENTER.
Page 37: Closed Captions
SETUP Menu Setting General Setup Page Closed Captions Closed captions are data that are hidden in the video signal of some discs.Captions are different from subtitles because captions hearing are impaired by showing the sound effects(e.g.,"phone ringing" and " footsteps"),while subtitles do not.
Page 38: Speaker Setup Page
Downmix Go To Speaker Setup Page 1.Press SETUP. 2.Press to select the 'Speaker Setup page'. Downmix This options allows you to set the stereo analog output of your DVD Player. Dolby - - Speaker Setup Page - - Downmix LT/RT...
Page 39: Dolby Digital Setup
3.Move the cursor by pressing the keys to highlight the selected item. LT/RT :Select this option if your DVD Player is connected to a Dolby Pro Logic decoder. Stereo :Select this option when output delivers sound from only the two front speakers.
Page 40 3.Move the cursor by pressing the keys to highlight the selected item. To select the setting that matches the number of speakers you have connected. Stereo:Left mono sound will send output signals to Left speaker and Right mono sound will send output signals to Right speaker.
Page 41: Preference Page
SETUP Menu Setting Preference Page Preference Page The options included in Preference page are : 'Audio', 'Subtitle','Disc Menu','Parental','Password',and 'Default'. Dolby Preference Page Audio Subtitle Disc Menu Parental Password Default Go To Preference Page 1.Press SETUP. 2.Press to select the 'Preference Page'.
Page 42 Audio,Subtitle and Disc menu These options set the Audio,Subtitle and Disc menu language fit for you Dolby Preference Page French Audio Spanish Subtitle Chinese Disc Menu Japanese Parental Korean Password Russian Default Thai Preferred Audio Language - 'Audio '(disc 's soundtrack)
Page 43 Some DVDs may have a parental level assigned to the complete disc or to certain scenes on the disc.This feature lets you set a playback limitation level.The rating levels are from 1 to 8 and are country dependent. You can prohibit the playing of certain discs that are not...
Page 44 - Material is unsuitable for children under age 13. 5-6 PG-R - Parental Guidance-Restricted;recommended that parents restrict children under 17 from viewing or allow to view only when supervised by a parent or adult guardian. 7 NC17 - No children under age 17;not recommended viewing for children under age 17.
Page 45 - The default password (1369)is always active even the password has been changed. Default Setting the 'Default ' function will reset all options and your personal settings to the factory defaults and all your personal settings will be erased. Dolby...
Page 46 1.Press to highlight 'Default ' . 2.Highlight Reset by pressing 3.Press ENTER to confirm selection. Caution! - When this function is activated,all settings will be reset to factory defaults.
Page 47: Parameters And Specifications
65+20% 1 week -20 C ~ +65 C 65+20% 2.Work circumstances Temperature Humidity Standard charge 0 C ~ +45 C 65+20% Standard discharge -20 C ~ +65 C 65+20% The chargeing time is various acording to the transformation of quanti...
Page 48: Maintenance And Service
Keeping the exterior surfaces clean Do not use volatile liquids such as insecticide spray near the unit. Do not leave rubber or plastic products in contact with the unit for a long period of time. since they leave marks on the surface.
Page 49 Parameters and specifications Electronical parameters Item Standard requirement Power requirements : AC 100-240 V , 50/60 Hz Dimensions (Approx.) : 200(L)X150(W)X38.8MM Power consumption : <10W Weight (Approx.) : 0.66kg Operating humidity : 5 % to 90 % VIDEO OUT :1.4 Vrms (1 KHz, 0 dB)
Page 50 : 20Hz to 20 kHz(1dB) response :More than 80 dB (ANALOG OUT connectors only) Signal-to-noise ratio Dynamic range :More than 85 dB (DVD/CD) :Video/Audio cable,Remote control, Stereo headphone,Rechargeable battery, Accessories Car cigarette Adapter,Car bag Note: Design and specifications are subject to change prior notice.
Page 51: Troubleshooting Tips
No key operation(by the unit and/or the remote control) is effective: Turn the unit off and then back to on. Alternatively, turn off the unit, disconnect the AC power cord and the re-connect it.(The player may not be operating properly due to lightning, static electricity or some other external factor.)
Page 52 Audio soundtrack and/or subtitle language is not the one selected at the initial settings: If the audio soundtrack and/or subtitle language does not exist on the disc, the language selected at the initial setting will not be seen/ heard. No subtitles: Subtitles appear only with discs which contain them.
Page 53: Definition Of Terms
With such discs, the ANGLE button can be used to view the scene from different angles.
Page 54 Track number These numbers are assigned to the tracks which are recorded on CDs. They enable specific tracks to be located quickly.
