- Page 1 INSTALLATION and USER MANUAL TYTAN DS410 TYTAN DS424 manual ver.DS410.IU.ALL.2522.001 2021-04-02...
-
Page 2: Table Of Contents
Anti-hijack function ................................7 Coded pa button authorization ............................8 Valet mode ....................................8 Installation manual ..................................9 General notes ..................................9 Programmable and optional features of TYTAN DS410/DS424..................9 2.2.1 CAN bus control ................................9 2.2.2 External RF receiver module with 2 analogue outputs ....................9 2.2.3 Ignition switch state detection methods ........................9... - Page 3 Technical data ....................................23 Description of inputs/outputs ..............................23 Installation schematics ................................24 Schematic A - universal ..............................25 Schematic B - Fiat ................................26 Schematic C - Renault ................................ 26 Schematic D - BMW ................................27 Index ......................................28 Digital Systems DS410.IU.ALL.2522.001...
- Page 4 • VALET mode - Vehicle Security System temporary disabled. • PANIC input* - pre-alarm signalisation input. IMPORTANT! The * symbol describes optional function/feature of the VSS which is dependent on the vehicle model and VSS configuration. Digital Systems DS410.IU.ALL.2522.001...
-
Page 5: User Manual
The status LED will start blinking until any door is opened and then will go off. If the alarm was triggered during the driver’s absence, the VSS signalizes it with three siren chirps. IMPORTANT! If after disarming neither doors nor trunk is opened within 30 seconds the system rearms automatically. Digital Systems DS410.IU.ALL.2522.001... -
Page 6: Trunk Release Button Logic
IMPORTANT! If the VSS is configured with the Ignition Safety Door Lock function, please check its description! Emergency disarming of the security system Tytan DS410/DS424 CAN has a procedure of emergency disarming the security system in case the remote control is inoperative or not available (not working or lost). -
Page 7: Passive Arming*/Automatic Central Door Locking
Uncoded PA button authorization - press the PA button for approximately 1 second Coded PA button authorization - follow the description given in further part of the manual. The authorization of anti-hijack function is confirmed by single 2 seconds pulse of LED. Digital Systems DS410.IU.ALL.2522.001... -
Page 8: Coded Pa Button Authorization
When entering valet mode, the VSS has to be disarmed and the ANTI-HIJACK and IMMOBILISER functions have to be authorized. Entering valet mode Turn the ignition on. Press the PA button 7 times (pause between press should be less than 1 second). The single blink of LED and 4 siren chirps confirm entering the valet mode. Digital Systems DS410.IU.ALL.2522.001... -
Page 9: Installation Manual
General notes • Tytan DS410/DS424 CAN Vehicle Security System (VSS) is intended to use in all combustion engine cars, with 12V or 24V supply system and negative ground. Tytan DS410/DS424 CAN security system must be installed according to manufacturer’s requirements and documentation. -
Page 10: Dual Function Line/Programmable Lines
2.2.6 OEM alarm detection If car is equipped with the OEM security system, start of OEM alarm cycle can trigger alarming in Tytan DS410/DS424 VSS. That feature allows DS410/DS424 to protect car using OEM motion detector and OEM towing detector. -
Page 11: Audible Confirmation Of Vss Arming/Disarming
Menu bar commands and functions: Firmware update allows changing the firmware currently used in DS410/DS424 to a different one (test firmware supplied by Digital Systems or firmware with updated list of operated vehicles) BLE module Bluetooth LE module firmware update... -
Page 12: Vehicle Security System (Vss) Service Mode
If more than one input is triggered releasing that input is also signalled by single siren chirp. In order to go to stage IV, press and hold the PA button (approx. 3 seconds) until siren chirps 4x. Digital Systems DS410.IU.ALL.2522.001... -
Page 13: Stage Iv - Setting Sensitivity And Testing Of Internal Ultrasonic Motion Detector
As long as the ignition is switched on, pressing any button on any programmed remote is signalled by 2 LED blinks and 2 siren chirps. Press PA button 3 times to repeat programming new remotes (paragraph 2 above) Switching off ignition exits the transmitter testing mode and the service mode. Digital Systems DS410.IU.ALL.2522.001... -
Page 14: Diagnostic Tools
CAN-bus connections on some vehicles (e.g. Subaru Forester). RMT_LOCK Lamp shows that LOCK button on Tytan remote transmitter was pressed. RMT_UNLOCK Lamp shows that UNLOCK button on Tytan remote transmitter was pressed. RMT_UNLOCKTRUNK Lamp shows that UNLOCK_TRUNK button on Tytan remote transmitter was pressed. Digital Systems DS410.IU.ALL.2522.001... -
Page 15: Additional Modules
Locking module has 2 outputs to handle analogue connection to vehicle central door locking system. Sometimes, the locking module can be used without any remotes, just to allow central door lock control via TytanBT app. Digital Systems DS410.IU.ALL.2522.001... -
Page 16: Bluetooth Devices In Ds410/Ds424
The remote has unique name built of remoteBT prefix and 4 digits of remote serial number, placed on PCB sticker inside the remote. The jokerBT has unique name built of jokerBT prefix and 4 characters of jokerBT serial number, printed on Joker (‘8390’ in the example here). Testing of BT devices Digital Systems DS410.IU.ALL.2522.001... -
Page 17: Pairing Bt Devices With Radiobt Module
When the button is released, the LED blinks again. If pairing is ok, the LED blinks 5x. In order to test pairing of new remote is ok, check the list of paired BT devices. Digital Systems DS410.IU.ALL.2522.001... -
Page 18: Jokerbt - Bluetooth Authorization Token
5mm x 0.15mm) is supplied with jokerBT or can be cut from stiff plastic foil. When the ‘jokerBT control’ panel is visible, place the joker as close as possible to the phone and interrupt the power supply as described above. Digital Systems DS410.IU.ALL.2522.001... - Page 19 It does not broadcast at all and it does not react on movement. In such state, the jokerBT can be stored with a battery inside e.g. in a car and it will not authorise the immobiliser function. To temporary disable the jokerBT, connect jokerBT with app as described above. Then, press ‘Temporary disable jokerBT’ button. Digital Systems DS410.IU.ALL.2522.001...
-
Page 20: Tytanbt App Operation As Bluetooth Remote Control And Authorization Token
The app has a TytanBT master switch. It disables the BT operation of TytanBT app, without necessity to switch the phone BT off. Disabling the BT operation of TytanBT app: saves phone battery (disables BT advertising of TytanBT application) prevents the authorisation token function from unintended authorisation of immobiliser/antihijack function Digital Systems DS410.IU.ALL.2522.001... - Page 21 The principle of operation is that when the car and the phone are in proximity and the BT connection is established, the app does not authorise the immobiliser/antihijack function. Instead, the app is activated with a notification. The user has to press the additional authorisation button on the TytanBT main screen, to authorise the immobiliser/antihijack. Digital Systems DS410.IU.ALL.2522.001...
- Page 22 To check if the phone is paired with BT module in the given vehicle, open vehicle properties in vehicle list panel. The writing on the button informs whether the phone is paired or not with this vehicle: Digital Systems DS410.IU.ALL.2522.001...
-
Page 23: Technical Data
Analogue signal required to distinguish OEM remote STATUS2- Input/negative signal in some vehicles (only if required by installation Pager diagram) Immobilizer Siren power DS410 +12V Siren power supply: DS410 power supply 12V or DS424 supply DS424 +24V power supply 24V Digital Systems DS410.IU.ALL.2522.001... -
Page 24: 10 Installation Schematics
To get a complete installation diagram for specific vehicle compare DS410/DS424 schematic and dedicated vehicle schematic. Connect wires presented on vehicle schematic – all other wires presented on DS410/DS424 schematic are not required or are optional. Vehicle schematics are available only for authorised dealers and installers. Digital Systems DS410.IU.ALL.2522.001... -
Page 25: Schematic A - Universal
*3 If STATUS 3 wire is drawn on car part of schematic, connect it to orange wire of DS410/DS424. In such case the orange wire cannot be connected to ignition signal. *4 RF module white wires are internally connected to (+) power supply of DS410/DS424. Digital Systems DS410.IU.ALL.2522.001... -
Page 26: Schematic B - Fiat
Schematic B - Fiat Schematic for Fiat vehicles with central door locking control via coded single wire, level 14, 53, 69. Schematic C - Renault Schematic for Renault vehicles with single wire bus, level 87. Digital Systems DS410.IU.ALL.2522.001... -
Page 27: Schematic D - Bmw
*2 Use diodes only if both STATUS 1 and STATUS 2 wires are drawn on car part of schematic. *3 If STATUS 3 wire is drawn on car part of schematic, connect it to orange wire of DS410/DS424. In such case the orange wire cannot be connected to ignition signal. Digital Systems DS410.IU.ALL.2522.001... -
Page 28: 11 Index
11 Index app/apps – TytanBT mobile application for iOS and Android systems, available on Apple App Store and Google Play Digital Systems – manufacturer of DS410/DS424 hardware, TytanBT app DS410 – a +12V hardware installed in a vehicle DS424 – a +24V hardware installed in a vehicle firmware –...
