UPM601-C
Ultra High Frequency
Partial Discharge Monitor: Continuous
Installation and Operation Manual
Rugged Monitoring Québec Inc.
1415, rue Frank-Carrel, Suite 230
Québec, QC, G1N 4N7
Canada
Tel: +1-418-767-0111
support@ruggedmonitoring.com
Proprietary notice:
Details of design and engineering are the exclusive property of Rugged Monitoring Inc. and are strictly
confidential. The information given herein is subject to change, at any time and without notice.
All rights are reserved. The information in this document may not be reproduced or passed on in any manner
without prior written consent of Rugged Monitoring.
Rugged Monitoring shall not be liable for technical or editorial errors or omissions contained herein; nor for
incidental or consequential damages resulting from the furnishing, performance, or use of this material.
All trademarks are the property of their respective owners.
Part number: MAN0054-EN-R01 (May 2023)
1
Document no. MAN0054-EN-R01
Copyright Rugged Monitoring Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPM601-C and is the answer not in the manual?

Questions and answers

Related Manuals for RUGGED MONITORING UPM601-C

Summary of Contents for RUGGED MONITORING UPM601-C

  • Page 1 All rights are reserved. The information in this document may not be reproduced or passed on in any manner without prior written consent of Rugged Monitoring. Rugged Monitoring shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

  • Page 2: Table Of Contents

    NSPECTING THE DEVICE ....................16 ETURNING DEVICES DAMAGED IN TRANSIT ................................. 17 TORAGE PREREQUISITE FOR UPM601-C INSTALLATION ................. 18 PRODUCT DRAWING ............................. 20 PRODUCT INSTALLATION .......................... 22 ............22 HECKING ENVIRONMENTAL CONDITIONS AND INSTALLATION SPACE COMMUNICATION PROTOCOL ......................... 23 10.1...
  • Page 3 Permanent damage may be done to the PD Monitor or Sensors if not properly used as per instructions. UPM601-C PD Monitor do not contain any user-serviceable parts. Opening PD Monitor or Sensors will void warranty and will damage its rated sealing. Always seek servicing from an authorized Rugged Monitoring service depot.

  • Page 4: Document Revision

    OCUMENT EVISION Description Date Initial First Release 24-05-2023 Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.

  • Page 5: Rugged Monitoring Warranty Notice

    ARRANTY OTICE UPM601-C Partial Discharge Monitor is guaranteed (Parts and Workmanship) for one full year from the date of purchase (different warranty conditions may have been negotiated for specific customers; for those cases, these conditions would supersede this standard text). Upon written notification of any defect, Rugged Monitoring will either repair or replace any faulty product or components thereof.

  • Page 6: General Description

    PD activity, it can effectively identify weak points in the insulation system and help in diagnosing the insulation condition of an electrical asset. The UPM601-C Monitor is designed to detect and record UHF signals emitted by partial discharges in electrical assets. Its primary purpose is to conduct surveys, providing timely alerts about potential faults and allowing corrective actions to be taken before complete breakdown occurs.

  • Page 7: Safety Precautions

    • Observe all safety labels on the product. • Keep all safety labels on the product complete and legible. • Replace damaged or obsolete safety markings. Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.
  • Page 8 • Change product only after consultation with Rugged Monitoring Spare Parts Spare parts not approved by Rugged Monitoring can lead to personal injury and property damage to the product. • Use only replacement parts approved by the manufacturer. •...
  • Page 9 Our experienced team guarantees the proper execution of all tasks. If work is not conducted by the Rugged Monitoring technical service, it is essential to ensure that the personnel involved are trained and authorized by Rugged Monitoring to maintain the quality standards.
  • Page 10 Do’s & Don’ts Do's: • Ensure that UPM601-C devices are properly grounded and connected to appropriate power source of 100 to 240 Vac @50/60Hz, 50W • Regularly inspect electrical connectors, plugs, and devices for any signs of damage or wear and replace them if necessary.

  • Page 11: Getting Started

    ETTING TARTED UPM601-C is a state-of-the-art PD monitor. It has 4 UHF Channels; transient over voltages protected, software configurable band pass filters, 200 –3000 MHz, 250 MS/s sampling rate. This monitor can be used to perform Online testing. It is packed with features that are result of extensive and dedicated research and development.

  • Page 12: Instruments & Controls

    5.1 Instruments & Controls The UPM601-C is equipped with advanced instruments and controls designed to revolutionize PD Monitoring. With the flexibility of either 4 UHF channels, this cutting-edge device offers enhanced capabilities for detecting and analyzing partial discharge (PD) in Transformers, Switchgears and Power Cables.
  • Page 13 Bottom View RHS View Rear View: 1. PD Alarm: Gives Alarm for Partial Discharge Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.
  • Page 14 5. Communication: Is provided with RJ45 6. Power Input: The UPM601-C requires 100 to 240 Vac @50/60Hz, 50W. This power input range allows flexibility in connecting the UPM601-C to a suitable power supply source within the specified voltage range.

  • Page 15: Upm601-Cmonitor Specifications

    5.2 UPM601-C monitor specifications This is only a summary of the most important specifications; for complete product specifications, please refer to the marketing product brochure. Description UPM601-C ✓ Transformers Application for Asset ✓ Switchgear Types ✓ Power Cables ✓ Usage...

  • Page 16: Unpacking

    Check that the items received comply with those listed in the delivery documents. Inspecting the device UPM601-C requires careful handling before installation on site. Please inspect the device for any signs of damage that may have occurred during transportation. If you identify any damage, kindly follow these instructions: •...

  • Page 17: Storage

    Storage For proper storage of UPM601-C before installation, it should be retained in its original transport packaging. Ensure to store it in a dry and dust-free environment. Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.

  • Page 18: Prerequisite For Upm601-C Installation

    Availability of UHF Sensors List. Is System in shutdown condition before connecting sensors to UPM601-C. Ensure the PD sensors are to be properly connected to UPM601-C. Mandatory Check List after commissioning Completion S. No Item to be verified / Inspected Check the tightness of UPM601-C Device.
  • Page 19 Check and verify the incoming power source by multimeter i.e., 100 to 240 Vac @50/60Hz, 50W before turning ON Check and verify earthing connection. Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.

  • Page 20: Product Drawing

    RODUCT RAWING Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.
  • Page 21 Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.

  • Page 22: Product Installation

    C with the correspondingly. Carefully place the UPM601-C unit into place, ensuring that it engages securely. Take care to align the UPM601-C correctly and avoid forcing it onto the surface, as this may damage the device or the mounting mechanism.

  • Page 23: Communication Protocol

    Channel 03 Discharge Rate Alarm 0 = Good 16 Bit Signed Integer Channel 04 Status 1 = Bad 16 Bit Signed Integer Channel 04 Maximum Amplitude 16 Bit Signed Integer Channel 04 Average Amplitude Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.
  • Page 24 16 Bit Signed Integer Channel 08 Maximum Amplitude 16 Bit Signed Integer Channel 08 Average Amplitude 16 Bit Signed Integer Channel 08 Maximum Discharge Rate 16 Bit Signed Integer Channel 08 Average Discharge Rate Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.

  • Page 25: Iec61850

    AmplAlrm: Amplitude Alarm DschRateAlrm: Discharge Rate Alarm AmplWar: Amplitude Warning DschRateAlrm: Discharge Rate Alarm MaxAmplitude: Maximum Amplitude AvgAmplitude: Average Amplitude ChanStatus: Channel Status The .CID file can be provided upon a request to Rugged Monitoring. Document no. MAN0054-EN-R01 Copyright Rugged Monitoring Inc.
