I Precautions
Storage
1. Keep this product away from extremely hot or cold places. The
storage temperature ranges from -40
temperature from -5
2. Do not use this product at damp environment like bathtubs, wash
basins, kitchens, washtubs, as well as basements, swimming pools
or similar places.
3. Do not expose your TV set to high humidity, dust or oil smoke.
4. Do not throw or drop this product.
5. Do not subject this device to the inside of a case or strong
vibrations, avoiding strong collision.
6. Do not push on or scrub this product with sharp objects.
Maintenance
1. Disconnect all cables of this device at first before cleaning.
2. Wipe the enclosure, screen and keys using soft cloth with a little
soft detergent on.
3. Do not use polishing cloth, abstergent, and all types of propellants
or chemical detergents like alcohol and benzene to clean your device.
1. Do not watch television programs or turn your TV set on for your
own and others' safety.
2. It is very dangerous to watch television programs or operate the
TV set while driving.
Bright spots or dark spots may appear on the screen. This is a
normal phenomenon associated with the active matrix display
technology and is not a sign of malfunction. Do not attempt to
maintain. For any failures, please turn off your TV set immediately
and contact us or your dealer. This device integrates a great deal of
fine electronic components. Disassembly or alternation may result in
damages or breaks.
to 60
to 40 .
Warning
Special Note
-1-
and the working
English version
Advertisement
Table of Contents
Summary of Contents for SWEEX 7 INCH DVB-T TV 16:9
- Page 1 3. Do not expose your TV set to high humidity, dust or oil smoke. 4. Do not throw or drop this product. 5. Do not subject this device to the inside of a case or strong vibrations, avoiding strong collision.
- Page 2 4. POWER/MODE: Standby/Mode shift 5. Remote-control receive window 6. AV Output 7. AV Input 8. Headphone jack 9. Panel buttons 10. SD/MMC/MS type CARD input port 11. USB connect jack 12. 12V DC Input 13. Speaker 14. Input of external antenna...
-
Page 3: Description Of Panel Buttons
2. S.SHOW (Scan Button): While viewing pictures, press it to change the display mode under CARD mode. 3. MENU/P.ADJ: A short press on it pops up the menu and a long press for three seconds pops up the LCD image adjust interface. In the menu interface, press Up/Down button to adjust the direction and the Left/ Right button to configure. - Page 4 V IDescription of Buttons on Remote Control POWER (Power On / Off): Press this button to turn off the TV, press it again to turn on the TV. MUTE (Mute): Press this button, sound disappears, press it again or VOL+ to resume normal sound.
- Page 5 (Retunr key): Under DTV/ATV mode, press to return to the previous channel, under CARD mode, press to return to backward menu step to step. P.ADJ (Picture adjust key): Enable to select brightness, contrast, color and TINT, press...
-
Page 6: Connection Of Main Interfaces
AV cable. Insert the audio left channel cable into the white end and the audio right channel cable into the red end. Then, insert the AV cable into AV/OUT jack. Note: AV/OUT is only available in DTV and CARD mode. - Page 7 After you device is connected to power supply, the system will implement an installation guide for your first installation. 7.1 Press VOL+ or VOL- to select YES then press OK to confirm. Then, the following three options will appear: Country (Set according to you location. Improper configure may lead to signal receive failure.)
-
Page 8: Dvb-T Menu Operation
English version VIII DVB-T Menu Operation Press the MENU button on your remote control or this device to pop up the menu, as shown in the figure. This DVB-T system offers seven options. Press CH+/CH- to select and VOL+/OK to access the submenu. - Page 9 English version Note: When the Parental Control lock set to be ON, a password is needed for you to delete all channels and enter SEARCH and FIRST TIME INSTALLATION mode. If it is set to be OFF, no password is required.
- Page 10 The default password is 8888 . Channel Lock: This item is set to be OFF as default. To start setting, set it as ON. Parental Setting: Press to set. Change PIN: Press to change your password.
- Page 11 English version 8.5 Game Press CH+/CH- on your control to move the yellow cursor to select a game. Press OK to confirm. Mine Tetris Gomoku Calendar Press EXIT on your control to return to the game menu. Keep pressing EXIT on your control for the system to save your settings and return to the playing interface.
- Page 12 English version Warning When the lock of the Parental Control menu is set to be ON, a password is needed for you to delete all channels and enter SEARCH and FIRST TIME INSTALLATION mode. If it is set to be OFF, no password is required.
- Page 13 This window indicates that the channel is locked for protection. 8.8.5 Mosaic Images This kind of image indicates poor signal quality. In this way, your TV can not resolve the images and thus shows mosaic images. If this condition occurs frequently, please check whether your receiving antenna is well connected.
-
Page 14: Main Menu
CONTRAST COLOUR RESET Press CH- or CH+ to select BRIGHT and press VOL- or VOL+ to adjust its analog. Press CH- or CH+ to select CONTRAST or COLOUR in turn and adjust the analog in the same way. Press CH- or CH+ to select RESET. - Page 15 SWAP, FINE, SEARCH, SOUND-SYS and COLOR-SYS. REMEMBER: Press VOL-/VOL+ to select OFF. Thus, this channel does not display when you change channels. If it is set to be ON, this channel would display on changing channels. AUTO-SEARCH: Press VOL-/VOL+ to start AUTO-SEARCH function.
- Page 16 If the signal intensity is very poor or too weak, ill images would still occur with strong noise, swing and bad audio effect no matter how you adjust the antenna. This is not the failure of your TV. Try an open antenna or a cable TV if the telescopic antenna does not work.
- Page 17 English version 9.4 Proper Receiving 9.4.1 Access the setting entries of the Language in the System to choose your required OSD language. 9.4.2 Access the setting entries of the AUTO-SEARCH and SEARCH and make sure whether the systems are set according to the responding transmitting requirements.
-
Page 18: Operations In Card Mode
Press OK to confirm. Then, press to enter the menu that you want to play. For MP3/WMA music files, press OK and the system will play the first track in this menu automatically. For JPEG files, you need to use the direction button to choose the required file. - Page 19 OK/MUSIC button on the panel to play MP3 music files if there are such files in the CARD or USB. In this way, you can view pictures while listening to music. To adjust the volume, press and hold the VOL+/VOL- button for three seconds.
-
Page 20: Troubleshooting
English version XI Troubleshooting The following phenomenon does not indicate failures. Before you contact us for repair, please check your device according to the approaches below. Problems Causes The AC adapter does not connect to the vehicle adapter properly; No picture or sound Non-permissible power is applied;... -
Page 21: Specifications
Decode standard: MPEG 2 ISO/IEC 13818 MPEG2 MP@ML Audio decode standard: MPEG1 LAYER 1, II MUSICAL ATV system Analog receive frequency: DK/I 49.75 MHz - 847.25 MHz BG 48.25 MHz - 847.25 MHz Analog color system: PAL/SECAM Analog audio system: DK... - Page 22 English version Warning This manual is for your reference only. The information in the Manual is subject to change without prior notice. The company reserves the right to explain for any unknowns, errors or omissions. Warning No elements are recoverable inside your device. Do not attempt to open it to improve your TV set.
