Summary of Contents for EAT E-Glo 2
- Page 1 EAT E-Glo 2 Phono Preamplifier Owner´s Guide E-Glo 2 08.04.2024...
-
Page 2: Important Safety Instructions
Unpacking The EAT E-Glo 2 phono preamplifier should be removed from its box with care. We suggest that you keep all of the original packaging, storing it in a safe, dry place in the event that you´re required to transport this product. - Page 3 EAT E-Glo 2 Power Supply unit Power cables Connect the power cable from the EAT E-Glo 2 Power Supply Unit to the POWER socket of the EAT E- Glo 2 Phono Preamplifier Unit and then connect the E-Glo 2 Power Supply Unit to the mains.
- Page 4 Control Panel POWER The rocker switch on the left side turns the unit ON or back to OFF. (EAT E-Glo 2 Power Supply Unit has to be connected to the EAT E-Glo 2 Phono Preamplifier Unit and turned ON). On and Off sequence: the Power Supply unit heats up for 40 seconds after it´s switched ON. This period is indicated by blinking of the Gain1 and Gain2 LED´s.
-
Page 5: Front Panel Indicators
Output connectors (OUT) Connect the Output of the phono amplifier to a line input (such as AUX, CD, Tuner, Tape or Video) on your amplifier. E-Glo 2 08.04.2024... -
Page 6: Technical Specifications
Power connection (POWER) Connect the power connector from the EAT Power Supply unit to the POWER socket of the phono amplifier before connecting the EAT Power Supply unit to the mains. Gain selection (G1 / G2 DIP switches) Use the DIP switches to select desired gain. Value depends on the valves used. Standard values with the original valves from the factory are G1: 76dB or G2: 70dB.
