Version EFS03282024
INSTALLATION, INSTRUCTION
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warning.ca.gov
EF40, EF50, EF60
& SERVICE MANUAL
PLEASE SAVE THIS
MANUAL FOR FUTURE
REFERENCE.
READ THIS MANUAL CAREFULLY. SEE INSIDE
COVER FOR IMPORTANT INFORMATION ABOUT
THIS MANUAL. KEEP INSTRUCTION WITH
APPLIANCE FOR FUTURE REFERENCE.
FOR MODELS:
IPX4
Advertisement
Table of Contents
Related Manuals for EUROfase HEATING EF40
Summary of Contents for EUROfase HEATING EF40
- Page 1 FOR MODELS: EF40, EF50, EF60 INSTALLATION, INSTRUCTION & SERVICE MANUAL IPX4 PLEASE SAVE THIS MANUAL FOR FUTURE REFERENCE. WARNING READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT CANCER AND REPRODUCTIVE HARM THIS MANUAL. KEEP INSTRUCTION WITH www.P65Warning.ca.gov APPLIANCE FOR FUTURE REFERENCE.
- Page 2 ON L4B 1L8, Note: Eurofase Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form without prior written consent from Eurofase Heating. EurofaseHeating.com...
-
Page 3: Table Of Contents
Contents Contents WARNINGS ..................Page 4 OVERVIEW ..................Page 6 APPLICABLE CODES & STANDARDS ..........Page 7 TECHNICAL SPECIFICATIONS ............Page 7 ELECTRICAL INSTALLATIONS ............Page 8 MOUNTING HEIGHT / CLEARANCES ..........Page 9 MOUNTING OPTIONS ............... Page 10 INSTALLING QUARTZ ELEMENT ............Page 11 MAINTENANCE INSTRUCTIONS ............ -
Page 4: Warnings
Warnings PLEASE READ ALL INSTRUCTIONS PRIOR GOOD TO INSTALLING OR USING HEATER. This product may cause a shock or possible ignition if service is attempted without first disconnecting its power source. KNOW! Keep electrical cords, drapery, furnishings and other combustible materials at least 3.3ft (1m) from the heater’s front fascia and keep them For optimal heater away from the two sides and rear. - Page 5 Warnings WARNING The heater should only be used as described in this manual. Any use not recommended by the manufacturer may result in fire, electric shock, or personal injury. Read and understand the installation, operating, and maintenance INSTALLATIONS: instructions thoroughly before installing or servicing this equipment.
-
Page 6: Overview
Overview Standard Grille Heater Body Quartz Element What’s in the box? Please inspect that all parts are included in the package. M o u n t i n g B r a c k e t M o u n t i n g B r a c k e t S c r e w H o l e S c r e w H o l e 16.5 in... -
Page 7: Applicable Codes & Standards
Electrical Code, NFPA 70, or the Canadian Electrical Code, Part 1, C22.1. Eurofase EF40, EF50, Ef60 heaters are designed and manufactured for residential and commercial heating applications for indoor and outdoor use, in accordance with the Standard for Fixed and Location-Dedicated Electric Room Heaters, UL 2021, and the Canadian Standard for Electric Air Heaters, CSA C22.2 No. -
Page 8: Electrical Installations
Read and follow installation clearance requirements outlined in this manual. The Appliance MUST be connected to a properly grounded electrical source. WIRING DIAGRAM EF40, EF50 AND EF60 MODELS 277V AC 208V / 240V / 480V AC L1(BLACK) -
Page 9: Mounting Height / Clearances
Mounting Height / Clearances 1. The minimum installation height from the floor to the heater shall be: 6ft (1.8m) American market, 8ft (2.4m) Canadian market 2. The minimum clearances from the ceiling, walls and other objects are shown in the pictures below. 4. -
Page 10: Mounting Options
ONE HOUR FIRE-RATED ITEM NO. DESCRIPTION FITS EF39FMPFB, EF39FMPFS, EF39FMPFSMG, EF39FMPFW 39” Flush Mount Kit EF40, EF50 EF61FMPFB, EF61FMPFS, EF61FMPFSMG, EF61FMPFW EF60 61” Flush Mount Kit *Flush mount kits sold seperately *MG- Marine Grade Please reference FLUSH MOUNT KIT Instruction... -
Page 11: Installing Quartz Element
Installing Quartz Element OPEN INSERT ELEMENT ELEMENTS LOCK INTO BRACKET SUPPORT BRACKET Open Lock Bracket to insert Loosen Quartz screw Element to open (x2) Lock Bracket CLOSE ELEMENT LOCK BRACKET Tighten screw once closed to secure the 2 Quartz Element TIGHTEN OUTER HEX NUT, LOCK WASHER AND LEAD WIRE RING TERMINAL TO THE THREADED STUD Threaded Stud Lead Wire Ring Terminal... -
Page 12: Maintenance Instructions
• Full list of product models with specifications can be found on our Eurofase Heating brochure (EurofaseHeating.com/Download). • For optimal comfort, it is best to heat from two sides rather than from just one. However, this may not be practical in some cases. -
Page 13: Replacement Parts
EF30480E 480V 3000W Quartz Element 480V 3000W ITEM # DESCRIPTION FITS EFDEEF2 Dual Element End Reflector EF40, EF50, EF60 EF39BOD Body Reflector – 39” EF40, EF50 EF61BOD Body Reflector – 61” EF60 EF39LWR Lead Wire Set – 39” EF40, EF50 EF61LWR Lead Wire Set –... -
Page 14: Manufacturer Warranty
Eurofase Heating (warrantor) will furnish the original owner replacement parts for any component part which fails before three years of use from date of original purchase. At our option, Eurofase Heating may offer to rebuild or replace the heater within the limited warranty period. -
Page 15: Troubleshooting
Troubleshooting SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION 1. Insufficient capacity for 1. Consider adding more heaters to the area or the application. opting for a model with greater capacity. 2. Mounting height or distance outside of 2. Decrease the mounting Insufficient Heat the recom mended range. - Page 16 EUROFASE HEATING WARRANTY REGISTRATION Customer Name: Address: City: State/Province: Zip/Postal Code: Country: Phone: Email: Model #: Serial No.#: Dealer’s Name: Date Purchased: Dealer’s Address: This Warranty Registration Card must be returned within 30 days of purchase to properly activate your warranty.
